Thus the Axolute Video Display: - must only be installed indoors; - must not be exposed to drips or splashes of water; - must only be used on bTicino digital 2-wire video door entry systems. PACKAGE CONTENT The package contains: •...
2 DESCRIPTION MAIN FUNCTIONS The bTicino Axolute Video Display is the evolution of the video handset which can be used in managing the home system. As well as all the 2-wire digital door entry functions, in systems combined with the My home multimedia system, Axolute Video Display can manage the home: from security to well-being to entertainment (display of the alarm state, sound system, temperature setting in single rooms).
Video Display 2 DESCRIPTION FRONT VIEW Colour LCD display; displays the menus which guide the use and programming operation, shows the pictures taken by the entrance panel or other cameras. Loudspeaker Call bell exclusion LED Connection key; activates/deactivates the sound connection Connection LED Switch ON entrance panel and cycling key Door lock LED...
2 DESCRIPTION VIDEO DOOR ENTRY FUNCTION KEYS Activation Entrance Panel/Cycling Activates the switching ON of the associated Entrance Panel and cycles any other Entrance Panels/cameras. Door lock key In connection opens the door lock of the connected Entrance Panel, at rest that of the associated Entrance Panel.
Video Display 2 DESCRIPTION REAR VIEW AXOLUTE Mini-USb connector for connection to the PC Configurator socket Connection to the bticino 2-wire digital system bUS Stretch end ON/OFF microswitch Connector for extra power supply...
3 INSTALLATION INSTALLATION WITH FLUSH-MOUNTED BOX To install the Axolute Video Display use a flush-mounted box item 506E After making all the connections fasten the Axolute Video Display to the flush-mounted box being careful to arrange the wires so that they are not damaged. Finish the installation with the cover plate in the version required.
Video Display 4 QUICK CONFIGURATION QUICK CONFIGURATION BY MEANS OF M CONFIGURATOR Note: If the apartment has the 2-wire apartment interface item 346850 the Axolute Video Display should be configured using Advanced Configuration. The quick configuration is recommended for standard video door entry systems where no special functions are required and short installation times are important.
Page 11
4 QUICK CONFIGURATION Selection of mode M The main menu page will be made up of a set of predefined video door entry functions which can be selected with M = 0–6. M= 0 M= 4 INTERCOMMUNICATING I CAMERA I M= 1 M= 5 CAMERA I...
Video Display 4 QUICK CONFIGURATION INTERCOMMUNICATING: intercommunicating call to the handset with address N same as the number indicated by the icon selected. (e.g.: INTERCOMMUNICATING 4 intercommunicating call address to the handset with N = 4) CAMERA: direct activation of the camera with the same address as the associated Entrance Panel increased by a number equal to that indicated by the icon selected.
5 ADVANCED CONFIGURATION Configuration from PC by means of the TiAxoluteDisplay software in the CD supplied lets you configure the main menu page without being limited to a predefined set of functions. The type, parameters and text of each function can be customised. •...
Video Display 5 ADVANCED CONFIGURATION CUSTOMISATION OF TEXTS The items in the Axolute Video Display menu (e.g. SCENARIO 4 = Night SCEN, COMMUNICATION = Intercom in the home) can be customised. The following are also possible for the following systems: ALARMS •...
5 ADVANCED CONFIGURATION OTHER FUNCTIONALITIES SCENARIOS and COMMUNICATION More than one call for scenarios and communication can be added in the first page. In this way up to 30 scenario or communication functions can be entered: COMMUNICATION SCENARIO I INTERCOMMUNICATING I In the example at the side 12 communication functions and 18 scenarios can be entered.
Video Display 5 ADVANCED CONFIGURATION CONNECTION TO THE PC To transfer the configuration made with the TiAxoluteDisplay software or update the firmware connect to the Axolute Video Display to the PC using USb-miniUSb cable. In order for the communication to occur, the Axolute Video Display must be powered and not physically configured.
6 SETTINGS After configuring the Axolute Video Display, you can view and modify the configuration settings in the SETTINGS menu. CONFIGURATION SETTINGS SETTINGS ADJUSTMENT SERVICES For information about these menus please consult the User Manual in the CD enclosed. MESSAGGES BELLS INFORMATION ! WARNING !
Video Display 6 SETTINGS Access to the Configuration menu Select SETTINGS Press OK to confirm SETTINGS CONFIGURATION MENU Select CONFIGURATION Press OK to confirm CONFIGURATION A WARNING message is displayed ! WARNING ! AREA RESERVED FOR Select QUIT CONFIGURATION OF THE DEVICE! Press OK to quit >...
6 SETTINGS 6.1.1 OPTIONS On selecting OPTIONS access is possible to the following system settings. > OPTIONS Select OPTIONS PARAMETER MODE H CONFIGURATION RESET Press OK to confirm > SLAVE <NO> Select (e.g.: SLAVE) PAGING <NO> DEFAULT Select <NO>/<YES> SLAVE – the Video Display configured <YES> allows the installation of several Video Displays configured with the same N address (max.
Video Display 6 SETTINGS 6.1.2 HANDSET CONFIGURATION On selecting h CONFIGURATION the address (N) of the Axolute Video Display and/or the associated Entrance Panel (P) can be edited. OPTIONS Select H CONFIGURATION PARAMETER MODE > H CONFIGURATION RESET Press OK to confirm Select ADDRESS (N) and/or (P) H CONFIGURATION >...
6 SETTINGS 6.1.3 RESET Selecting RESET cancels all the data and returns the Axolute Video Display to the factory settings. OPTIONS Select RESET PARAMETER MODE H CONFIGURATION > RESET Press OK to confirm The following message is displayed CANCEL THE CONFIGURATION OF THE Press OK to quit the menu DEVICE ?
Video Display 7 TROUBLE SHOOTING 9 MEMO CARD PROBLEM SOLUTION - check that the handset and entrance panel have been correctly wired and configured (must have On pressing the Entrance panel Activation/Cycling the same P address); ( ) key no picture appears - the audio/video channel may be busy, wait for it to become free and try again.
7 TROUBLE SHOOTING PUSH TO TALK MODE Receiving a call from the entrance panel. Press the Connection key to answer the call. The lED is ON. During the conversation you can activate the PUSh TO TAlK function. Press the Connection key for at least 2 seconds to talk to the entrance panel.
Video Display 8 APPENDIX TECHNICAL DATA from SCS bus: 18 - 28 V Power supply from 1 2 : 18 - 28 V 200 mA (in A/V connection) Absorption (Max) 8 mA (in stand-by) Operating temperature 0 - 40 °C...
