Model No. : WLIVEX85212.0
Serial No. ___________
Serial number decal
Write the serial number in the
space above for reference.
QUESTIONS ?
If you have questions, or if there are
missing parts, please contact us:
UK
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
Whitwood, West Yorkshire
WF10 5QJ
UK
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USERʼS MANUAL
Visit our website
www.iconsupport.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLIVEX85212.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Weslo WLIVEX85212.0

Summary of Contents for Weslo WLIVEX85212.0

  • Page 1 USERʼS MANUAL Model No. : WLIVEX85212.0 Serial No. ___________ Serial number decal Write the serial number in the space above for reference. QUESTIONS ? If you have questions, or if there are missing parts, please contact us: Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING : To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your bike before using it. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    The exercice bike provides an array of features The model number is WLIVEX85212.0 and the lo- designed to make your workouts at home more cation of the serial number decal are shown on the effective and enjoyable.

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included tool(s), assembly requires an adjustable wrench and a Phillips screwdriver .
  • Page 6 STEP 1 Attach the front stabilizer (2) and rear stabilizer (3) to the main frame (1) with the carriage bolts (5), arc washers (6) and acorn nuts (7) as shown. Note: The Leveler end caps of the rear stabilizer can be ADJUSTED to keep the equipment stable. STEP 2 Attach the pedals (9L/R) to the Crank (8L/R) re- spectively, viewed from the rider’s exercising posi-...
  • Page 7 STEP 4 Connect the Extension Wire (13) with the sensor wire (11), then fix the handlebar post (17) to the main frame (1) with the Inner hex bolts (14) and arc washers (6). STEP 5 I: Feed the pulse wire (28) out of the handlebar post (17) through the top of the computer bracket.

  • Page 8: How To Operate The Bike

    HOW TO OPERATE THE EXERCISE CYCLE then press the ends of the pedal straps onto the tabs. HOW TO ADJUST THE HEIGHT AND THE LATERAL HOW TO PLUG THE POWER ADAPTER POSITION OF THE SEAT For effective exercise, IMPORTANT: If the exercise bike has been exposed the seat should be at the to cold temperatures, allow it to warm to room proper height.

  • Page 9: Console Features

    CONSOLE FEATURES ENTER : During the time setting mode, press this button to validate the hours and minutes. During the setting mode, press this button to validate the adjusted values. During the STOP mode, press this button to reset the values. START/STOP: For a quick start, press this button to start the counting of the console, it will start at 0.

  • Page 10: Desired

    the display. HOW TO USE THE PRESET PROGRAMS : Press the UP ou DOWN to select Program 1. The 1. Turn on the console resistance level is 5 by default. TIME wil flash on the console, press the UP and DOWN button to To turn on the console, press any button on the select the length of your workout.

  • Page 11: Maintenance And Troubleshooting

    Program 11 you define your HRC target desired. The HRC is calculated as follow : 220- your age. For As you pedal, change the resistance of the pedals instance, for a person of 35 years old : 220-35 = 185 by pressing the Resistance increase and decrease pulse/min.

  • Page 12: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your Before beginning this or any exercise pro- body uses carbohydrate calories for energy. Only af- gram, consult your physician.

  • Page 13: Exploded Drawings

    EXPLODED DRAWING—Model No. WLIVEX85212.0 part 1...
  • Page 14 EXPLODED DRAWING—Model No. WLIVEX85212.0 part 2...

  • Page 15: Part List

    PART LIST—Model No. WLIVEX85212.0 Item Description Qty. Item Description Qty. Main frame Washer Front Stabilizer Rear Stabilizer Ball Bearing Rear End Caps Bearing Collar Carriage bolt M8×L74 Sensor Arc Washer Screw ST3X10 Acorn nut M8 Tri-slot nut Crank Big washer Pedal 1 pr.

  • Page 16: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
