Alto-Shaam 500-1D Installation Operation & Maintenance

Alto-Shaam 500-1D Installation Operation & Maintenance

Hot food holding electric
Hide thumbs Also See for 500-1D:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Operation & Maintenance, Installation, Operation & Maintenance Manual
500-1D
500-2D
500-3D
W164 N9221 Water Street • P.O. Box 450
Menomonee Falls, Wisconsin 53052-0450 U.S.A.
262.251.3800 • 800.558.8744
PHONE:
262.251.7067 • 800.329.8744
FAX:
www.alto-shaam.com
Printed in U.S.A.
500-1DN
500-2DN
500-3DN
U.S.A. / CANADA
U.S.A. ONLY
Consult instructions
for operation and use.
Drawer Warmers
Hot Food Holding
500-1D
500-2D
500-3D
500-1DN
500-2DN
500-3DN
• Installation
• Operation
• Maintenance
MN-29742 (Rev. 9) • 12/17
Electric

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500-1D and is the answer not in the manual?

Questions and answers

Related Manuals for Alto-Shaam 500-1D

Summary of Contents for Alto-Shaam 500-1D

  • Page 1 Drawer Warmers Electric Hot Food Holding 500-1D 500-1D 500-1DN 500-2D 500-3D 500-1DN 500-2DN 500-3DN 500-2D 500-2DN • Installation • Operation • Maintenance 500-3D 500-3DN W164 N9221 Water Street • P.O. Box 450 Menomonee Falls, Wisconsin 53052-0450 U.S.A. 262.251.3800 • 800.558.8744 PHONE: U.S.A.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Delivery .

  • Page 3: Delivery

    . This manual must be read and understood by all people using or installing the appliance . Contact the Alto-Shaam Tech Team Service Department if you have any questions concerning installation, operation, or maintenance .

  • Page 4: Transportation And Damage Claims

    . fi led and actively pursued . Alto-Shaam cannot, however, 2 . Do not sign a delivery receipt or a freight bill until fi le any damage claims, assume the responsibility of any a proper count has been made and inspection of all claims, or accept deductions in payment for such claims .

  • Page 5: Unpacking

    Alto-Shaam of all liability . • Remove all protective plastic fi lm, packaging materials, and accessories from the appliance before connecting electrical power . Store any accessories in a convenient place for future use .

  • Page 6: Safety Procedures

    . Operating instructions and warnings must WARNING be read and understood by all operators and users . Alto-Shaam recommends regular staff training to avoid Indicates a hazardous situation that, if not avoided, could the risk of accident or damage to the appliance . Operators result in death or serious injury.
  • Page 7 If your appliance makes an especially loud noise catch fire. If fat deposits and/or food waste warranty and relieve Alto-Shaam of all liability . when starting up, shut down the appliance and call a inside the appliance ignite, shut down qualifi ed and trained service technician .

  • Page 8: Installation

    Do not store or use gasoline or other experienced workers when moving or flammable vapors or liquids in the vicinity leveling appliance and handling accessories. of this or any other appliance. This Alto-Shaam Minimum Clearance Requirements appliance must be Back 3" (76mm) ®...
  • Page 9 Installation 500-1D, 500-2D, 500-3D 12-5/16" (312mm) Electrical Connection 24-5/8" (624mm) 43-3/8" (1101mm) Cord Length: 120V - 5' (1524mm) 208-240V - 8' (2438mm) 230V - 8' (2438mm) 6-3/4" (171mm) FOR 4-7/8" (121mm) LEG STAND OR 5" (127mm) FOR CASTER STAND ASSEMBLY CASTER STAND ASSEMBLY WITH 3"...
  • Page 10 Installation 500-1DN, 500-2DN, 500-3DN 8-5/16" (211mm) Electrical Connection 16-11/16" (423mm) 53-3/4" (1364mm) Cord Length: 120V - 5' (1524mm) 208-240V - 8' (2438mm) 230V - 8' (2438mm) 6-3/4" (171mm) FOR 4-7/8" (121mm) LEG STAND OR 5" (127mm) FOR CASTER STAND ASSEMBLY CASTER STAND ASSEMBLY WITH 3"...

  • Page 11: Electrical Connection

    Electrical Connection 1 . An identification tag is permanently mounted on the This section is provided for the assistance of Drawer Warmer . qualified and trained service technicians only and is not intended for use by untrained or 2 . Plug Drawer Warmer into a properly grounded receptacle only, positioning the unit so the power unauthorized service personnel.

  • Page 12: Operation

    Operation Before initial use: Food Product Tips Clean both the interior and exterior of the unit with a Bread and Rolls clean, damp cloth and mild soap solution . Rinse carefully . Breads and rolls are traditionally difficult to hold for Clean and install the drawer warmer pan(s) .
  • Page 13 Operation 1. Preheat Drawer Warmer at 200°F (93°C) for 30 minutes 5 . Check to ensure the drawers are securely closed, before loading hot food. and use the Up Arrow or Down Arrow to set the temperature to 160°F (71°C) . Push power switch to the On position .

  • Page 14: General Holding Guidelines

    General Holding Guidelines Chefs, cooks and other specialized food service personnel Holding Temperature Range employ varied methods of cooking . Proper holding Meat Fahrenheit Celsius temperatures for a specific food product must be based Beef Roast — Rare 130°F 54°C on the moisture content of the product, product density, Beef Roast —...

  • Page 15: Cleaning And Preventative Maintenance

    (do not use water to extinguish a grease fire!). Failure to clean the appliance properly invalidates the warranty and relieves Alto-Shaam of all liability. MN-29742 • Rev 9 • 12/17 • Drawer Warmers...
  • Page 16 Cleaning and Preventative Maintenance WARNING WARNING To prevent serious personal injury, death, or To prevent serious injury, death, or property damage, always disconnect the appliance property damage: from the power source before cleaning Do not steam clean, hose down or flood the or servicing.

  • Page 17: Food Safety

    Food Safety Food fl avor and aroma are usually so closely related that it Internal Food Product Temperatures is diffi cult, if not impossible, to separate them . There is also Hot Foods an important, inseparable relationship between cleanliness Danger Zone 40°F to 140°F 4°C to 60°C and food fl avor .

  • Page 18: Troubleshooting

    Check main power circuit breaker to the unit and verify that the circuit breaker on the back of the unit is turned on, if applicable. Do not attempt to repair or service the unit beyond this point. Contact Alto-Shaam for the nearest authorized service agent. Repairs made by any other service agents without prior authorization by Alto-Shaam will ®...
  • Page 19 Troubleshooting Code Description Possible Cause s E-10 Cavity air sensor shorted Cavity air sensor reading < 5°F (-15°C) . Verify sensor integrity . E-11 Cavity air sensor open Cavity air sensor reading > 517°F (269°C) . Verify sensor integrity . Product probe is shorted E-20 Product probe reading <...

  • Page 20: Service

    Service Service View - Exterior Part numbers and drawings are subject to change without notice . MN-29742 • Rev 9 • 12/17 • Drawer Warmers...
  • Page 21 GASKET, WITH ADHESIVE 0.125 x 0.375 [lin ft] 1 NU-2361 NUT, 6-32 HEX, S/S 1012439 INNER BACK PANEL, 500-3D 1012673 INNER BACK PANEL, 500-2D 1012667 INNER BACK PANEL, 500-1D 1012445 OUTER CASING, 500-3D 1012671 OUTER CASING, 500-2D 1012664 OUTER CASING, 500-1D 1012446...
  • Page 22 Service AME SPOT LLER 0 x 1-1/8" FLAT HD Service View - Drawer Assembly LDER, SHORT, S/S ER W/HANDLE WER FRONT SPOT WER, OUTER , #44, S/S THREADED, 1/4-20 NC ACORN #18-8, S/S Non-Vented Drawer Vented Drawer Part numbers and drawings are subject to change without notice . Item Part Description 5017810...
  • Page 23 Service Service View - Narrow Exterior Part numbers and drawings are subject to change without notice . WARNING DANGER To prevent serious injury, death, or property To prevent serious injury, death, or property damage, always disconnect the appliance damage, always lock-out or post breaker from the power source before cleaning or servicing.
  • Page 24 Service Service View - Narrow Exterior Parts List Item Part Description 1493 BRACKET, SENSOR MTG. 1012779 TOP COVER IN-2003 INSULATION BK-29605 CONTROL SENSOR BLOCK CC-34970 WARMER CONTROL GS-23622 GASKET ADHESIVE 0.125 x 0.375 [lin ft] NU-2361 NUT, 6-32 HEX, S/S 1012778 INNER BACK PANEL, 500-3DN 1012790...
  • Page 25 Service Service View - Narrow Drawer Assembly Non-Vented Drawer Vented Drawer Part numbers and drawings are subject to change without notice . Item Part Description WS-2294 WASHER, 1/4" LOCK NU-2187 NUT, 1/4-20 NC ACORN #18-8 S/S 5017809 DRAWER FRAME BG-24890 BEARING, DRAWER WARMER SC-25018 SCREW, 1/4-20 x 1-1/8"...
  • Page 26 Service Service View - Electrical Item Part Description Item Part Description CC-34970 WARMER CONTROL WS-22297 WASHER, FLAT CR-34967 CONNECTOR-2 CONDUCTOR SC-36973 SCREW, PAN PH, METRIC, M5 SW-34769 SWITCH, ROCKER, 125-277V, 20A WS-22302 WASHER, SPLIT LOCK SP-29392 SPACER, SNAP-IN, 7/16 BU-3964 BUSHING, STRAIGHT, STRAIN RELIEF 1003936 HI-LIMIT PROTECTION COVER...

  • Page 27: Wiring Diagrams

    Wiring Diagrams MN-29742 • Rev 9 • 12/17 • Drawer Warmers...
  • Page 28 Wiring Diagrams MN-29742 • Rev 9 • 12/17 • Drawer Warmers...
  • Page 29 Wiring Diagrams MN-29742 • Rev 9 • 12/17 • Drawer Warmers...

  • Page 30: Limited Warranty

    This warranty is exclusive and is in lieu of all other warranties, express or implied, including the implied warranties of merchantability and fi tness for a particular purpose . In no event shall Alto-Shaam be liable for loss of use, loss of revenue or profi t, or loss of product, or for any indirect, special, incidental, or consequential damages .
