NOTES:
• The original factory-installed firmware is permanently available on the
SW USB. If the attempted firmware upload fails for any reason, the
switcher reverts to the factory-installed firmware.
• When downloaded from the Extron website, the firmware is placed in a
folder at
C:\Program Files\Extron\Firmware\SW USB
C:\Program Files (x86)\Extron\Firmware\SW USB
10.
On the Add Device window, the path to the new firmware file is displayed in the
field.
Figure 13. Add Device Window with an SW USB Switcher and Firmware File
Selected
11. Click . The Add Device window closes, and your SW USB name and information
Add
appear in the Devices section of the Firmware Loader window.
Figure 14. Firmware Loader Window with SW USB Device Added
or
(for Windows 7).
Path
SW USB Series • Operation 21
