Model No. : WLIVEX73414.0
Serial No : ___________
Serial Number
Decal
Write the serial number in the space
above for reference
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4,
Westgate Court, Silkwood Park,
OSSETT
WAKEFIELD
WF5 9TT
UNITED KINGDOM
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLIVEX73414.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Weslo WLIVEX73414.0

Summary of Contents for Weslo WLIVEX73414.0

  • Page 1 USER’S MANUAL Model No. : WLIVEX73414.0 Serial No : ___________ Serial Number Decal Write the serial number in the space above for reference CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health &...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT..................2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    WARNING : To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your bike before using your bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new Weslo® CityBi bike. manual, please see the front cover of this manual. To The Weslo® CityBi bike provides a selection of help us assist you, note the product model number features designed to make your workouts at home and serial number before contacting us.

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing materials until you finish all assembly steps. In addition to the included tool(s), as- sembly requires one Phillips screwdriver and one adjustable wrench Use the drawings below to identify the small parts needed for assembly.
  • Page 6 STEP 1 Attach front stabilizer (2) and rear stabilizer (4) to main frame (1) by fixing Carriage bolt(6), Arc wash- ers(8) and cap nut (9) STEP 2 Thread the right pedal (11R)which marked “R” onto the right side of the crank(10) , then circumvolved easilly and tighten;...
  • Page 7 STEP 4 Pull the handlebar wire(25) out of the hole of upright post post (17) ,then put the handlebar (24) onto the upright post (17) by using washer (23), inner hex bolt (21) and spring washer (22), then cover with the handlebar chuck cover (20).

  • Page 8: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE in one of the adjustment holes. Then, tighten the HOW TO ADJUST THE HEIGHT OF THE SEAT AND THE LATERAL SEAT POSITION knob. effective exercise, HOW TO ADJUST THE PEDAL STRAPS the seat should be at the proper height.

  • Page 9: How To Measure Your Heart Rate

    HOW TO MEASURE YOUR HEART RATE Measure your heart rate if desired. To measure your heart rate, hold the handgrip heart You can measure your heart rate using either the rate monitor with your palms resting against the handgrip heart rate monitor or a compatible heart contacts.

  • Page 10: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING HOW TO CHANGE THE BATTERIES Regular maintenance is important for optimal performance and to reduce wear. Inspect and properly tighten all parts each time the bike is used. If the brightness of the console’s display is weak, the Replace any worn parts immediately.

  • Page 11: Console Features

    CONSOLE FEATURES 1. Turn on the console To turn on the console, simply start pedaling or press a console’s button. 2. Press the arrow buttons Press the arrow buttons to choose the data you want to display. Follow the name of the value at the top of the screen.

  • Page 12: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: the first few minutes of exercise, your body uses carbohydrate calories for energy. Only after the first few minutes of exercise does your body begin to use Before beginning this or any exercise pro- stored fat calories for energy. If your goal is to burn gram, consult your physician.

  • Page 13: Exploded Drawing

    EXPLODED DRAWING...
  • Page 14 EXPLODED DRAWING...

  • Page 15: Part List Model

    PART LIST MODEL Key No. Qty. Description Key No. Qty. Description MAIN FRAME SCREW FRONT STABILIZER BELT TRAY ROLLER END CAP BELT REAR STABILIZER HEX SCREW ADJUSTABLE END CAP SPRING WASHER CARRIAGE BOLT M8×74 SPRING WASHER SCREW MAGNET BOARD AXLE ARC WASHER Φ20×D8.5×R30 MAGNET BOARD ACORN NUT M8...

  • Page 16: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
