USER MANUAL
Table of Contents
Safety Information................................................................................................3
Specifications......................................................................................................4
Main Power Connection.........................................................................................5
DMX-512 Connection.............................................................................................5
DMX Profile.............................................................................................................................6
Main Control Menu..................................................................................................................7
Rigging the Fixture................................................................................................8
Cleaning & Maintenance..........................................................................................................8
Parts List..................................................................................................................................8
Advertisement
Table of Contents
Related Manuals for Mega Lite 7000-Drama LED W
Summary of Contents for Mega Lite 7000-Drama LED W
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information……………………………………………………………………………………3 Specifications……………………………………………………………………………….………..4 Main Power Connection…………………………………………………………………………..5 DMX-512 Connection……………………………………………………………...……………..5 DMX Profile..........................6 Main Control Menu........................7 Rigging the Fixture…………………………………………………………..……………………….8 Cleaning & Maintenance......................8 Parts List..........................8... -
Page 3: Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Technical Information Part Numbers Fixture 7000-Drama LED W Mechanical Specifications 23” DMX Connectors: 3-pin XLR connectors in/out Power Connections: Nema 5-15 cable mounted connection Thermal: Maximum ambient temperature 40° C Maximum surface temperature 60° C Display: Digital Fastening System: Mounting Yoke... -
Page 5: Main Power Connection
120 Ohm resistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it in to the last fixture on the signal run. Pre-manufactured terminator plugs are availa- ble for purchase from your Mega-Lite dealer (HOS-DMXT). -
Page 6: Dmx Profile
DMX Profile Drama W Mode A DMX Chanel Function Description Value On/Off LED off 0% 0-250 LED on 100% 251-255 Drama W Mode P DMX Chanel Function Description Value Dimmer LED intensity (off to on) 0-255 Drama W Mode F DMX Chanel Function Description... -
Page 7: Main Control Menu
Main Control Menu CONTROL BOARD The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each func- tion and its options. -
Page 8: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. - Page 9 Please visit our website for any other related technical documents. For service related issue please contact our service dept. Monday—Friday 9am to 6pm CST Voice: 210-684-2600 E-mail: service@megasystemsinc.com Specifications in this manual are subject to change. Mega-Lite 18668 Highway 16N Helotes, TX 78023 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
