UK

Description

To avoid the risk of glass breakage which may result in minor or moderate injury:
- Handle the monitor with care to avoid breaking the screen. The display contains glass parts to break.
- Do not place foreign objects on the monitor.
391420
32"
81 cm
769,8 mm
Accessories
- AC Wire
- VGA cable
- Audio cable
- HDMI cable
- User manual
Warning
- The installation and calibration must be carried out by highly skilled
personnel.
- Do not open there may be a risk of electric shock.
Use only for the following temperature conditions: from (-10) to (+55) °C.
Do not use with voltages different from the ones specified.
391422
529,8 mm
277 mm
This product should be installed in line with installation rules, preferably by a qualified electrician.
Incorrect installation and use can lead to risk of electric shock or fire.
Before carrying out the installation, read the instructions and take account of the product's specific
mounting location.
Do not open up, dismantle, alter or modify the device except where specifically required to do so by
the instructions. All Bticino products must be opened and repaired exclusively by personnel trained
and approved by Bticino. Any unauthorised opening or repair completely cancels all liabilities and
the rights to replacement and guarantees.
Use only Bticino brand accessories.
Safety instructions
391420
391422

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 391420 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bticino 391420

  • Page 1 Do not open up, dismantle, alter or modify the device except where specifically required to do so by - Do not open there may be a risk of electric shock. the instructions. All Bticino products must be opened and repaired exclusively by personnel trained Use only for the following temperature conditions: from (-10) to (+55) °C.
  • Page 2 Explanation of connectors This section describes the jacks on the back panel of your MONITOR. There are several ways to connect devices. Audio HDMI INPUT Lets you connect a device, with an HDMI or DVI output. Video 02 Video 01 Audio HDMI S-Video...
  • Page 3 1. To ensure a normal operation, the remote control should not be dropped or damaged in any way. It should also be kept dry and away from all heat sources. 2. Battery replacement is necessary when the remote controller acts inconsistently or stops operating the LCD display. Choose the input source If you hope to enjoy the picture from the external input source, before to select the source ,you need to connect the devices,otherwise,when you select the source ,the none or no signal will appears on the screen, Press source(input) button on the monitor or remote control,the menu appears on the screen ,then press source to select the monitor item,...
  • Page 4 Also, never place drinks or vases with water on top of the monitor. This could increase the risk of fire or shock hazard or damage to the monitor. Mounting Your MONITOR to the Wall : The monitor can be wall-mounted (VESA bracket not included). Specification Model 391420 391422 Size 32” 42”...
