Model No. WLIVEX79210.0
Serial No. ___________
Write the serial number in the
space above for reference.
QUESTIONS ?
If you have questions, or if there are
missing parts, please contact us:
UK
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
Whitwood, West Yorkshire
WF10 5QJ
UK
CAUTION
Read all precautions and instruc-
tions
in this manual before using
this equipment. Keep this manual
for future reference.
by WESLO
EasyFit.
by WESLO
USERʼS MANUAL
Visit our website
www.iconsupport.eu
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo WLIVEX79210.0
Summary of Contents for Weslo WLIVEX79210.0
- Page 1 WESLO EasyFit. by WESLO USERʼS MANUAL Model No. WLIVEX79210.0 Serial No. ___________ Write the serial number in the space above for reference. QUESTIONS ? If you have questions, or if there are missing parts, please contact us: Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING : To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
The model number is WESLO®Easy Fit offers a selection of features WLIVEX79210.0 and the location of the serial designed to let you enjoy this healthful exercise in number decal are shown on the front cover of this the convenience nd privacy of your home. -
Page 5: Assembly
ASSEMBLY STEP 1 Install the Front stabilizer (2) and Rear stabilizer (3) to the Main frame (1) and fixing with the Square neck bolt (13), Arc washers (14) and Acorn nut (15). STEP 2 Connect the Extended wire (21) with the Sensor wire (16), and then fix the Front vertical tube (4) to the Main frame (1) with the Bolts (18) and Arc washers (14). - Page 6 STEP 4 Install the Saddle (7) to the Saddle supporting tube (6) with the Washers (8) and Nylon nuts (32), put on the Extension plastic tube (30) to the Saddle supporting tube (6), and then stick the Saddle supporting tube (6) to the Main frame (1) with the Pop-pin knob (28).
-
Page 7: Console Features
CONSOLE FEATURES During the time setting mode, press this button to validate the hours and minutes. During the setting mode, press this button to validate the adjusted values. During the STOP mode, press this button to reset the values. START/STOP: For a quick start, press this button to start the counting of the console, it will start at 0. - Page 8 HOW TO USE THE MANUAL MODE hand excessively or to squeeze the metal contacts too tightly. For optimal performance, clean the 1. Turn on the console. metal contacts using a soft cloth; never use alcohol, To turn on the console, press the On/Reset button abrasives, or chemicals to clean the contacts.
- Page 9 HEART RATE CONTROL PROGRAMS : 1. Turn on the console To turn on the console, press any button on the console or simply begin pedaling. 2.Select your preset program Press the UP and DOWN button to select program 8 to 11 Wait until the word PROGRAM begins flashing.
-
Page 10: How To Operate The Exercise Cycle
HOW TO OPERATE THE EXERCISE CYCLE HOW TO ADJUST THE HEIGHT AND LATERAL HOW TO ADJUST THE PEDAL STRAPS POSITION OF THE SEAT To adjust the pedal straps, first pull the ends of the pedal straps off the tabs on the pedals. Adjust the For effective exercise, the seat should be at the pedal straps to the desired position, and then press the ends of the pedal straps onto the tabs. - Page 11 HOW TO MEASURE YOUR PULSE Measure your heart rate if desired. Contacts You can measure you heart rate using either the handgrip pulse sensor or the optional chest pulse sensor. Note: If you hold the handgrip pulse sensor and wear the chest pulse sensor at the same time, the console will not display your heart rate accurately.
-
Page 12: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your Before beginning this or any exercise pro- body uses carbohydrate calories for energy. Only af- gram, consult your physician. -
Page 13: Suggested Stretches
SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible. -
Page 14: Exploded Drawings
EXPLODED DRAWING—Model No. WLIVEX79210.0 part 1... - Page 15 EXPLODED DRAWING—Model No. WLIVEX79210.0 part 2...
-
Page 16: Part List
PART LIST—Model No.WLIVEX79210.0 N° Description N° Description Main frame Chain cover Front stabilizer Cross pan screw ST4.2×18 Rear stabilizer Front vertical tube Anti-loosing washer Handle bar Saddle supporting tube Ball rack Saddle Bottom bracket cup Washer D8 Cross pan screw ST3×10... -
Page 17: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING BATTERY REPLACEMENT Inspect and tighten all parts of the exercise cycle regularly. If the console display becomes dim, the batteries Replace any worn parts immediately. should be replaced; most console problems are the To clean the exercise cycle, use a damp cloth and a result of low batteries. -
Page 18: Notes
NOTES :... - Page 19 NOTES :...
-
Page 20: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
