Page 1: Warning Decal Placement
USERʼS MANUAL Model No. WLIVEX79412.0 Serial No. : ___________ Serial No Decal Write the serial number in the space above for reference. QUESTIONS ? If you have questions, or if there are missing parts, please contact us: Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com... -
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............1 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING : To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your bike before using it. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for purchasing the Weslo® Elite. The this manual. To help us assist you, note the prod- bike provides an array of features designed to uct model make your workouts at home more effective and number and serial number before contacting us. -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and re- move the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included tool(s), assembly requires a Phillips screwdriver an adjustable wrench. - Page 6 STEP 1 Install the Front stabilizer (2) and Rear stabilizer (3) to the Main frame (1) and fixing with the Square neck bolt (13), Arc washers (14) and Acorn nut (15). STEP 2 Connect the Sensor connective wire (21) with the Sensor wire (16), and then fix the Front vertical tube (4) to the Main frame (1) with the Bolts (18) and Arc washers (14).
-
Page 7: Maintenance And Troubleshooting
STEP 4 Install the saddle (7) to the Horizontal seal post (31) with Multifunctional wrench. Then tighten the Horizontal seal post (31) on the Saddle supporting tube (6) with Flat washer(19),Knob nut (20). Finally, insert the Saddle supporting tube (6) to the Main frame (1) and tightly with Knob bolt (28) .You can control the Knob bolt (28) to adjust the appropriate height which is suitable for you . -
Page 8: How To Operate The Bike
HOW TO OPERATE THE BIKE HOW TO ADJUST THE HEIGHT AND THE LATERAL HOW TO PLUG IN THE POWER ADAPTER POSITION OF THE SEAT IMPORTANT: If the exercise bike has been exposed For effective exercise, to cold temperatures, allow it to warm to room the seat should be at the temperature before plugging in the power adapter. -
Page 9: Console Features
CONSOLE FEATURES Press this button to increase the resistance during the workout or during the setting mode to increase the values of Time, Distance, Calories, Age or gender or the programs. DOWN : Press this button to decrease the resistance during the workout or during the setting mode to decrease the values of Time, Distance, Calories, Age or Gender or programs. - Page 10 HOW TO USE THE MANUAL MODE heart rate along with the other modes. If your heart rate is not shown, make sure that your hands are 1. Turn on the console. positioned as described. Be careful not to move your hand excessively or to squeeze the metal contacts To turn on the console, press the On/Reset button too tightly.
- Page 11 Each program corresponds to a specific target : FInally, press START/STOP to start. Program 8 you define your HRC target 4. Change the resistance of the pedals as Program 9 corresponds to 55% of Max HRC desired. Program 10 corresponds to 75% of Max HRC Program 11 corresponds to 90% of Max HRC As you pedal, change the resistance of the pedals by pressing the Resistance increase and decrease...
-
Page 12: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your Before beginning this or any exercise pro- body uses carbohydrate calories for energy. Only af- gram, consult your physician. -
Page 13: Exploded Drawings
EXPLODED DRAWING—Model No. WLIVEX79412.0 part 1... - Page 14 EXPLODED DRAWING—Model No. WLIVEX79412.0 part 2...
-
Page 15: Part List
PART LIST—Model No. WLIVEX79412.0 Item Description Qty. Item Description Qty. Main frame Crank cover Front stabilizer Chain cover 1each Rear stabilizer Screw ST4.2×18 Front vertical tube Handle bar Screw ST3×10 Saddle supporting tube Lock washer Saddle Tension control wire Ball rack Computer Belt tray Pedal... -
Page 16: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
