Introduction

ADAM-3013 is a DIN-rail mounted, RTD input signal conditioning module

with 1000VDC 3-way isolation between input, output and power. The

switch configurable input and output offers flexible ,wide raging capability

for Platinum and Nickel RTDS. The input of the ADAM-3013 RTD input

can be configured for any one of up to fourteen defined temperature ranges

(see "Input Range" under "Specification" below) and two OEM-defined

ranges. The output is linearized to the RTD temperature input and can be set

for either 0~5V, 0~10V or 0~2 m A.

The ADAM-3013 is equipped with a dual function LED signal monitor. The

front mounted LED indicates both line power and conversion status.

Conversion operation is indicated by a flashed LED.If the LED is off, please

check that the power connection and wiring connections are correct.

3-way isolation completely eliminates ground loops from any

source.Isolation protects expensive SCADA systems from ground faults and

Table of Contents

Do you have a question about the ADAM-3013 and is the answer not in the manual?

Page 1 1000VDC 3-way isolation between input, output and power. The switch configurable input and output offers flexible ,wide raging capability for Platinum and Nickel RTDS. The input of the ADAM-3013 RTD input can be configured for any one of up to fourteen defined temperature ranges (see “Input Range”...
Page 2 RTD applications. The ADAM-3013 can be mounted on a DIN-rail and features daisy chain power wiring to connect easily from adjacent ADAM-3000 series modules in a compact space.Also,the ADAM-3013 modules uses single +24 VDC with very low power consumption and can be operate in environments with high humidity and wide temperature variation.
Page 3 Configuration Please refer to the following pages on the Adam-3013 configuration. Figure 1 shows the RTD Wiring of ADAM-3013. Figure 2 shows the terminal wiring of ADAM-3013.Positive terminals 9 and 7 are internally connected, as are negative terminals 12 and 10.Power can be connected through the adjacent modules, making wiring much easier.ADAM-3013...
