Chapter IX. Data Center Bridging (DCB)
v. On the FC Ports, if a FC target is connected then perform the following steps -
switch(config)#vsan database
switch(config-vsan-db)#vsan 2
switch(config-vsan-db)# vsan 2 interface fc 2/2
switch(config-vsan-db)#exit
switch(config)interface fc 2/2
switch(config-if)# switchport mode auto
switch(config-if)# switchport speed auto
switch(config-if)# no shutdown.
vi. If you have not created a zone then make sure the default-zone permits the VSAN created,
otherwise the initiator and the target on that particular VSAN although FLOGI'd into the
switch will not talk to each other. To enable it, execute the below command.
switch(config)# zone default-zone permit vsan 2
4.2.

Configuring the Brocade 8000 switch

i. Configure LLDP for FCoE.Example of configuring LLDP for 10-Gigabit Ethernet interface.
switch(config)#protocol lldp
switch(conf-lldp)#advertise dcbx-fcoe-app-tlv
switch(conf-lldp)#advertise dcbx-fcoe-logical-link-tlv
ii. Create a CEE Map to carry LAN and SAN traffic if it does not exist. Example of creating a
CEE map.
switch(config)# cee-map default
switch(conf-cee-map)#priority-group-table 1 weight 40 pfc
switch(conf-cee-map)#priority-group-table 2 weight 60
switch(conf-cee-map)#priority-table 2 2 2 1 2 2 2 2
