- Page 1 User manual 349320 349321...
-
Page 3: Table Of Contents
Contents 1 Introduction and Basic Functions 4 House automation functions General information Scenarios ■ ■ ■ Your Video Station: use it now! ■ Alarms Video door entry function key s Sound system ■ Navigation key s ■ Temperature control ■ Menu functions ■... - Page 4 Notes...
-
Page 5: Introduction And Basic Functions
1 Introduction and basic functions ■ General information ■ Your Video Station: use it now! Video door entry function keys Navigation keys ■ Menu function Volume adjustment Monitor adjustment Date/Time adjustment Camera swing Cleaning glass Bells adjustment Paging... -
Page 6: General Information
Signals the last alarm events which have occurred and the division of the system. • Sound system: Manages the BTicino digital sound system, acting as an amplifi er. • Temperature control: Displays and adjusts the temperature in the various zones of the home and the state of the control unit. -
Page 7: Video Door Entry Function Keys
Introduction and basic functions Video door entry function keys Navigation keys Mute Enables/disables the microphone during a sound connection. Activating the Mute during the conversation Allows access to the menu; confirms the the LED lights up. selection made. Activation Entrance Panel/Cycling It activates the switching on of the associated Entrance Panel and, if present, allows the cycling display of the keys... -
Page 8: Menu Functions
Introduction and basic functions ■ Menu functions COMMUNICATION Main menu example with programming of just the COMMUNICATION Use the key to access the main menu: commands. 1) Communication 2) Intercommunication 3) Camera 4) Cycle cameras 5) Settings SETTINGS ACTIVATION I HOUSE AUTOMATION Use the keys to select the functions from those available:... -
Page 9: Paging
Introduction and basic functions CUSTOMISED MENU The installer has given the exact confi guration of your Video Station The customised menu allows more intuitive use of the Video Station functions. In fact the menu only displays the functions in your My the tables below;... -
Page 10: Volume Adjustment
Introduction and basic functions Volume adjustment NOTE: During a video door entry call you can access the Adjustments menu directly by pressing the key. Inside the menu select Select one of the items Adjustments (e.g. Bells) Adjust the volume to Press to access the level required. -
Page 11: Monitor Adjustment
Introduction and basic functions Monitor adjustment NOTE: During a video door entry call you can access the Adjustments menu directly by pressing the key. Select Adjustments Inside the menu select one of the items (e.g. Contrast) Press to access the menu ADJUSTMENTS COLOUR Select... -
Page 12: Date/Time Adjustment
Introduction and basic functions Date/Time adjustment Sets the current date and time. Press ; the fi rst Select > TIME 12:05:00 two numbers fl ash Adjustments DATE 31:07:08 Press to access the menu the hour ADJUSTMENTS Press to confi rm Select TIME 12:05:00... -
Page 13: Camera Swing
Introduction and basic functions Camera swing NOTE: This menu can only be accessed during the connection with the entrance panel, if this is set up for the camera swing. Select Adjustments Adjust the correct camera angle Press to access the menu ADJUSTMENTS Select Swing... -
Page 14: Cleaning Glass
Introduction and basic functions Cleaning glass The device can be temporarily deactivated for cleaning (all the LED go out). At this point the device surface can be wiped with a cloth without sending any commands to the system. Normal operation is reset after 20 seconds (all the LED light up again). Select Services Press... -
Page 15: Bells Adjustment
Introduction and basic functions Bells adjustment You can associate one of sixteen tunes to each call event. Choose the tune Adjust the volume Select Confirm and then save the selection and return to the TUNE Select previous page Bells Press to access the menu CALL FROM EP = call from the... -
Page 16: Paging
Introduction and basic functions Paging If your system is set up, using the icon in the main menu a “paging” call can be sent to the system: • Basic: only sound system • Enhanced: on the speaker* audio handsets as well Select Paging Press... -
Page 17: Trouble Shooting
2 Trouble shooting Push to Talk mode... - Page 18 Trouble shooting PROBLEM SOLUTION On pressing the Entrance panel Activation/Cycling key ( ) no picture - the audio/video channel may be busy, wait for it to become free appears. (from 1 to 3 minutes) and try again. On pressing the key the menu does not switch on and the - the audio/video channel is busy, wait for it to become free (from 1 to 3 handset gives a busy sound...
-
Page 19: Push To Talk Mode
Trouble shooting Push to Talk mode Receiving a call from the entrance panel. Press the Connection key to answer the call. The connection LED lights up. During the conversation you can activate the PUSH TO TALK function. Press the Connection key for at least 2 seconds to talk to the entrance panel. - Page 20 Trouble shooting Release the key to hear from the entrance panel. The LED becomes red. To end the connection press the connection key briefl y. The LED goes out.
-
Page 21: Cctv Functions
3 CCTV functions ■ Activation ■ Intercommunication ■ Camera ■ Cycle cameras... -
Page 22: Activation
CCTV functions ■ Activation ■ Intercommunication This function activates an actuator or an entrance panel. As an example This function allows conversation with other video handsets/ handsets you can activate the opening of a secondary gate. installed in your home or in other apartments. Press to access Press... -
Page 23: Camera
CCTV functions ■ Camera ■ Cycle cameras This function lets you monitor your home, activating one of the cameras This lets you display the pictures taken by all the cameras installed one in the apartment and in the common areas (e.g. garage or garden). after the other. - Page 24 Notes...
-
Page 25: House Automation Functions
4 House automation functions ■ Scenarios ■ Alarms ■ Sound system ■ Temperature control ■ Multimedia menu... -
Page 26: Scenarios
House automation functions ■ Scenarios Your Video Station communicates with the BTicino automation system, The installer has given a brief description of the scenarios set in the activating the scenarios. tables below, if he has not fi lled it in ask for it. -
Page 27: Alarms
House automation functions ■ Alarms Your Video Station communicates with the BTicino burglar-alarm Alarms icons key: system, in particular giving information on the system state, the active zones and the last 3 alarms given. ARMED ANTIPANIC DISARMED TECHNICAL Inside the Main menu... -
Page 28: Sound System
House automation functions ■ Sound system The information in the screen is read as indicated below: If your Video Station is connected to the BTicino sound system you can check it. 10/06 10:20 Inside the Main menu select Sound system... -
Page 29: Temperature Control
House automation functions ■ Temperature control Your Video Station lets you control and adjust the temperature inside the home, interacting with the BTicino temperature control system. LOCAL AMPLIFIER Inside the Main menu select Temperature control system Press to confi rm... - Page 30 House automation functions You can set the temperature on diff erent levels in the various system zones. TEMP. CONTROL UNIT ZONES: 01 20.5 °C 20.5 °C 22.5 (+2) 18.5 °C 1) Press the keys to select Temperature control unit/Zones 1) Press the keys to select Temperature control unit/Zones 2) To set the manual mode and adjust the temperature use the 2) To set the manual mode and adjust the temperature use the...
-
Page 31: Multimedia Menu
House automation functions ■ Multimedia menu If your system has the Multimedia Interface (item 3465), you can access your menu via the dedicated icon. Inside the Main menu select Multimedia Press to access the menu MULTIMEDIA INTERFACE ✎ To navigate the menu of the multimedia interface use the same keys as its remote control: MY HOME... - Page 32 Notes...
-
Page 33: Services
5 Services ■ The “Settings” menu ■ Services Professional studio Hands free Door state Alarm messages ■ Messages... -
Page 34: The "Settings" Menu
Services ■ The “Settings” menu The main menu always has the SETTINGS icon. Selecting it gives access to a wide range of customisations which let you get the most from your Video Station. SETTINGS VOLUME MONITOR ADJUSTMENT DATE/HOUR SWING Inside the Main menu select Settings PROF. -
Page 35: Services
Services ■ Services Professional studio Hands free The Professional Studio function lets you set the automatic opening of The Hands Free function automatically activates the microphone and the door lock when there is a call from the Entrance Panel. It cannot be loudspeaker when there is a call, avoiding having to press the Connection activated at the same time as the Door State function. -
Page 36: Door State
Services Door state Alarm messages This function tells you about the door lock state. If it is open the “door If it is activated the Video Station tells you if the antiintrusion system has lock LED” fl ashes, if it is closed it remains OFF. detected an alarm. -
Page 37: Messages
Services ■ Messages Select Messages Press to confi rm MESSAGES - 1 + Select the message M e s sa g e f ro m you want to display s w i tc h b o a rd Press to return to the previous page There are messages, the menu can be selected. - Page 38 BTicino SpA Via Messina, 38 20154 Milano - Italy www.BTicino.it...
