  • Page 6: Introductions

    Via Bluetooth, it is simple for DBScar diagnostic connector to communicate with ScanPad 071; Equipped with an exclusive ScanPad 071 protection sleeve to prevent it from being damaged; Browser: built-in Wi-Fi module makes surfing on the internet freely; Email: allows you to send and receive email. External POP3 or IMAP email account for some common Web email service provider can be added;...

  • Page 7: Knowledge Of Scanpad 071

    1.3.1 Whole Set ScanPad 071 ScanPad 071 is composed of a ScanPad 071 tablet computer, a protection sleeve and a diagnostic connector (in red & black). Fig. 1-1 ScanPad 071 whole set A ---- ScanPad 071 tablet computer (See Chapter“1.3.2”) B ---- Protection sleeve (See Chapter “1.3.3”)

  • Page 8: Scanpad 071 Tablet Computer

    LAUNCH ScanPad 071 User’s Manual — Knowledge of ScanPad 071 1.3.2 tablet computer ScanPad 071 Fig. 1-2 ScanPad 071 tablet computer Name Notes POWER key In Off mode, press it to turn on ScanPad 071; In On mode, press it to activate the LCD if the LCD is blank.

  • Page 9: Scanpad 071 Protection Sleeve

    To remove protection sleeve from ScanPad 071 main unit, follow the steps described as below to proceed: 1. Pull the black sleeve outwards from the right margin of ScanPad 071, and then remove it completely. 2. Reverse the upper enclosure and then use the screwdriver to loosen all screws.

  • Page 10: Golo Diagnostic Connector (Applied For Personal Car Owners)

    To connect to PC for data transmission or upgrade via USB cable. This diagnostic connector works only with ScanPad 071. If it is not in use, please place it in right position. 1.3.5 GOLO diagnostic connector (applied for personal car owners) Fig.

  • Page 11: Technical Parameters

    LAUNCH ScanPad 071 User’s Manual — Knowledge of ScanPad 071 1.4 Technical Parameters ScanPad 071: Operating system: Android CPU: Dual core 1GHz Battery: 3000mh, rechargeable polymer lithium battery Standby time: It is subject to the using environment. Generally it can keep working for 4 hours.

  • Page 12: Package List

    ScanPad 071 User’s Manual — Knowledge of ScanPad 071 1.5 Package List While purchasing, please check the following accessories: • ScanPad 071 tablet computer (including ScanPad 071 protection sleeve) • Password envelope • DBScar diagnostic connector (red & black) • OBD II extension cable •...

  • Page 13: Preparations

    The charging time of battery varies with temperature condition and battery consumption status. While ScanPad 071 has low battery, a beep will sound. If it is very low, ScanPad 071 will be switched off automatically. Note: Do one of the followings to save power:...

  • Page 14: Power On / Power Off Scanpad 071

    2.4 Power on / power off ScanPad 071 2.4.1 Power on 1. Press the POWER key to turn on ScanPad 071. 2. If it is the first time you turned on ScanPad 071, the system will prompt you to make some initial setup. 3. Set your account.

  • Page 15: Customize Your Desktop

    LAUNCH ScanPad 071 User’s Manual — Knowledge of ScanPad 071 MAIN MENU key: To switch to main menu screen. SHORTCUT key: To view the recent applications. OPTION MENU key: To select operation option from the list. Notice bar: To notify users of new events and display the status (For detailed indicators, please see the following table.).

  • Page 16: Delete Items From The Desktop

    Drag: Hold and press the desired item, then drag it to a location. For example, drag to move or delete the application icon on the desktop. 2.8 Auto-rotate the screen To perform such operations as browsing webpage, viewing images etc, rotate ScanPad 071, the screen will automatically change the display direction. To...

  • Page 17: Lock & Unlock The Screen

    2.9 Lock & unlock the screen 2.9.1 Lock the screen • When ScanPad 071 is ON, press POWER key once to lock the screen; • The system will lock the screen automatically after ScanPad 071 remains idle for a long time.
  • Page 18 LAUNCH ScanPad 071 User’s Manual — Knowledge of ScanPad 071 The way to disable functions of ScanPad 071 is to set it as airplane mode. In this mode, all wireless radio waves will be disabled, including Bluetooth and WLAN. Do one of the followings to enable or disable airplane mode: •...

  • Page 19: How To Diagnose

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis 3 How to diagnose 3.1 Connect DBScar Follow the steps mentioned below to connect DBScar connector: Locate vehicle’s DLC socket. The DLC (Data Link Connector or Diagnostic Link Connector) is the standardized 16-cavity connector where diagnostic code readers interface with the vehicle's on-board computer.

  • Page 20: Bluetooth Setting

    ScanPad 071 User’s Manual — Vehicle Diagnosis 3.2 Bluetooth setting Enter ScanPad 071 Bluetooth setting screen (“Settings” --> “Wi-Fi” --> “Bluetooth”), slide the Bluetooth switch to ON and ScanPad 071 will start searching available Bluetooth device, tap the desired connector to pair and match.

  • Page 21: User And Connector Registration

    3.4 User and connector registration 3.4.1 User registration Tap the program icon on the desktop to launch the application, a disclaimer page will pop up on the window. Tap “I’ve read it” to enter the main menu screen. Tap “Log In” located at the upper right corner of the screen to enter a screen as indicated in Fig.
  • Page 22 LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Fig. 3-5 In Fig. 3-5, tap “Register Connector” if you want to experience vehicle diagnostic software. See Fig. 3-6. Fig. 3-6 Input the Serial Number and Verification Code, and then tap “Confirm”.

  • Page 23: Software Layout

    Diagnose: To enter vehicle diagnosing function. My Data: To view diagnostic report and operation log. What’s New: To view the Launch’s latest information and product trends. Customer Management: To manage customer’s information, including add...

  • Page 24: Download Diagnostic Software

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis new customer and remote diagnosis etc. One Key Upgrade: It enables you to perform online software update. Account: To maintain and manage your personal information. More: To view software version and user’s manual.
  • Page 25 LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Fig. 3-10 Tap “Check download” to enter download page. See Fig. 3-11. Fig. 3-11 Tap “Download” to start downloading. Once it is complete, a screen similar to the following will be shown on the screen: Fig.

  • Page 26: Start Diagnosing

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis context menu to download your software. For details, please refer to Chapter 3.11 One Key Upgrade. Fig. 3-13 3.6 Start diagnosing on the main menu screen, and then choose “Diagnose” to enter the vehicle selection page.
  • Page 27 LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Fig. 3-14 Tap the desired connector to start connecting. If successful, a pop-up message “Connected to 98384*****00” will be shown. After Bluetooth is properly connected, the system will enter software version selection screen. See Fig. 3-15.
  • Page 28 LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Fig. 3-15 To check whether a new version is available or not, click “Check Latest Version”. If a newer version is detected, it will start downloading the latest version. Tap the desired version to start initializing. After initializing is complete, the screen will display as below: Fig.

  • Page 29: Read Trouble Code

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Fig. 3-17 Tap “Engine”, the system will jump to the function menu. See Fig. 3-18. Fig. 3-18 To return to the previous screen, click 3.6.1 Read Trouble Code Tap “Read trouble code” in function menu, the screen will display the diagnostic result.

  • Page 30: Clear Trouble Code

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis 3.6.2 Clear Trouble Code Tap “Clear Trouble Code” function menu, the system will automatically delete the currently existing trouble code. Note: The trouble code will not disappear until the trouble was completely cleared.
  • Page 31 LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Check the box before the desired item and then click “Confirm”. To select all, click “Select all”. To deselect all, click it again. To return to the previous screen, click After communication is complete, dynamic data of the selected data stream will appear on the screen.

  • Page 32: Special Function

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Data Stream: Tap to select the desired data stream to be browsed, and then click “Confirm” to view the waveform. See Fig. 3-21; Start to record: Tap to start recording diagnostic data for future playback and view.

  • Page 33: M Yspace

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis 3.7 My Space There are 2 options available in My data: Diagnostic report and history. 3.7.1 Diagnostic Report This option is used to view the diagnostic report generated in process of vehicle diagnosis.
  • Page 34 LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Fig. 3-24 Button definitions: : To revise the diagnosis report filename; : To delete the selected report; : To send the report via Bluetooth, email or messaging. In Diagnosis playback, click certain file to view it. See Fig. 3-25.
  • Page 35 LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Fig. 3-25 Button definitions: Delete: To delete the current report; Character: To view the diagnostic report in character form. Graph: To view the diagnostic report in waveform form.

  • Page 36: Operation Record

    DBScar connector serial number, operation time and check vehicle brand etc. 3.8 Launch News This option allows you to view the latest information and news from Launch. Tap “Launch News”, the system will display the relevant information title. Tap the desired title to view the details.

  • Page 37: One Key Upgrade

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis 3.10 One Key Upgrade This function allows users to download or upgrade multiple vehicle diagnosis software. Tap “One Key Upgrade” to enter a screen similar to Fig. 3-27. Fig. 3-27 Check the box next to the software that you intend to download (To select all, just click “Select All”), then click the “Next Step”...
  • Page 38 LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis Fig. 3-28 The following options are available: Message: Tap the desired friend to view the details if there are historical messages, otherwise the screen will appear blank. Friends: Displays all friends list. To add a new friend, click...

  • Page 39: User Management

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis 3.12 User Management This function allows you to register connector, change password, set security question and retrieve password etc. 3.12.1 Connector registration Tap “Register Connector” to enter a screen similar to Fig. 3-29. Input Serial Number and Verification Code, and then click “Register”...

  • Page 40: Forget Password

    LAUNCH ScanPad 071 User’s Manual — Vehicle Diagnosis 3.12.5 Forget password Tap “Forgot Password” to enter. Input the correct user name and tap “Next Step”: If you set the security question before, the screen will enter the Answer the security question interface. Key in your answer and tap “Confirm”, the system will feedback your new password.

  • Page 41: Others

    LAUNCH ScanPad 071 User’s Manual — Others 4 Others 4.1 Email The function allows you to send and receive email. You can add POP3 or IMAP email account for some common web email service provider. 4.1.1 Add an email account Note: Before sending or receiving email, you have to set up an email account.

  • Page 42: View Email

    LAUNCH ScanPad 071 User’s Manual — Others 5. Input a title in Subject column. 6. Enter the content in Compose email area. 7. After inputting, tap , you can perform any one of the followings: attach file, add CC/BCC, save draft, discard and setting.

  • Page 43: Wlan

    LAUNCH ScanPad 071 User’s Manual — Others 4.2 WLAN This function enables you to enjoy surfing on the internet and downloading data from the internet via Wi-Fi. 4.2.1 Set Wi-Fi on 1. Enter main menu screen, choose “Settings” > “Wi-Fi”.

  • Page 44: B Rowser

    4.3 Browser 4.3.1 Open browser Enter main menu screen, tap to launch the browser. You can choose the desired homepage or input the website address to browse. 1 Tap to input or edit the web link 2 Web page display area 3 Tap to open bookmarks, view history and saved web pages 4.3.2 Browse a webpage...

  • Page 45: Zoom In / Zoom Out A

    LAUNCH ScanPad 071 User’s Manual — Others 4.3.3 Zoom in / zoom out a page There are two ways to zoom in/ zoom out while browsing a webpage. • To zoom in so that the text on a webpage appears in a column that fits your device’s screen, double-tap with the tip of your finger.

  • Page 46: U Sing B Luetooth

    Enter main menu screen, tap “Settings” > “Bluetooth”. ScanPad 071 starts scanning all Bluetooth devices. Choose the desired one from the search result to pair it with ScanPad 071. 4.4.4 Send file via Bluetooth You can send pictures, video, audio files or test reports to others for sharing and review via Bluetooth.

  • Page 47: Camera

    LAUNCH ScanPad 071 User’s Manual — Others audio file. and choose “Bluetooth” from the pull-down menu. Tap the target Bluetooth device you want to transmit files. 4.5 Camera 4.5.1 Open and close camera • Enter main menu screen, tap • In shoot mode, tap to exit the camera.

  • Page 48: View A Video

    LAUNCH ScanPad 071 User’s Manual — Others 4.5.5 View a video After a video is recorded, it will be displayed in thumbnail at the lower right corner of the screen. Tap it to view in full-screen mode. The following operations can be done: •...

  • Page 49: G Allery

    This option is used to manage pictures and video files. 4.6.1 Open gallery Enter main menu screen, tap “Gallery” to access it. The system searches images and videos in ScanPad 071 and SD card automatically, and categorizes it into corresponding folders. 4.6.2 Browse images Enter main menu screen, tap “Gallery”.

  • Page 50: Music Player Interface

    LAUNCH ScanPad 071 User’s Manual — Others Music files are stored into 4 categories: Artists, Albums, Songs and Playlist. Tap the desired music type. Open music file list. Tap the desired audio files to start playing. Press VOLUME+/- key to increase or decrease the volume.

  • Page 51: Create A New Playlist

    LAUNCH ScanPad 071 User’s Manual — Others , the following settings can be made: party shuffle, add to playlist, use as ringtone, delete, sound effect and search etc. to return to the previous screen. to go back to desktop. 4.7.3 Create a new playlist 1.

  • Page 52: Delete An Alarm

    LAUNCH ScanPad 071 User’s Manual — Others Set the detailed items. After setting, tap “DONE” to confirm. 4.9.2 Delete an alarm Enter main menu screen, tap “Alarms”. Tap the desired alarm. , then tap “OK” in the confirmation dialog box to delete it.

  • Page 53: Auto-Rotate The Screen

    Tick the box “Auto-rotate the screen”. 4.12 Set screen lock This item allows you to protect your ScanPad 071 from unauthorized use by creating a personal screen unlock pattern. Once it is set, ScanPad 071 screen will not be unlocked until you draw the right pattern.

  • Page 54: View The Running Applications

    24-hour format. Tap “Choose date format” to choose the desired date format from the list. 4.16 View and release the memory of SD card and ScanPad 071 To view the available memory of ScanPad 071 and SD: enter main menu screen...

  • Page 55: R Estore S Can P Ad 071 To Factory Settings

    “Settings” > SD card and ScanPad 071 memory. Release ScanPad 071 memory In case your ScanPad 071 encounters low memory, please try to solve it by doing the following: • Move the file and email attachments to SD card.
