INSTALLATION HDS 6.3/32, 8.0/32, 9.5/30
17.33"
17.36"
61.00"
Floor Mounting Dimensions
31.77"
26.91"
34.79"
Control
Panel
64.00"
26.91"
9.801-509.0 - C • Karcher Operator's Manual
Piping to Outside
Customer
Supplied Draft
Diverter
19.50"
Dia
Exhaust Out
12" Dia.
1" Gas
Inlet
Connection
High Pressure
Connection
Inlet
Electrical
Connection
26.18"
Water In
3/4" GHF
3.64"
NOTE: Draft diverter should be
installed 3 ft. above exhaust outlet.
98015080-4
36"
Minimum
Out 22mm
Screw
9
