Summary of Contents for Bticino AXOLUTE Whice
- Page 1 349320 - 349321 AXOLUTE & Nighter Whice User manual 09/09-01 PC 09/09-01 PC...
-
Page 3: Table Of Contents
AXOLUTE Nighter & Whice Contents 1 Introduction and basic functions 4 House automation functions 1.1 General information 4.1 Scenarios 1.2 Your Video Station: use it now! 4.2 Alarms 1.2.1 Video door entry function keys 4.3 Sound system 1.2.2 Navigation keys 4.4 Temperature control 1.3 Menu functions 4.5 Multimedia menu... - Page 4 Notes...
-
Page 5: Introduction And Basic Functions
AXOLUTE Nighter & Whice Introduction and basic functions General information Your Video Station: use it now! 1.2.1 Video door entry function keys 1.2.2 Navigation keys Menu functions 1.3.1 Volume adjustment 1.3.2 Monitor adjustment 1.3.3 Date/Time adjustment 1.3.4 Camera swing 1.3.5 Cleaning glass 1.3.6 Bells adjustment 1.3.7 Paging... -
Page 6: General Information
Signals the last alarm events which have occurred and the division of the sys- tem. • Sound system: Manages the BTicino digital sound system, acting as an amplifier. • Temperature control: Displays and adjusts the temperature in the various zones of the home and the state of the control unit. -
Page 7: Video Door Entry Function Keys
AXOLUTE Nighter & Whice 1.2.1 Video door entry function keys 1.2.2 Navigation keys Mute Enables/disables the microphone during a sound connection. Activating the Mute during the conversation the connection key Allows access to the menu; confirms the selection made. LED turns red. Activation Entrance Panel/Cycling It activates the switching on of the associated Entrance Panel and, if present, allows the cycling display of the other Entrance... -
Page 8: Menu Functions
1 Introduction and basic functions Menu functions COMMUNICATION Use the key to access the main menu: Main menu example with programming of just the communication commands. 1) Activation 2) Intercommunication 3) Camera 4) Cycle cameras 5) Settings SETTINGS ACTIVATION I Use the keys to select the functions from those available: HOUSE AUTOMATION... - Page 9 AXOLUTE Nighter & Whice CUSTOMISED MENU The customised menu allows more intuitive use of the Video Station functions. The installer has given the exact configuration of your Video Station the tables In fact the menu only displays the functions in your My Home system and the below;...
-
Page 10: Volume Adjustment
1 Introduction and basic functions 1.3.1 Volume adjustment NOTE: During a video door entry call you can access the Adjustments menu directly by pressing the key. Inside the menu select one Select Adjustments of the items (e.g. Bells) Adjust the volume to the Press to access the level required. -
Page 11: Monitor Adjustment
AXOLUTE Nighter & Whice 1.3.2 Monitor adjustment NOTE: During a video door entry call you can access the Adjustments menu directly by pressing the key. Select Adjustments Inside the menu select one of the items (e.g. Contrast) Press to access the menu COLOUR ADJUSTMENTS... -
Page 12: Date/Time Adjustment
1 Introduction and basic functions 1.3.3 Date/Time adjustment Sets the current date and time. Press ; the first two Select Adjustments > TIME 12:05:00 numbers flash DATE 31:07:08 Press to access the Set the hour menu ADJUSTMENTS IMPOSTAZIONI Press to confirm Select Date/Time TIME 12:05:00... -
Page 13: Camera Swing
AXOLUTE Nighter & Whice 1.3.4 Camera swing NOTE: This menu can only be accessed during the connection with the en- trance panel, if this is set up for the camera swing. Select Adjustments Adjust the correct camera angle Press to access the menu ADJUSTMENTS Select Swing... -
Page 14: Cleaning Glass
1 Introduction and basic functions 1.3.5 Cleaning glass The device can be temporarily deactivated for cleaning (all the LED go out). At this point the device surface can be wiped with a cloth without sending any commands to the system. Normal operation is reset after 20 seconds (all the LED light up again). -
Page 15: Bells Adjustment
AXOLUTE Nighter & Whice 1.3.6 Bells adjustment You can associate one of sixteen tunes to each call event. Choose the tune Adjust the volume Select Confirm and then to save the selection and return to the previous TUNE Select Bells page Press to access the... -
Page 16: Paging
1 Introduction and basic functions 1.3.7 Paging If your system is set up, using the icon in the main menu a “paging” call can be sent to the system: • Basic : only sound system • Enhanced : on the speaker* audio handsets as well Select Paging Press to confirm... -
Page 17: Trouble Shooting
AXOLUTE Nighter & Whice Trouble shooting Push to Talk mode... - Page 18 2 Trouble shooting PROBLEM SOLUTION On pressing the Entrance panel Activation/Cycling key ( ) no picture ap- - the audio/video channel may be busy, wait for it to become free (from 1 to 3 pears. minutes) and try again. On pressing the key the menu does not switch on and the handset gives - the audio/video channel is busy, wait for it to become free (from 1 to 3 min- a busy sound...
-
Page 19: Push To Talk Mode
AXOLUTE Nighter & Whice Push to Talk mode Receiving a call from the entrance panel. Press the Connection key to answer the call. The connection LED lights up. During the conversation you can activate the PUSH To TALK function. Press the Connection key for at least 2 seconds to talk to the entrance panel. The LED remains oN. - Page 20 2 Trouble shooting Release the key to hear from the entrance panel. The LED becomes red. To end the connection press the connection key briefly. The LED goes out.
-
Page 21: Cctv Functions
AXOLUTE Nighter & Whice CCTV functions Activation Intercommunication Camera Cycle cameras... - Page 22 3 CCTV functions Activation Intercommunication This function activates an actuator or an entrance panel. As an example you can This function allows conversation with other video handsets/ handsets installed activate the opening of a secondary gate. in your home or in other apartments. Press to access the Press...
- Page 23 AXOLUTE Nighter & Whice Camera Cycle cameras This function lets you monitor your home, activating one of the cameras in the This lets you display the pictures taken by all the cameras installed one after the apartment and in the common areas (e.g. garage or garden). other.
- Page 24 Notes...
-
Page 25: House Automation Functions
AXOLUTE Nighter & Whice House automation functions Scenarios Alarms Sound system Temperature control Multimedia menu... - Page 26 4 House automation functions Scenarios Your Video Station communicates with the BTicino automation system, activat- The installer has given a brief description of the scenarios set in the tables be- ing the scenarios. low, if he has not filled it in ask for it.
-
Page 27: Alarms
AXOLUTE Nighter & Whice Alarms Alarms icons key: Your Video Station communicates with the BTicino burglar-alarm system, in particular giving information on the system state, the active zones and the last 3 alarms given. ARMED ANTIPANIC DISARMED TECHNICAL Inside the Main menu... -
Page 28: Sound System
4 House automation functions Sound system The information in the screen is read as indicated below: If your Video Station is connected to the BTicino sound system you can check 10/06 10:20 Inside the Main menu select Sound system 10/06 20:30... -
Page 29: Temperature Control
AXOLUTE Nighter & Whice Temperature control Your Video Station lets you control and adjust the temperature inside the home, interacting with the BTicino temperature control system. LOCAL AMPLIFIER Inside the Main menu select Temperature control system Press to confirm TEMPERAT. CONTROL... - Page 30 4 House automation functions You can set the temperature on different levels in the various system zones. TEMP. CONTROL UNIT ZONES: 01 20.5 °C 20.5 °C 22.5 (+2) 18.5 °C 1) Press the keys to select Temperature control unit/Zones 1) Press the keys to select Temperature control unit/Zones 2) To set the manual mode and adjust the temperature use the keys...
-
Page 31: Multimedia Menu
AXOLUTE Nighter & Whice Multimedia menu If your system has the Multimedia Interface (item 3465), you can access your menu via the dedicated icon. Inside the Main menu select Multimedia Press to access the menu MULTIMEDIA INTERFACE ✎ To navigate the menu of the multimedia interface use the same keys as its remote control: MY HOME ✎... - Page 32 Notes...
-
Page 33: Services
AXOLUTE Nighter & Whice Services The “Settings” menu Services 5.2.1 Professional studio 5.2.2 Hands free 5.2.3 Door state 5.2.4 Alarm messages Messages... -
Page 34: The "Settings" Menu
5 Services The “Settings” menu The main menu always has the SETTINGS icon. Selecting it gives access to a wide range of customisations which let you get the most from your Video Sta- SETTINGS tion. VOLUME MONITOR ADJUSTMENT DATE/HOUR SWING Inside the Main menu PROF. -
Page 35: Professional Studio
AXOLUTE Nighter & Whice Services 5.2.1 Professional studio 5.2.2 Hands free The Professional Studio function lets you set the automatic opening of the door The Hands Free function automatically activates the microphone and loud- lock when there is a call from the Entrance Panel. It cannot be activated at the speaker when there is a call, avoiding having to press the Connection key to same time as the Door State function. -
Page 36: Door State
5 Services 5.2.3 Door state 5.2.4 Alarm messages This function tells you about the door lock state. If it is open the “door lock LED” If it is activated the Video Station tells you if the antiintrusion system has de- flashes, if it is closed it remains oFF. -
Page 37: Messages
AXOLUTE Nighter & Whice Messages Select Messages Press to confirm MESSAGES - 1 + Select the message you Me ss age f ro m want to display sw it chb oa rd Press to return to the previous page There are messages, the menu can be selected. No messages, the menu cannot be selected. - Page 38 BTicino SpA Via Messina, 38 20154 Milano - Italy www.bticino.com BTicino SpA reserves at any time the right to modify the contents of this booklet and to communicate, in any form and modality, the changes brought to the same.
