Lexus LS500 Quick Manual
Hide thumbs Also See for LS500:
Table of Contents

Advertisement

Quick guide
Basic function
Navigation system
Audio/visual
system
Voice command
system
Information
Peripheral
monitoring system
Phone
Lexus Enform
Index
LS500_LS500h_Navi_OM50F66U_(U)
• Giving guidance for the route quickly
• Information to be read before operation
• Setting initial settings before operation
• Connecting the Bluetooth
• Operating the map screen
• Searching the map
• Activating the route guidance
• Listening to the radio
• Enjoying music and video
• Operating the voice command system
• Operating the weather information screen
• Checking the situation around the vehicle
• Operating the phone
(Hands-free system for cellular phones)
• Operating the Lexus Enform
• Search alphabetically
®
device
1
2
3
4
5
6
7
8
9
