Open the file and perform the following operations, as shown in Figure 4:
If there are more than one network interface, to solve connection problems follow the procedure
below:
If the Switchboard is used in a multi-server environment (for further details, see "Menu Settings –
Multi-server configuration" on page 60), configure the PC Ethernet interface used to connect to
IPervoice network with a static IP address, selected for example in an interval from 192.168.1.2 to
192.168.1.253 (for ex. 192.168.1.100), set the "Subnet mask" to 255.255.0.0; do not set the "Pre-
defined gateway" as shown in Figure 3.
If the switchboard is used in a single-server environment, it is also possible to automatically configure
the PC Ethernet interface (DHCP). In this case, set the MAC_ADDRESS parameter in the configuration
file, as shown below.
Configured other PC network interfaces as needed (for ex. in DHCP mode), avoiding configuration
conflicts among interfaces.
Open the file and perform the following operations, as shown in Figure 4:
Find the section [SETTINGS] and change or add the following rows:
SIP_SERVER=192.168.1.1
DEFAULT_GATEWAY=192.168.1.1
PHP_SERVER_HOSTNAME=192.168.1.1
ADAPTER_IP:= <IP address of the interface used by Switchboard application
DS1039-035A
Figure 3: Setting of network interface connected to IPervoice
7
>
