IPerCom Hardware installation guide
www.urmet.co.uk
technical@urmet.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPerCom and is the answer not in the manual?

Questions and answers

Related Manuals for urmet domus IPerCom

Summary of Contents for urmet domus IPerCom

  • Page 1 IPerCom Hardware installation guide www.urmet.co.uk technical@urmet.co.uk...

  • Page 3: Table Of Contents

    Contents IPerCom system schematic Page 1 IPerCom combined with iPassan access control system schematic Page 2 Network installation and configuration requirements Page 3 & 4 1717/31 or 1717/33 Max Pro Touchscreen Monitor Controls Page 5 Connections Page 6 & 7...
  • Page 4 1060/74 Sinthesi Steel Entry Panel Connections overview Page 23 Maglock connection example Page 24 Fail safe and fail secure release connection examples Page 25 Interface to iPassan and third party access control systems Page 26 Mounting height Page 27 1060/82 Proximity Key Reader Connections overview Page 28 Maglock connection example...

  • Page 5: Ipercom System Schematic

    IPerCom schematic 2-Core cable This schematic shows the IPerCom Doorbell push button video entry system with integrated 2-Core cable Panic alarm input IPerCom proximity access control 2-Core cable Extension sounder 1717/31 1717/33 1717/41 1717/43 Cat5e Lock power supply 2-Core cable...
  • Page 6 1717/31 1717/33 1717/41 Network installation and configuration requirements 1717/43 This schematic shows the IPerCom The installation should be installed, tested and documented as per the following standards – Cat5e video entry system with iPassan proximity access control European Committee for Electrotechnical Standardisation (CENELEC) EN 50173 Information Technology –...

  • Page 7: Network Installation And Configuration Requirements

    Network installation and configuration requirements The installation should be installed, tested and documented as per the following standards – European Committee for Electrotechnical Standardisation (CENELEC) EN 50173 Information Technology – Generic Cabling Systems EN 50173-1:2011 General requirements EN 50173-2:2007 + A1:2010 Office Premises EN 50173-3:2007 + A1:2010 Industrial Premises...
  • Page 8 Specific network requirements for IPerCom are as follows – IGMPv2 or IGMPv3 Multicast Service must be enabled. The following ports must be open and not restricted – TCP ports 2049, 51234, 5060, 50118, 3306, 13451 to 3460, 111, 80, 433, 41365, 22, 918 &...

  • Page 9: 1717/31 Or 1717/33 Max Pro Touchscreen Monitor

    Micro SD card slot 2MP webcam Switch NOT USED Microphone 12-Way connector for external connections 1717/31 or 1717/33 Max Pro Touchscreen Monitor connections Blue backlit Home button Secondary LAN connection for Home Area Network Speakers LAN connection to IPerCom network...
  • Page 10 IPerCom ‘door entry network’ and one for connection to the the IPerCom ‘door entry network’ and one for connection to the the IPerCom ‘door entry network’ and one for connection to the local apartment network (Home Area local apartment network (Home Area...

  • Page 11: Connections

    An additional terminal connector is supplied to allow a number of external connections to the Max An additional terminal connector is supplied to allow a number of external connections to the Max An additional terminal connector is supplied to allow a number of external connections to the Max An additional terminal connector is supplied to allow a number of external connections to the Max An additional terminal connector is supplied to allow a number of external connections to the Max An additional terminal connector is supplied to allow a number of external connections to the Max...
  • Page 12 1717/31 or 1717/33 Max Pro Touchscreen Monitor mounting height...

  • Page 13: 1717/41 Or 1717/43 Max Lite Touchscreen Monitor

    1717/41 or 1717/43 Max Lite Touchscreen Monitor 7” Touchscreen Switch NOT USED Microphone 12-Way connector for external connections Speakers LAN connection to IPerCom network Blue backlit Home button Micro SD card slot...
  • Page 14 LAN connector LAN connector for connection to the for connection to the for connection to the for connection to the IPerCom ‘door entry network’. IPerCom ‘door entry network’. IPerCom ‘door entry network’. IPerCom ‘door entry network’. IPerCom ‘door entry network’.
  • Page 15 An additional An additional An additional cable cable is supplied to allow a number of external connections to the Max touchscreen, is supplied to allow a number of external connections to the Max touchscreen, is supplied to allow a number of external connections to the Max touchscreen, is supplied to allow a number of external connections to the Max touchscreen, is supplied to allow a number of external connections to the Max touchscreen, is supplied to allow a number of external connections to the Max touchscreen,...
  • Page 16 1717/41 or 1717/43 Max Lite Touchscreen Monitor mounting height...
  • Page 17 Button for Yokis control Door open button 1160/3 Miro handsfree audio station connections Button for Yokis control LAN connection to IPerCom network The 1160/3 Miro handsfree audio station has one LAN connector for connection to the IPerCom 12-Way connector for external connections...
  • Page 18 1 1 160/3 Miro handsfree audio station Miro handsfree audio station Miro handsfree audio station Miro handsfree audio station Miro handsfree audio station connections connections DOORPHONE DOORPHONE POE PORT POE PORT Door entry system network Door entry system network Door entry system network Maximum PoE power Maximum PoE power Maximum PoE power...
  • Page 19 An additional cable is supplied to allow a number of external connections An additional cable is supplied to allow a number of external connections An additional cable is supplied to allow a number of external connections An additional cable is supplied to allow a number of external connections An additional cable is supplied to allow a number of external connections An additional cable is supplied to allow a number of external connections An additional cable is supplied to allow a number of external connections...
  • Page 20 1160/3 Miro handsfree audio station mounting height 1160/3 Miro handsfree audio station 1550mm Finished Floor Level...

  • Page 21: Connections

    1060/13 Elekta, 1060/18 & 1060/19 Elekta Steel Call Modules Connections for 1060/13 Elekta and 1060/18 & 1060/19 Elekta Steel entry panels are identical - NC NO SE+ SE- LAN – Network connection to PoE network switch port AD - Input for hearing aid induction loop SE2 - Normally open voltage free relay output specifically for triggering vehicle automation systems.
  • Page 22 Typical connections for a maglock Typical connections for a maglock Typical connections for a maglock Typical connections for a maglock Typical connections for a maglock Typical connections for a maglock – Lock power power supply SE+ SE- V V NC NO NC NO SE+ SE Fit a varistor a varistor as close as possible to the...
  • Page 23 Typical connections for fail safe (fail open) electric release - Typical connections for fail safe (fail open) electric release Typical connections for fail safe (fail open) electric release Typical connections for fail safe (fail open) electric release Typical connections for fail safe (fail open) electric release Typical connections for fail safe (fail open) electric release Typical connections for fail safe (fail open) electric release Typical connections for fail safe (fail open) electric release...
  • Page 24 Interfacing IPerCom lock output to iPassan access control system Interfacing IPerCom lock output to iPassan access control system Interfacing IPerCom lock output to iPassan access control system Interfacing IPerCom lock output to iPassan access control system - SE+ SE- V V NC NO...
  • Page 25 1060/1 1060/18 & 1060/19 8 & 1060/19 8 & 1060/19 mounting height mounting height mounting height BS8300 6.6 for access control systems refers to the activation pad height of BS8300 6.6 for access control systems refers to the activation pad height of BS8300 6.6 for access control systems refers to the activation pad height of BS8300 6.6 for access control systems refers to the activation pad height of BS8300 6.6 for access control systems refers to the activation pad height of...

  • Page 26: 1060/13Mounting Height

    1060/13 mounting height 1060/13 mounting height 1060/13 mounting height 1060/13 mounting height BS8300 6.6 for access control systems refers to the BS8300 6.6 for access control systems refers to the BS8300 6.6 for access control systems refers to the BS8300 6.6 for access control systems refers to the BS8300 6.6 for access control systems refers to the BS8300 6.6 for access control systems refers to the activation pad height of activation pad height of...
  • Page 27 1060/74 Sinthesi Steel entry panel module AD/ILA TLC-EXT IC2 DIGITAL CONNECTOR LAN – Network connection to PoE network switch port SE+ SE- Output for direct connection to a fail secure (fail locked) release. SE2 - C NC NO - Voltage free relay output specifically for triggering vehicle automation systems. This output is triggered by a dedicated button on the Max monitor - V+ V- Input for a local power supply, for use when PoE is not available.
  • Page 28 Typical connections for a maglock Typical connections for a maglock Typical connections for a maglock Typical connections for a maglock Typical connections for a maglock Typical connections for a maglock – Lock Pt No power 788/100 supply The 788/100 is a miniature The 788/100 is a miniature The 788/100 is a miniature The 788/100 is a miniature...
  • Page 29 Typical connections for fail safe (fail open) electric release - Lock Pt No 788/100 power supply The 788/100 is a miniature relay designed to fit inside the 1060/74 back box AD/ILA Varistor Typical connections for fail secure (fail locked) electric release - AD/ILA Varistor...
  • Page 30 Interfacing IPerCom lock output to iPassan access control system Interfacing IPerCom lock output to iPassan access control system Interfacing IPerCom lock output to iPassan access control system Interfacing IPerCom lock output to iPassan access control system – 1104/921 iPassan controller or 1104/921 iPassan controller or...

  • Page 31: Mounting Height

    1060/74 mounting height 1060/74 mounting height 1060/74 mounting height 1060/74 mounting height Wheelchair Housing Design Guide (WHDG) refers to a height of Wheelchair Housing Design Guide (WHDG) refers to a height of Wheelchair Housing Design Guide (WHDG) refers to a height of Wheelchair Housing Design Guide (WHDG) refers to a height of Wheelchair Housing Design Guide (WHDG) refers to a height of Wheelchair Housing Design Guide (WHDG) refers to a height of...

  • Page 32: 1060/82 Proximity Key Reader

    1060/82 proximity key reader module NO NC SP PA NO NC C – Voltage free clean contact lock release output rated at 30V @ 3.5A V+ V- Input for a local power supply, for use when PoE is not available. 44 – 57V DC @ 200mA LAN –...
  • Page 33 Typical connections for a maglock – Maglock Lock power supply Varistor N.C. EMERGENCY DOOR RELEASE N.O. N.C. PRESS TO EXIT N.O. NO NC SP PA...
  • Page 34 Typical connections for fail safe (fail open) electric release - Lock power supply Varistor NO NC SP PA Typical connections for fail secure (fail locked) electric release - Lock power supply Varistor NO NC SP PA...

  • Page 35: Mounting Height

    1060/82 mounting height 1060/82 mounting height 1060/82 mounting height 1060/82 mounting height BS8300 6.6 BS8300 6.6 for access control systems refers to the activation pad height of for access control systems refers to the activation pad height of for access control systems refers to the activation pad height of for access control systems refers to the activation pad height of for access control systems refers to the activation pad height of for access control systems refers to the activation pad height of...

  • Page 36: 1060/84 Relay Module

    1060/84 Relay Module V+ V- PB1 – External normally open clean contact input 1 PB2 – External normally open clean contact input 2 OUT1 – NO NC C - Voltage free clean contact relay output rated at 30V DC @ 5.0A or 250V AC @ 5.0A OUT2 –...
  • Page 37 1060/41 Concierge Handset Plug the loudspeaker connector (green connector) into the PC loudspeaker output Plug the microphone connector (pink connector) into the PC microphone output Plug the USB connector into a spare USB port on the PC Internal connection – S+ S- Connection for 1072/59 External Sounder It is not necessary to install driver software for the 1060/41 Switchboard Handset.

  • Page 38: Notes

    Notes …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………………………………………………… ……………………………………………………………………………………………………………………………………………………………...
  • Page 40 URMET COMMUNICATION AND SECURITY UK LTD Urban Hive, Skyline 120, Avenue West, Great Notley, Essex. CM77 7AA Tel 01376 556010 Fax 01376 567864 www.urmet.co.uk technical@urmet.co.uk...
