INSTALLATION HDS 3.5/20, 4.0/22, 3.9/30, 5.0/23, 4.8/30

12.00"
4.00"
48.54"
21.30"
8
24.50"
36.68"
Control
Panel
49.00"
Floor Mounting Dimensions
20.61"
20.61"
9.801-509.0 - C • Karcher Operator's Manual
Piping to Outside
Customer
Supplied Draft
Diverter
19.50"
24.00"
Dia.
Exhaust Out
10" Dia.
3/4" Gas
Inlet
Connection
High Pressure
Out 22mm
Connection
Inlet
Electrical
Connection
24.87"
Water In
3/4" GHF
3.70"
24.00"
NOTE: Draft diverter should be
installed 3 ft. above exhaust outlet.
98015080-3
36.00"
Minimum
Screw
