Specifications
Function
AC Current
Notes:
Accuracy is given as ± (% of reading + least significant counts) at 23C ±5C with relative humidity
lower than 80%. Accuracy is specified for a period of one year after calibration.
Position Error of Clamp: Accuracy and position error assumes centralized primary conductor at
optimum position, no external electrical or magnetic field, and within operating temperature
range.
Distance from
optimum position
*Add this error to the AC Current accuracy specification listed earlier in this section.
LCD displays '0' counts when the reading is < 10 counts.
ACA specifications are AC Coupled, True RMS.
For non‐sinusoidal waveforms, additional accuracy Crest Factor (C.F.) considerations exist as
detailed below:
Add 3.0% for C.F. 1.0~2.0
Add 5.0% for C.F. 2.0~2.5
Add 7.0% for C.F. 2.5~3.0
800.561.8187
Range Overload Reading (OL)
30.00 A AC
300.0A AC
3000 A AC
MA3010
15mm (0.6")
25mm (1.0")
35mm (1.4")
www.
33.00 A AC
330.0 A AC
3300 A AC
MA3010 Error*
+2.0%
+2.5%
+3.0%
9
.com
Accuracy
Resolution
(45 to 500Hz)
0.01A ±(3.0% + 5 digits)
0.1A ±(3.0% + 5 digits)
1A ±(3.0% + 5 digits)
MA3018 MA3018 Error*
35mm (1.4")
50mm (2.0")
60mm (2.4")
MA3010_MA3018 en‐GB_V1.0 1/15
information@itm.com
+1.0%
+1.5%
+2.0%
