USER MANUAL
Safety Information..............................................................3
Specifications.................................................................... 4
Main Power Connection..................................................... 5
IR Controller...................................................................... 5
Wireless Control Set up..................................................................6
Rigging the Fixture..............................................................7
Cleaning & Maintenance.................................................................7
Parts List.........................................................................................7
Advertisement
Table of Contents
Related Manuals for Mega Lite Color PAC 150 DMX
Summary of Contents for Mega Lite Color PAC 150 DMX
- Page 1 USER MANUAL Table of Contents Safety Information…………………………………………………..…3 Specifications………………………………………………………….. 4 Main Power Connection…………………………………………….. 5 IR Controller………….……………………………………………..5 Wireless Control Set up..............6 Rigging the Fixture……………………………...……………………..7 Cleaning & Maintenance..............7 Parts List..................7...
- Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5.
-
Page 4: Technical Information
Technical Information Part Numbers 7316– Color PAC 150 DMX Mechanical Specifications DMX Wireless: W-DMX and 3 pin XLR Thermal: Maximum ambient temperature 104° Maximum surface temperature 140° Fastening System: Tear drop mounting 6.25” Power connection: DC Connection 9V 100mA Battery Type: 2 18650 3.7V 2200mA... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 90V to 240V from 50Hz to Cable (USA) Cable (EU) - Page 6 Wireless DMX Setup To Connect to a fixture using wireless DMX. 1. Power On the Color PAC DMX and the wireless function in the rear of the unit. 2. Make sure fixtures you are wanting to connect via wireless DMX have the receive function 3.
-
Page 7: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 8: Warranty Information
Customer Support Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob- lem. Please visit our website for any other related technical documents. For service related issue please contact our service dept.
