Page 1 IPERVOICE SYSTEM INSTALLATION MANUAL...
Page 2: Table Of Contents
IPERVOICE SYSTEM SUMMARY MT124-025D Version 4.10 IPerVoice in brief ......................... 8 Digital audio/video transmission ....................10 General Characteristics ......................12 System Architecture ........................14 The External Level: the IP network ......................15 4.1.1 The External Level IP devices ........................16 The Internal Level: the IP riser columns ....................
Page 3 Video Signal Adjustment .......................... 83 Apartment Stations Configuration ......................84 7.6.1 Dip Switch Configuration ..........................84 7.6.2 Button Function Assignment ........................86 IPervoice Configuration ......................88 General Information ..........................88 The Frontend ............................89 8.2.1 FrontEnd in Multi-Server Mode ........................91 8.2.2 The main menu ............................
Page 4 8.3.9 Special Decoder Configuration ......................... 117 8.3.10 VoIP Telephone Configuration ......................... 118 8.3.11 End of Configuration with StartUp Wizard ....................126 IPervoice Devices advanced Configuration ................127 IP/CAT5 Gateway ............................ 127 IP Call Module ............................128 9.2.1 Block Group .............................. 129 9.2.2...
Page 5 9.7.1 Aggiunta di una nuova porta ........................151 Special Decoder ............................154 VoIP Telephone ............................157 9.10 Stairs Preset Commands ......................... 160 9.10.1 Default Path Images ..........................160 9.10.2 Call Buttons .............................. 161 9.10.3 Special Functions ............................163 Column Devices Configuration ..................165 10.1 Column Devices Programming .......................
Page 6 13.3 Checking server and IP devices firmware version .................. 265 13.4 IPervoice Server Upgrade ........................267 13.4.1 IP devices automatic upgrade ........................270 13.4.2 IPervoice servers upgrade in Multi-Server mode ..................271 13.5 IPervoice devices replacement ....................... 272 13.5.1 IP devices replacement ..........................272...
Page 7 13.11.6 Search by Door Code ..........................292 13.11.7 Search by Key Code (Badge code) ......................292 13.11.8 Search in Multi-Server Mode ........................293 Stand Alone-FrontEnd Usage (IPervoice sa-fe) ..............295 14.1 Hardware and Software Requirements ....................296 14.2 Pre-Installation Checks / Updates ......................297 14.3 IPervoice sa-fe Installation ........................
Page 8: Ipervoice In Brief
The IP network used by IPervoice must be private and isolated from other IP networks present in the building, in order not to compromise the features and the proper operation of the system.
Page 9 IPervoice is a system based on an “open” communication standard. The use of the SIP protocol (Session Initiation Protocol) allows the connection of third party devices that use the same standard. However, to ensure the system correct operation, it is advisable to use only URMET certified devices.
Page 10: Digital Audio/Video Transmission
IPervoice, transmitted on the IP communication channel. In encoding/decoding phase, the codecs also perform the compression (and/or decompression) of the data, reducing the data volume, in order to make the stream of encoded data easier to be transmitted.
Page 11 (high resolution of images, number of frames per second), keeping the amount of data needed in order to send the information on the network very low. IPervoice uses two different standard codecs; the first one is specific for video information, the second is for audio data: H.264:...
Page 12: General Characteristics
PoE (Power Over Ethernet). Also for this reason the installation is simpler and more economical. • The possibility of using optical fibre to cover long distances means that IPervoice does not have distance limits between the IP network devices.
Page 13 • 16 video door phone apartment stations for each apartment. The IP network used by IPervoice must be private and isolated from other IP networks present in the building, in order not to compromise the features and the proper operation of the system.
Page 14: System Architecture
YSTEM RCHITECTURE Observing the architecture of the IPervoice network, it can be noted that the system is structured on two levels: • The “external” level, used to create the framework of the system. The network used for communication between devices is fully IP-compatible.
Page 15: The External Level: The Ip Network
EVEL NETWORK The framework of IPervoice is made by the IP network, used to connect all the digital devices of the system. On the “external” level of IPervoice devices that perform operations concerning the building structure instead of the single building are usually present. For the laying of the network, a cable available on the market can be used, provided that it is CAT5 certified.
Page 16: The External Level Ip Devices
EVEL DEVICES On the External Level IP network of IPervoice there are many devices that have different characteristics and features. Some of them are optional and depend on the required features, some are fundamental for the correct operation of the whole system. One of them, for example, is the system server 1039/1 that coordinates and manages many services provided by IPervoice.
Page 17 ELEKTA IP Call Module 1039/13 The call module 1039/13 is characterized by a special front panel made of smoked glass. All the buttons are “soft-touch” and there are no movable mechanical elements. It can independently manage two different outputs, the first one used to open a pedestrian door (both with capacitive discharge and with relay contacts), the second to control for example an automatic gate or barrier.
Page 18 Provided with a front panel made of vandal-proof stainless steel, the call module 1039/18 is specifically designed for IPervoice. It can independently manage two different outputs, the first one used to open a pedestrian door (both with capacitive discharge and with relay contacts), the second to control for example an automatic gate or barrier.
Page 19 IP video 2-button door unit 1039/72 The video door unit 1039/72 is dedicated to the IPervoice system and is designed on two-module Sinthesi style. It is equipped with a CCD colour camera and two configurable call buttons. If needed, the number of call buttons can be increased by means of the expansion module 1038/17.
Page 20 Protection degree: IP42 PC Concierge switchboard 1039/41 IPervoice system implements the concierge switchboard function using a Personal Computer and a specific software application. The PC must be equipped with an audio card, in order to perform audio communications with the call modules, VoIP telephones and terminals inside the apartments.
Page 21 Installation: table-top and wall mounting VoIP ATA Interface 4501/30 The VoIP ATA interface allows to connect to IPervoice IP network a traditional analog telephone, making it a IP, SIP based telephone for Voice over IP (VoIP) applications. The interface 4501/30 is also equipped with a PSTN port that can be used to connect it to a traditional telephone line.
Page 22 All the services provided by the IPervoice system are managed and controlled by the server. The connection to the IP network, that is the main facility of IPervoice, is made by means of an Ethernet port embedded in the server. There...
Page 23 The switch provides a total of 32W on the 4 PoE ports, that • 4 x 10-100 Mbit/s PoE Ethernet ports able to powers all the IPervoice system devices designed for PoE provide 15,4 W each port, but no more than standard.
Page 24 Ethernet and in 10Mbps Ethernet. The ports from 1 to 4 use the PoE standard and automatically detect the presence of PoE compatible devices. The switch provides a total of 15,4W for each PoE port, that can power all the IPervoice system devices designed for PoE Main technical characteristics standard. Switch •...
Page 25: The Internal Level: The Ip Riser Columns
EVEL RISER COLUMNS IPervoice has been designed as IP based digital video door phone system, so, besides the system part that forms the “External level”, also the building riser structure can follow the same principle. This is not the only option; as described below, the “Internal level” can be realized with the dedicated IPervoice CAT5 bus.
Page 26 In the second case, the figure shows a minimal solution, that can be used when the number of apartments is limited. In this way, the number of devices is lower, allowing to reduce system costs and consumption. Figure 5: The internal level – building IP riser – reduced solution...
Page 27 Ethernet and in 10Mbps Ethernet. The ports from 1 to 4 use the PoE standard and automatically detect the presence of PoE compatible devices. The switch provides a total of 15,4W for each PoE port, that can power all the IPervoice system devices designed for PoE Main technical characteristics standard. Switch •...
Page 28: The Internal Level: The Dedicated Cat5 Riser Columns
Also in this case, Urmet provides a specific cable, with a blue sheath (1069/91), suitable for laying it in ducts with 230V cables inside. The flexibility of IPervoice is unlimited regarding the number of riser columns in a system, so it is possible to make installations with a large number of users. On the riser column a second audio channel can be present by adding a twisted pair cable (e.g.
Page 29 Figure 7: The internal level – distribution on multiple CAT5 risers With the riser distributor 1039/54, it is possible to install more than one riser column for the apartments. The 103954 can provide a maximum of four riser columns making installation in larger building more flexible. Warning: the riser distributor allows the wiring of several riser columns instead of a single riser.
Page 30 Column power supply unit for CAT5 1039/20 The power supply unit 1039/20 is used to power the devices of the riser column and the apartment devices. The power supply is directly injected on the communication BUS. Warning: to extend the CAT5 BUS up to the maximum distance of 900 metres, a power supply unit Main technical characteristics must be installed every 100 metres.
Page 31 4-user decoder for CAT5 1039/34 The decoder 1039/34 allows the connection of up to 4 apartments max., where 4 apartment stations max. or up to 16 intercom apartment stations can be daisy-chain connected, using the intercom interface 1039/36. The decoder provides a floor call function for each apartment, an auxiliary alarm signal –...
Page 32: The Internal Level: The Ip Apartments
EVEL APARTMENTS Figure 8 shows the wiring inside the apartments connected to IPervoice IP network. From the IP switch, that must be provided with PoE Ethernet ports (e.g. the 1039/45), it is possible to reach apartments (up to 4, in this case). Now it is possible to connect the iModo device (1717/2) as advanced apartment terminal, used to access all IPervoice basic and advanced functions.
Page 33 Figure 9 shows some typical features of iModo terminal. Figure 9: iModo Terminal – main features Note: Besides iModo terminal, in a short time other IP terminals will be available: they will complete the line dedicated to IP apartments and allow to extend and integrate IP system features.
Page 34 IPervoice system. With additional LAN or WiFi connections it is possible to Main technical characteristics connect to the apartment local network;...
Page 35: The Internal Level: The Distribution In Traditional Apartments
THE DISTRIBUTION IN TRADITIONAL APARTMENTS If the traditional CAT5 dedicated solution has been chosen, IPervoice offers two options for installing devices inside an apartment. In the first case, as shown in the upper area of Figure 10 each device is connected in series to the next one, starting from the 4-user decoder.
Page 36 AIKO hands-free video door phone 1716/3 (black) 1716/4 (white) The video door phone 1716/3 (or /4) is equipped with a 4.3” LCD. The user interface is simple and user-friendly. Soft-touch capacitance button are used for access. The device implements various other functions in addition to traditional video door phone features.
Page 37 7” display. The GUI is user-friendly and can be directly accessed from the touch-screen display. In addition to the traditional video door phone functions, other features offered by the IPervoice system are available; among these the most relevant ones are the following: •...
Page 38 Door phone for CAT5 1139/2 The door phone for CAT5 1139/2 is dedicated exclusively for use in the analogue columns of the IPervoice system. It is provided with a door lock release button and 3 buttons for optional functions. It has the same extra-slim style as SIGNO series Main technical characteristics •...
Page 39 This device allows the alarm signals generated by the alarm control panel 1061 to be sent to the concierge switchboard of IPervoice system. Warning: The interface works only if used with the control panel 1061/4 or 1061/6 and not with other intruder alarm systems.
Page 40: Multi-Server Architecture
ULTI ERVER RCHITECTURE In large systems where high reliability is required, a special solution can be implemented. This solution is called Multi-Server Architecture. The block diagram of Figure 11 shows a possible deployment. Figure 11: Multi-Server architecture – Block diagram...
Page 41 ERVER ODE CHARACTERISTICS Several buildings in the same residential area, can compose a global IPervoice system. This one thus can reach considerable dimension; such big residential areas, comprising several Buildings, must sometimes be managed in a centralized mode, keeping every group of Buildings controlled by its own server independent, in order to ensure a high reliability level of the whole system.
Page 42: Switchboard Installation
IP network. There are two valid solutions: 1) Inside the IP network of a single IPervoice system (in the example, the switchboard #1 and #3) 2) To the infrastructure network level (the switchboard #2) In case of malfunction or maintenance of the network infrastructure level, the first solution allows the operation of a switchboard, only for the system where the switchboard is connected.
Page 43 Building Block 1 Building Block 2 Server IP: 10.1.1.1 Server IP: 10.1.2.1 Net Mask: 255.255.0.0 Net Mask: 255.255.0.0 DCHP Range: 10.1.1.2 -10.1.1.254 DCHP Range: 10.1.2.2 -10.1.2.254 Building Block 3 Building Block 4 Server IP: 10.1.3.1 Server IP: 10.1.4.1 Net Mask: 255.255.0.0 Net Mask: 255.255.0.0...
Page 44: Ipervoice Services
ERVOICE ERVICES IPervoice features are provided as services. Each service has its specific function, but at the same time it also interacts, if necessary, with the other services active in the system; for example, the CCTV service manages the cameras and interacts with the Video door phone service during user activity.
Page 45 Figure 12: Video door phone service – Basic diagram Alternative options are possible: a configuration in which the system is fully implemented on the IP network and the apartment stations are VoIP telephones (4501/5) (Figure 13), or another configuration, where there are no apartment stations, but only concierge switchboards 1039/41 and, if necessary, door units based on the module 1039/72 (Figure 14).
Page 46: Services Functions
To “call” an apartment, a concierge switchboard, a VoIP telephone or simply a system user, these devices must be uniquely identified; this identifier is named “call code”. IPervoice provides the installer with two modes for assigning the call codes. The first one is based on the system topologic diagram, and it is also the system internal logic;...
Page 47 In the model based on the topologic code, the eight digits are divided into 4 pairs; each pair is used to identify a hierarchical portion of the system, as shown in Figure 15. In the example, the first pair identifies the building or block (B1), the second the stair (S2), the third the floor (F4) and the fourth and last the apartment (A1).
Page 48 Source Audio/video call Audio call Main Call Module Addition of a “beep-beep” at the end of the ring tone sequence Selected door phone ring tone for 3 consecutive seconds Secondary Call Addition of a “beep-beep” at the end of Module the ring tone sequence 0,4 sec ON 0,2 sec OFF repeated for 5 times...
Page 49 ALL PRIORITY ALL PICKUP TIME AND UARANTEED CONVERSATION TIME IPervoice system manages 7 call priority levels, as shown in Table 3. A higher number means that the call is more important and has higher priority. Priority Type of communication with the apartment station Switchboard during “Room monitor”...
Page 50 UDIO CHANNEL MANAGEMENT ON THE RISER COLUMN HOICE METHODS IPervoice allows a second audio channel to be wired on each riser column. This optional function is useful in order to increase the number of simultaneous communications in the same riser column (Figure 6 at page 28), in particular when a video door phone call and an apartment station call for the switchboard occur at the same time.
Page 51 In any case, the use of the second audio channel, if present, or the closing of a communication on the main channel in case of a new incoming call, is managed by the system using a series of choice methods. There are two application diagrams: the first is used if the incoming call is a video door phone call (audio and video), the second if the call is a door phone call (audio only).
Page 52 ANAGEMENT OF CALL MODULE LOCKS AND DOOR LOCK RELEASE CODES The call modules 1039/13 and 1039/18 have two separate lock outputs. The first output can be used to directly activate a fail locked type electric release. The second output is via a relay contact and can be used to control for example an automatic gate or barrier.
Page 53 ALL FORWARDING Video door phone calls from a call module to an apartment station, can be forwarded to a mobile device, such as a smartphone or tablet. The IPerVoice system must be permanently connected to the Internet via a broadband to use this function.
Page 54: The Switchboard Service
WITCHBOARD ERVICE In the IPervoice system, the service that makes it possible to manage the Concierge Switchboard is performed by a software application called “Switchboard”, developed for Windows Vista and Windows operating systems (Figure 16).
Page 55 Figure 16: "Switchboard" application IPervoice is unlimited regarding the number of switchboards that can be present in the system, so, if required by operative requirements, the concierge service can be distributed to more units, according to competence areas. The personal computer minimum requirements are described in the product list at page 20; for the configuration of the optional devices, two solutions are available.
Page 56 Figure 17: Concierge switchboard – use of USB door phone Figure 18: Concierge switchboard – use of handset (headset + microphone)
Page 57: Service Functions
If the call comes from an apartment station, a call button must be configured to associate it to the selected switchboard This operation is performed by the installer via the configuration web frontend, present on the IPervoice server...
Page 58 ALLS FROM THE SWITCHBOARD The switchboard can call any other system user, a resident, a VoIP telephone or also another switchboard. The call is performed by entering the code or using the address directory, that can be read by the switchboard software. By using the “auto-on” function, the switchboard can at any time establish an audio/video communication with a call module.
Page 59 intercepted by the switchboard. The attendant can speak with the visitor and transfer the communication to the user or act as an intermediary, speaking with the user and the visitor. In NIGHT mode, the switchboard does not perform the concierge service for main call stations, that will directly send the call to the desired apartment station .
Page 60: Panic Service (Panic Alarm)
ANIC LARM The Panic Service present in IPervoice system allows to send a rescue request from apartment stations to their competence area switchboards. This alarm has no effects on audio/video communications active in the column from which it comes; the alarm sent to the switchboard is stored in the system log, in order to allow the attendant to manage it according to the system configuration.
Page 61: Room Monitor Service
In the apartment there is at least one “hands-free” station, as for example the model 1707/1. The room monitor has been enabled on the apartment station by IPervoice FrontEnd. The hands-free apartment station, enabled for "room-monitor" feature, must be configured as "Master"...
Page 62: Local Activations Service
CTIVATIONS ERVICE This service allows to activate relay outputs according to events that can occur in IPervoice system. The devices with usable relays are the “special decoder” modules 1039/80, that have two independent relay outputs, also associated to two inputs which allow the local control of outputs. Modules 1039/80 are directly connected to the IP network and so can be installed in any place of the residential building.
Page 63: The Cctv Service
CCTV S ERVICE Through the CCTV service, the users can display on their video door phones the images captured by the system cameras. The cameras can be the call module cameras or those connected via the IP servers. The displaying is performed in cyclic mode: by pressing the “auto-on” button on the apartment station, the user can see the images coming from the first camera, then the second one and so on.
Page 64 The association among cameras and users or groups of users is configured by the installer with the configuration web frontend present on the IPervoice server. By pressing the button on his apartment station, the user will request the system to select the next camera present in the list associated to that user.
Page 65: The Access Control Service
ONTROL ERVICE The IPervoice system is provided with an embedded access control service, used to control the opening of different passages, such as doors, gates, barriers and so on, after identification of proximity keys 1125/50. To control the way opening, both the call modules 1039/13 and 1039/18 can be used, which are provided with an embedded proximity reader or the IP key reader 1039/88 can be used.
Page 66: Proximity Key Management
5.7.2 T ANDS IPervoice makes it possible to define one or more time bands to limit the access to the building. For example, the maintenance men must not be enabled to enter during the night, weekends or holidays. Three time profiles can be configured: The management operations of keys and associated passages are performed using the web application available through the system server.
Page 67: Anti Pass-Back
/18), but, as described later, a local directory can be configured, using the configuration web application embedded in each telephone 4501/5. IPervoice system supports only VoIP telephones certified by Urmet; other telephone types could not work or make the whole system work incorrectly.
Page 68: Technical Prescriptions
XTERNAL EVEL IPervoice “Street Side” is composed by a 100 Mb/s Ethernet network, so the topology is star point-to- point. In each centre there is a PoE switch (1039/44 or 1039/45). Each star centre is the PoE switch (1039/44 or 1039/45), where all IP IPervoice devices are connected.
Page 69 Switch-to-switch branch, used to connect PoE switches in order to extend the Ethernet network. In all cases, the max. allowed distance is that defined by IEEE 802.3 standards for Fast Ethernet networks (100 Mb/s), connected with UTP CAT5 cable: according to these standards, the distance between two Ethernet devices must not be longer than 100 m Figure 24: External level, IP network –...
Page 70: Prescriptions For Internal Level
RESCRIPTIONS FOR NTERNAL EVEL As regards the “Riser side”, devices are connected in series: in each device there is one “input” and one “output” RJ45 socket; the last one is used to connect the next device. This is the mode generally used on all the riser, except for intercom interfaces (1039/36) used inside the apartments, that use a star topology for their connected apartment stations.
Page 71 Figure 25: Internal level, riser – topology and distances The main rules to be respected that are always valid are the following: The max. extension of a riser, except derived stations inside apartments, must not be greater than 900 m.
Page 72 On the riser, the max. distance between a power supply (1039/20) and the next one must be shorter or equal to 100 m. The max. number of power supply units that can be installed in a riser is 9. The max. number of 4-user decoders (1039/34) that can be installed between a power supply and the next one (i.e.
Page 73 Figure 26: Internal level, riser – topology and distances with riser distributor If more than one riser is needed, a riser distributor (1039/54) can be installed on the output of the first power supply. Even though the available risers are four, remember that the distributor, that is a passive component, does not change riser dimensioning parameters, that remain the same.
Page 74 Figure 27: Livello interno, colonna montante – topologia e distanze con interfacce intercomunicanti If in apartments one or more intercom interface 1039/36 is needed, install a power supply 1039/20 on the derived branch of the 4-user decoder. This in order to power apartment stations and intercom interfaces.
Page 75 The Table 8 summarizes all the above mentioned constraints. Riser distances and extensions Max. distance between two column power supply units (1039/20) 100 m Max. distance between IP Gateway (1039/50) and the last 4-user decoder (1039/34) 900 m Max. distance between IP Gateway and the last apartment station 900 m Riser max.
Page 76: Installation Prescriptions
EVEL TREET IPervoice “External level”, composed by IP network, typically concerns the street side, that is the part of the system placed outside the building or referred to the external perimeter of the building (chapter “The External Level: the IP network” on page 15). The cable used for the data is usually laid in conduits buried under the road surface, so more exposed to humidity and seepage.
Page 77: Wiring Instructions
Cable type • Double sheathed cable with 4 unshielded twisted pairs UTP CAT 5E • External polyurethane sheath • Use allowed also in pipes containing 230 V conductors Electric and physical characteristics • External sheath diameter and colour: 5,7 ± 0,25mm / BLACK •...
Page 78: Internal Level (Riser Side)
EVEL ISER The “Internal level” is the IPervoice network referred to building risers or apartments. In this case, cables are laid in ducts inside the structure, in shaft for the riser and in pipes inside apartments or for floor distribution. URMET 1069/91 blue cable also allows cables to be laid in ducts with 230V cables inside.
Page 79: Wiring Instructions
Cable type • Double sheathed cable with 4 unshielded twisted pairs UTP CAT 5E • External PVC sheath • Use allowed also in pipes containing 230 V conductors Electric and physical characteristics • External sheath diameter and colour: 5,7 ± 0,25mm / RAL 5017 •...
Page 80: Warning About Rj45 Connectors Use
RJ45 C ARNING ABOUT ONNECTORS USE CAT5 Ethernet cables have 8 conductors inside that can be: stranded wire (also named flexible conductors) solid plain copper wire Cables with stranded conductors (flexible) are those normally used for mobile cables that allow a personal computer to be connected to a wall socket.
Page 81: Advices For Devices Installation
As already mentioned, all devices must be correctly wired, according to national standards in force. Also the position of “command modules”, as for example call modules and apartment stations, is important for the correct operation, especially for an easy use of IPervoice system. 7.4.1 C...
Page 82: Apartment Stations Installation
7.4.2 A PARTMENT TATIONS NSTALLATION As regards installation of wall mounting door phones and video door phones inside apartments, it is suggested to follow the instructions shown in the Figure 29. Figure 29: Devices installation – Apartment stations installation...
Page 83: Video Signal Adjustment
IDEO IGNAL DJUSTMENT Before riser startup, the video signal must be adjusted. This procedure is used to ensure the correct signal level of all system devices. To adjust the video signal, the installer must do all necessary electrical connections; once this operation is completed, he must follow the procedure below: 3) Put the riser to be adjusted in “Video adjustment”...
Page 84: Apartment Stations Configuration
PARTMENT TATIONS ONFIGURATION As described in the next chapters, IPervoice system configuration is almost totally performed with a laptop and a PDA Phone or a Netbook, except for apartment stations, that are provided with micro switches (dip-switches on the video door phone bracket) that must be locally programmed on the device.
Page 85 In both cases, the numbering follows the binary system: the Figure 30 and the Figure 31 show the possible configurations concerning decoder and apartment. Port 0 (DER1) Port 1 (DER2) Port 2 (DER3) Port 3 (DER4) Figure 30: Apartment stations configuration – Dip-switch for programming 4-user decoder port number Warning: if in the apartment there is only one apartment station, its identification number must always be 0 (zero), because it is the Master station.
Page 86: Button Function Assignment
UNCTION SSIGNMENT In IPervoice system, apartment stations are provided with some buttons, used to perform special functions. For some buttons, these functions are configured by default and cannot be changed; other buttons, as described in the chapter “Apartments Configuration”, paragraphs “Call Buttons” on page 198 and “Special Functions”...
Page 87 Idle state Audio/Video Idle state Handset on-hook communication with Handset off-hook Handset off-hook Door lock release 1 Door lock release 1 Door lock release 1 • • • Door lock release 2 Call button 7 Door lock release 2 •• ••...
Page 88: Ipervoice Configuration
ERVOICE ONFIGURATION After describing the IPervoice system installation, it is possible to deal with the system functions configuration, according to specific customer requirements. ENERAL NFORMATION For IPervoice system set-up, the installer must perform some configurations, to make the system work as required.
Page 89: The Frontend
RONTEND The fundamental tool used to configure the IPervoice system is a Web based application resident on the server 1039/1, called “FrontEnd”. To use this application, connect a laptop (Notebook or Netbook) the IPervoice IP network, and access to the FrontEnd with a browser commonly used for Internet.
Page 90 Warning: for the FrontEnd correct operation, the browser must support “javascript” features, that must be activated. Also “Cookies” must be enabled. The Frontend web page structure is split into three main areas (see Figure 35). The first area, indicated by number 1, is dedicated to the application menu, where all the Frontend functions can be called; the second area, indicated in the figure by number 2, is on the left side of the page.
Page 91: Frontend In Multi-Server Mode
8.2.1 RONT ND IN ULTI ERVER The page shown after login has the above described structure, with different contents when in Multi- Server mode. As shown in Figure 36, the functions tree indicated by number 2 has a different structure: the single system is not the first element of the list, but a part of the Multi-Server system.
Page 92: The Main Menu
• Export template: export of data template for resident and external SRV CONFIGURATION Change of IPervoice server date and time and configuration of system remote management. It displays the system log. SEARCH It activates the search functions available in the IPervoice system, for example: search of a resident, of a device by topological or logic code, by key code and so on.
Page 93 (firmware): • Check System consistency: checking of firmware versions on the configured devices • Upgrade system firmware: update of the IPervoice server firmware • Backup and Restore: backup and restore of the system configuration data (also available in MAINTENANCE menu).
Page 94: Devices Tree
8.2.3 D EVICES TREE On the left side of Frontend user interface, the system hierarchical structure is shown, associated to a list of system configuration functions. Beside each item there is an icon, to make the identification easier. At the top of the list there is the name assigned to the system, in this specific example “Technical Guide System”, that is the starting root;...
Page 95: System Structure
8.2.4 S YSTEM STRUCTURE The IPervoice Frontend allows the system information to be entered, according to the system topologic structure. The result is a hierarchical structure that contains the buildings (Blocks), the stairs inside each block (Stairs), and the respective Floors (Figure 38). This figure shows the different devices that are...
Page 96: Preliminary Checking
The hierarchical structure defined above is also used to fill in the residents data (i.e. people living in the apartments), for populating the user directory. In the IPervoice system, the residents are “included” in the apartments, so the data entry is performed apartment by apartment and is more user-friendly. The...
Page 97: The "Startup Wizard
TART IZARD To make the system configuring operations easier, especially for the first system start-up, the IPervoice system provides a guided procedure that, once activated from the Frontend, helps the user, “step by step”, to set up the data necessary for the correct operation of the system. This procedure is called StartUp Wizard and is launched by clicking with the mouse on the respective menu item (Paragraph “The main menu”...
Page 98 If there are VoIP telephones 4501/5 in the system, they need some preliminary settings, in order to be detected by the IPervoice server and be available in the list of the new devices to be configured. These operations are described in the chapter “VoIP...
Page 99 (1039/13 or 1039/18) Main IP video door unit None (1039/72) VoIP Telephone Associated Block, Stair and Floor (4501/5) Video Server None (1039/69) IP key reader None (1039/88) IP Special Decoder None (1039/80) Table 14: Dependency constraints for IPervoice devices configuration...
Page 100: Site Configuration
8.3.2 S ONFIGURATION Once the wizard has started, the first step to be performed concerns the input of system configuration parameters. Note: the information required by the Startup Wizard during this configuration step can also be changed later in the Frontend main page. Figure 41: Startup Wizard –...
Page 101 Parameter Meaning Default value Language Language used by the system. It can be selected from the English pull-down menu. Refer to Frontend to get the updated list of supported languages. Addressing method Method used to determine the devices addressing in the call Topologic codes codes.
Page 102: Ip/Cat5 Gateway Configuration
8.3.3 IP/CAT5 G ATEWAY ONFIGURATION With the IP/CAT5 gateways configuration, the Startup Wizard starts the real devices installation. The list displayed to the installer is shown in Figure 42. Only devices not yet configured are in the list: to configure them, select the desired device and click the button “Next page”. The system will display in sequence, for each selected gateway, the detail page where all the required data can be entered.
Page 103 Figure 44: “Topological code” structure The “Block code” and the “Stair code” assigned to the gateway specify its block and stair. These codes are the first part of the system “Topological code”, as shown in Figure 44. DENTIFICATION In this section, the only data required to be entered by the installer is the “name” assigned to the gateway;...
Page 104 ATEWAY LOCK AND TAIR SSIGNMENT Each gateway is always associated to a building (Block) and to a Stair, so it is necessary to select from the two pull-down lists the “Block Code” and the “Stair Code”, that identify the block and the stair. If the block code, the stair code or both of them are not included in the lists, they need to be added and then selected.
Page 105 Name Stair identifier, required field. Maximum length: 32 alphanumeric characters Code Stair code, required field. It must be unique for each block. It is the second pair of characters for the topological call code. Fixed length: 2 alphanumeric characters (for ex. S1, 01, 1S, etc.) Table 18: Identification data of a new Stair Warning: To add a new stair, a block, identified by the item “Block code”, must be selected from...
Page 106 Figure 47: Startup Wizard – Configuration of column devices associated to the gateway In order to configure the column devices, enter the number of 4-user decoders. This operation is performed by entering the decoder number in the respective text field named “Number of connected Decoders”...
Page 107 To expand the detail section of each 4-user decoder, click on the image near “Dec Name”. The list of the outputs (ports) connected to the apartments will be displayed for the user. To configure each apartment, select the Floor to which it must be associated. If the desired floor has not been added yet, it is possible to add it during the apartment definition, by pressing the button “Add a floor”.
Page 108 Apt Name Name of the apartment. Required field. The system assigns a default name like Apartmentn, where n is a progressive number . Apt code Code of the apartment. Required, numeric and unique field in the assigned floor. Fixed length: 2 alphanumeric characters (e.g.. 01, A1, 1A, AB). Alarm Interface Alarm interface 1039/61 installed in the apartment.
Page 109: Ip Call Module Configuration
This is the minimum required data for the configuration; to obtain the correct operation, the installer must complete the configuration by entering the other data, as described in the chapter “IPervoice Devices advanced Configuration - IP Call Module ” on page 128. Name Call Module identifier, required field.
Page 110 “Door” must be added to the IP Call Module. Perform this operation following the procedure described in the chapter “IPervoice Devices advanced Configuration - IP Call Module, Doors” on page 133.
Page 111: Ip Video Door Unit Configuration (Entry Panel)
In order to use this device in the system, the installer must complete the configuration by entering other data, as described in the chapter “IPervoice Devices advanced Configuration - IP Video Door Unit (Entry Panel)” on page 128.
Page 112 “Door” to the IP Video door unit. This operation must be performed as described in the chapter “IPervoice Devices advanced Configuration - IP Video Door Unit (Entry Panel) - Doors” on page 141.
Page 113: Concierge Switchboard Configuration
The data entry form also displays some information shown for the other IPervoice devices described above. After configuration, it is always possible to know the switchboard MAC Address, by selecting from the menu the item...
Page 114 Figure 55: Wizard – Configuration of a new switchboard Name Name assigned to the switchboard, required field. Maximum length: 32 characters Firstname First name of the concierge, if both first name and surname must be entered. This is an optional field. Maximum length: 32 characters IP address IP address automatically assigned by the system server to the switchboard.
Page 115: Video Server Configuration
As for the Call Modules, the entry of configuration data with the StartUp Wizard may not be enough for the required operation; the installer must complete the configuration by entering the other data, as described in the chapter “IPervoice Devices advanced Configuration - Concierge Switchboard” on page 142.
Page 116: Ip Key Reader Configuration
“Door” must be added to the IP Key reader. This operation must be manually performed, as shown in the chapter “IPervoice Devices advanced Configuration - IP Key Reader ” on page 148.
Page 117: Special Decoder Configuration
8.3.9 S PECIAL ECODER ONFIGURATION After configuring the IP key readers, press the button “Next” to access the list of the new special decoders detected in the system. Select from the list the devices to be configured and press the button “Next”...
Page 118: Voip Telephone Configuration
To perform this operation, access 4501/5 telephone web server. First of all, the IP address assigned to the VoIP telephone by the IPervoice server must be known. To obtain this data, the VoIP telephone must be correctly powered and the LCD display must show the message “No Service”; press the button “Menu”...
Page 119 Figure 62: VoIP Telephone 4501/5 – Access to configuration Figure 63: VoIP Telephone 4501/5 – System information and main menu...
Page 120 IP-ATA 4501/30 RELIMINARY PERATIONS FOR INTERFACE REGISTRATION To register 4501/30 interface, perform the following operations: Disconnect from the LAN network the PC used to configure the 4501/30 device. Check that the PC is configured to operate in DHCP client mode. Figure 64: VoIP-ATA 4501/30 interface –...
Page 121 username and password and press the button “Login” to access. The browser will show the system information page (Figure 66). Figure 66: VoIP-ATA 4501/30 interface – System Information and main menu SIP S EGISTRATION TO ERVOICE ERVER After these preliminary operations have been completed, the registration procedure is the same for both devices.
Page 122 Figure 67: VoIP Telephone 4501/5 – SIP server settings The VoIP telephone allows max 3 different SIP servers to be registered: to use this telephone with the IPervoice system, fill in only the fields concerning the first server (“Realm 1”) . The settings are shown...
Page 123 PC used for configuration and connected to IPervoice system with the WAN port, present on the rear side of the interface (Figure 68). Also in this case, the green led “REG” on the device front panel will turn on to confirm the SIP registration.
Page 124 ONFIGURATION WITH THE IZARD Once the preliminary procedure is completed, the StartUp Wizard shows the list of the new VoIP telephones in a specific section: select the devices to be configured and click the button “Next page” to access to the detail page, where the required configuration data must be entered. Figure 69: Startup Wizard –...
Page 125 4501/5 telephone keypad. In this case, it is necessary to program the telephone directory or the speed dialing numbers of each telephone. Please refer to ”IPervoice Devices advanced Configuration - VoIP Telephone” on page 157.
Page 126: End Of Configuration With Startup Wizard
8.3.11 E ND OF ONFIGURATION WITH TART IZARD By clicking the button “Next page”, the StartUp Wizard displays the page that informs the user that the guided configuration has been completed. By pressing the button “Back to main page”, the browser goes back to the main page.
Page 127: Ipervoice Devices Advanced Configuration
ERVOICE EVICES ADVANCED ONFIGURATION All the IPervoice devices have some “advanced” configuration parameters, that must be explicitly set for the correct operation of the system. This chapter describes these parameters showing, for each device, its meaning and programming mode. IP/CAT5 G...
Page 128: Ip Call Module
IP C ODULE IP call modules (such as 1039/13 or 1039/18) have a large number of parameters that can be changed by the installer. To access to the parameters configuration page, select the desired module in the devices tree (Figure 73). Warning: if the operations concern a main module, it must be searched in the section “Primary Call Module”, in the first tree level;...
Page 129: Block Group
In the IPervoice system, contrary to the usual procedure, the resident names are associated to the apartments and so the “residents address books” are block and stair lists. For further details concerning the resident names/apartments association,...
Page 130: Remarks About Secondary Call Modules
9.2.2 R EMARKS ABOUT ECONDARY ODULES The “Secondary” call modules are automatically configured by the system in order to show only the names of residents associated to the competence Block or Stair. If the visitor knows the code (logic/topological), he can call any system apartment, in any Block – Stair. For this reason, a resident of Stair A, called by the Secondary Call Module of Stair B, can also open the door of Stair B.
Page 131: Interface Options
9.2.3 I NTERFACE PTIONS This section is dedicated to the configuration parameters setting of the IP call modules user interface. The Figure 76 shows on the Frontend the dedicated section, after it has been expanded with the button placed beside “Interface options”. Figure 76: Advanced Configuration –...
Page 132: Special Functions
Brightness Camera brightness, it cannot be changed min: 0, max: 10 Theme Identifier of colour theme used by the user interface, it cannot be changed Micro Microphone audio level, it cannot be changed. +3dB Available values: -5dB, -3dB, 0dB, +3dB, +4dB, +5dB Speakers Loudspeaker audio level, it cannot be changed.
Page 133: Doors
Each command function can have two operating states: Not assigned Default condition, the function has no effect on the system outputs. Outputs The function is active: if it occurs, the outputs selected from the list “Output List” are activated (Figure 77). The available command modes are the following: •...
Page 134 Figure 78: Advanced configuration – List of doors managed by the IP Call Module By pressing the button “Add a door”, access to the page where the configuration data can be entered (Figure 79 – Main door; Figure 80 - Vehicle entrance); the installer has two options: Enter the required data: this is the typical case, the system will create a new door with the data entered by the user Press the button “Use existing door”: this case is used in case of advanced functions...
Page 135 Figure 80: Advanced configuration – Adding a new vehicle entrance gate to the IP Call Module Name Door identifier, alphanumeric required field. Maximum length: 32 characters. Number Number of the door of the call module. The value can be selected from a pull-down menu;...
Page 136 Type Type of door opening. The value can be selected from a pull-down menu, the available values are: • Secret: the apartment station door lock release button will only activate the electrical lock if the apartment is in audio conversation or in video connection with the call module, or has been called and is waiting to be answered.
Page 137: Ip Video Door Unit (Entry Panel)
IP V IDEO NTRY ANEL IP Video door units, also called “Entry Panel” (1039/72), have the same functions as IP call modules previously described, but they have no graphic display and numeric keyboard. To access the configuration page, select the desired module from the devices tree, as shown in the following Figure Figure 81: Advanced Configuration –...
Page 138: Interface Options
Warning: If operations concern a main module, search for the desired module in the section “Primary entry panel” in the first level of the tree; if operations concern a secondary module, search for it in the belonging block/stair, in the item “Blocks”. As for IP call module, advanced configuration parameters are grouped into three different sections: the one, dedicated to the user interface of the video door unit, the 2 section used to assign “Call...
Page 139: Call Buttons
9.3.2 UTTONS Each module 1039/72 is provided with 2 call buttons, that can be up to 32 max. by installing modules 1038/17. In order to associate the desired function to each button, select, from the pull-down menu in the section header, the button to be configured and expand the section “Call buttons” (Figure 83). Figure 83: Advanced Configuration –...
Page 140: Special Functions
VoIP Phone The call is sent to the VoIP telephone selected from the pull-down menu. Apartment This is the most used function. In this case the call is sent to a special apartment. The selection is made by indicating the apartment topological code with the respective pull-down menus.
Page 141: Doors
9.3.4 OORS Also the IP video door unit can command two doors (usually pedestrian door and gate) with the same modes and characteristics as the previously described IP call module. For programming procedures, see the paragraph 9.2.5 “Doors” on page 133. Figure 85 shows the mask used to configure passages on module 1039/72.
Page 142: Concierge Switchboard
ONCIERGE WITCHBOARD The concierge switchboard advanced configuration parameters are split into two sections: the 1 , where the “Competence Area” is defined, and the 2 , used to define the interactions with the IP special decoders (1039/80). Select in the devices tree the section “Switchboard”, as indicated by the red arrow, choose the switchboard to be configured and access the page shown in Figure 86.
Page 143: Special Functions
Figure 87: Advanced configuration – Management of concierge switchboard competence areas 9.4.2 S PECIAL UNCTIONS Also the switchboard can activate one or more system outputs, if an event occurs. Figure 88: Advanced configuration – Special Decoder Functions that can be associated to the IP call module The outputs operating modes are the same as those indicated in the section concerning the call module, but the special functions that can activate a command for the configured outputs are the following: Drive output on call...
Page 144: Switchboard In Multi-Server Mode
The switchboard becomes the central control node of the whole Multi-Server system, because it can receive/send information from/to all IPervoice servers that it can manage. In Multi-Server mode, the switchboards are in the first hierarchic level of the devices tree and over the single systems (Figure 89).
Page 145 Warning: in order to complete the registration, the server must be active and online, otherwise the FrontEnd will not allow the selection (Figure 90). Figure 90: Multi-Server mode – Advanced Configuration – Switchboard registration, server offline Figure 91: Multi-Server mode – Advanced Configuration – Switchboard registration...
Page 146: Competence Area E Special Functions In Multi-Server Mode
9.4.5 OMPETENCE REA E PECIAL UNCTIONS IN ULTI ERVER “Competence areas” and “Special functions” configuration in a Multi-Server system is similar to the one above described (paragraphs 9.4.1 e 9.4.2 and on page 142 and following); before performing the desired configurations, select the server. Competence areas to which a switchboard belongs and special functions that it can manage are specific for each server and they must be configured in this site.
Page 147: Video Server
In order to activate a video server (1039/69), enable on the device the controlled cameras; to perform this operation, access IPervoice system advanced configuration. Select the item “Video Server” from the devices tree and choose the desired device, then press the button “Add a camera” near the item “Camera list”, as shown in Figure 93.
Page 148: Ip Key Reader
Name Camera identifier, required alphanumeric field. Max. length: 32 characters. Note: it is suggested to assign to each camera an identifier which contains also the reference to the belonging module, so it will be easier to identify the camera during selection. Number Video input number.
Page 149: Special Functions
Setting and entry modes are the same as those described in the chapter “IPervoice Devices advanced Configuration - IP Call Module , Doors” on page 133, even if in this case, as shown in Figure 96, there are fewer parameters.
Page 150: Moduli Controllo Accessi Avanzato Su Rete Ip (Ip Modules)
NETWORK ODULES The IPerVoice has two more devices, in addition to the IP key reader described above, which can be used to implement an access control system with superior features. In brief, each functional unit consists of a controller connected to the IPerVoice IP network (IP Module), and a door control unit (PIO Module).
Page 151: Aggiunta Di Una Nuova Porta
Name Device ID, mandatory field. Maximum length: 32 characters. IP address IP address automatically attributed by the system server to the IP Module. MAC address Univocal physical address of the device. This is used to discriminate the devices from one another during configuration. FW version Application firmware version installed on the device.
Page 152 Figure 98: Advanced configuration – Adding a new door to the IP Module Name Door ID, mandatory alphanumeric field. Maximum length: 32 characters. Door access type Door type. The possible settings are: • Key Code: access by means of proximity key •...
Page 153 notification is generated. min: 1 sec, max: 999 sec Default setting: Not enabled. Warning: An appropriate open door sensor must be connected to the door control module to use this function. Time Profile Time profile to be assigned to the door (if available) (see “Time Bands” on page 66 The setting can be selected from a drop-down menu containing the previously programmed profiles.
Page 154: Special Decoder
PECIAL ECODER The special decoder advanced configuration concerns operation modes of the two relay outputs present in the device. To access the configuration page, select the item “Special decoders” from the devices tree, identify the desired device and select the number of the output to be configured (Figure 99). Figure 99: Advanced Configuration –...
Page 155 Figure 100 : Advanced Configuration – Special Decoder outputs configuration Name Output identifier, required alphanumeric field. Maximum length: 32 characters. Note: it is suggested to assign an identifier to each output, which must contain the reference to the belonging module, for an easier identification during the procedure used to associate it to the command event.
Page 156 VENT UTPUT SSOCIATION The procedure used to associate an output to an event used to control the output status consists in some steps. For example, to activate an output of a decoder with a “special code” entered on the keypad of a call module, follow the four steps shown in Figure 101. First of all, select the Special Decoder to which the command must be sent (Step 1) and then define the desired output with its timing parameters (Step 2).
Page 157: Voip Telephone
IP T ELEPHONE The VoIP telephone 4501/5 has no other parameters to be configured, besides those described in the respective section of the StartUp Wizard. No alphanumeric codes can be entered from the telephone keypad; if the logic or topological codes defined in the system contain non-numeric characters, to call a switchboard, another VoIP telephone or the apartments, these codes must be entered in the telephone directory.
Page 158 Figure 102: configuration – 4501/5 VoIP telephone numbers programming 10 speed dialling numbers are available, from 0 to 9; by selecting the respective code, the user can call the programmed number. Besides the fields required to program a new number, described in the following Table 36 , there are some buttons, that make it possible to: Delete the selected number: “Delete Selected”...
Page 159 To save the new programmed user or update an existing one, press the button “Add Phone”; to delete information in the entered data field, press the button “Reset”. IP T PENING WITH ELEPHONE If the VoIP telephone 4501/5 is used as apartment station, it must be able to open the passages (pedestrian door and vehicle entrance gate for example) managed by call modules.
Page 160: Stairs Preset Commands
In order to configure the apartment stations of the stair, IPervoice will use the stair profile to automatically assign to the apartment stations the preset parameters. So the installer doesn’t need to configure them in manual mode...
Page 161: Call Buttons
Figure 105: Configurazione avanzata scale – Impostazione mappe grafiche predefinite The configuration page will contain a list of the call modules where the plan can be set (Figure 105). See the following table to receive information to set required parameters. Call module name Under the call module item (in the example of Figure 105 “Main Entrance Call Module”...
Page 162 Figure 106: Stair advanced configuration – Preset call buttons Programming information are in Table 46. Call Buttons The system executes the command configured below when the call button, selected from the pull-down menu, is pressed. Available values are from Call button 1 to Call button 250. These are configurable buttons used when the apartment station handset is picked up (or the conversation button on hands-free models has been pressed.
Page 163: Special Functions
VoIP Phone The call is sent to the VoIP telephone selected from the pull-down menu. Apartment In this case the call is sent to an apartment. The selection is made by indicating the topologic code of the apartment, which must belong to the same IP Gateway.
Page 164 Special buttons The system executes the command on the configured outputs when the special button, selected from the pull-down menu, is pressed. The available values are: Button 1 to Button 250 . These are configurable buttons. Drive output on Door The system executes the command when the user in the apartment Opening station requests a door lock release.
Page 165: Column Devices Configuration
Devices advanced Configuration” on page 127, do not exhaust the subject of the devices belonging to IPervoice system riser columns. In particular, this chapter describes how to program the column devices by means of SmartPhone or Netbook, how to configure the column lift interface 1039/37 and how to add new 4-user decoders.
Page 166: Softmobile Software Installation
PDA. If this operation is performed for the first time, or if a new “Mobile” device must be used, the “SoftMobile” software must be installed. With the IPervoice FrontEnd, it is possible to select the version suitable for the PDA being used, and then download it to the PC for the installation.
Page 167 There are no constraints for SoftMobile software installation, nor for the Mobile operating system folder of config.dat file containing the system data (e.g. IPervoice). At present, the IPervoice system supports Classic or Professional Version 6 of Windows Mobile operating system, the standard version is not yet supported.
Page 168: System Data Download To Pda And Smartphone Device
FrontEnd. Leaving the PC connected to the FrontEnd, the configuration data must be downloaded from the IPervoice server to the “Mobile” device that will be used to program the riser columns. Because a direct download is not possible, the data must be first downloaded from the IPervoice server to the PC by means of the FrontEnd specific function, then from the PC to the Mobile device.
Page 169 The last step consists of moving the config.dat file, now saved on PC, to a specific PDA folder. The Figure 114 shows an example, where the file has been saved in the “IPervoice” folder on the PDA memory card. To perform this operation, use the functions of Windows “Explorer” to copy a file from one folder to another.
Page 170: Download Of System Data To Column Devices
Figure 114: System data download to PDA – Destination folder Once the copy is completed, the USB connection between PC and PDA is not needed any more. The PDA can be disconnected and used to download system data to column devices. 10.1.3 D OWNLOAD OF SYSTEM DATA TO COLUMN DEVICES To download system data, the SoftMobile...
Page 171 In the example the IPervoice file row is selected in the folder. After selecting the file, the application goes back to the previous screen; press the button “Submit” to download the config.dat...
Page 172 Figure 116: SoftMobile, Windows Mobile version - config.dat file selection ONFIG DAT FILE SELECTION AND DOWNLOAD YMBIAN The SoftMobile application, in Symbian version, uses an external utility to download the config.dat file. This application is called “Database Manager” and is installed in the same folder containing the SoftMobile main application.
Page 173 Figure 117: Database Manager – Application start-up The first step consists of selecting the config.dat file, that must be saved (as already described in “SoftMobile software Installation” on page 166) on the PDA “memory card”, and not in the SoftMobile application folder.
Page 174 EVICE SELECTION AND SYSTEM DATA DOWNLOAD Every time system data must be downloaded to column devices, the Bluetooth interface 1039/56 must be connected to the device to be configured. Figure 119: Bluetooth programming interface For the connection, use the provided cable without down powering the device to be programmed .
Page 175 Figure 120: SoftMobile, Windows Mobile and Symbian versions – System data download to the 4-user decoder The next page is shown in Figure 121 on the left: here press the button “Search Device”: for the first time, if the Bluetooth device has not been identified yet, the PDA automatically shows the identification procedure (“Pairing with Bluetooth programming interface (Windows Mobile)”...
Page 176 Figure 121: SoftMobile, Windows Mobile and Symbian versions – Bluetooth device selection and data download The download procedure is now completed, the Bluetooth programming interface 1039/56 can be disconnected; repeat the same procedure to configure the next column device. Note: if the programmed 4-user decoder manages apartments equipped with intercom interfaces (1039/36), these must also be configured, to complete the apartment programming procedure.
Page 177 AIRING WITH LUETOOTH PROGRAMMING INTERFACE INDOWS OBILE If the Bluetooth device 1039/56 is used for the first time, the identification procedure is automatically activated. Figure 122 shows the procedure to be used in this case: first of all the user is informed that a new Bluetooth device has been detected and is asked to confirm if it must be added to the list of devices known by the PDA.
Page 178 Figure 123: SoftMobile, Symbian version – Bluetooth programming interface identification and pairing HECKING OF PARAMETERS DOWNLOADED TO THE COLUMN DEVICE Even though the application has confirmed the correct download of configuration parameters, it can be useful to check the data already downloaded to the device. To perform this operation, click on the item “MENU”, if Windows Mobile PDA is used, or on the item “Options”...
Page 179 must be performed, for the 4-user decoder, comparing the number assigned to the device; regarding an apartment, using its special parameters, for example those highlighted in , i.e. the lower part of topological code (Floor and Apt), and the call codes assigned to the apartment stations buttons; this subject will be dealt with in the chapter “Apartment advanced configuration - Call Buttons”...
Page 180 For both PDA models, the search can be performed by “Topological Code” and by “Device Name and Type” (Figure 127). To start searching, select the item “Search”. Figure 127 : SoftMobile, Windows Mobile and Symbian versions – Search mode The list displayed depends on the search mode : in the first case, the display will show the items identified by a Topological Code according to the configured search method, typically Blocks, Stairs, Floors and Apartments.
Page 181: Parameters For Column Devices Configuration
Figura 128 : SoftMobile, versioni Windows Mobile e Symbian - Risultati ricerca per Codice Topologico 10.1.4 P ARAMETERS FOR COLUMN DEVICES CONFIGURATION IPervoice configuration data, required for correct operation of the system, is of a different type. It is programmed in the IPervoice server by means of the FrontEnd, as already described. Warning: column devices must be programmed only AFTER all configuration data has been stored in the FrontEnd database.
Page 182 Concerned Parameter Configuration at page Devices to be programmed device Time T1 1039/34 and Pag. 101 All the devices 1039/34 and 1039/36 in the (Call Pickup time) 1039/36 “Site Configuration” system Time T2 1039/34 and Page 101 All the devices 1039/34 and 1039/36 in the (guaranteed conversation 1039/36 “Site Configuration”...
Page 183: 4-User Decoders Configuration
10.2 4- USER ECODERS CONFIGURATION 4-user decoders are associated to a Block and a Stair and are physically and logically connected to an IP gateway. To select the device to be configured, its respective IP gateway must be identified; then expand the item “Decoders”, that includes the devices 1039/34 (Figure 129).
Page 184: Lift Interface Configuration
10.3.1 O PERATING MODE IPerVoice allows to configure two operating modes for the lift interface: Floor Mode – default Apartment Mode The configuration is performed for each stair, as shown in Figure 131. The first mode (Floor Mode) allows to configure the interface commands according to the apartment floor: in this case, several apartments of the same floor will have the same relay activation diagram.
Page 185 Figure 131: Lift Interface Configuration - Lift mode setting Also lift interface modules are associated to a Block and a Stair and so they are connected to an IP gateway. To select the device to be configured, identify the IP gateway to which the lift interface is associated, expand the item “Lift Interface”...
Page 186 Figure 133: Lift Interface Configuration - Main configuration data The display shows the configuration page, similar to that shown in Figure 133; besides main data, shown in the following table, to complete the configuration perform the following two operations: Creation of access path Association of command relays Name Name assigned to the lift interface, required field.
Page 187 To access the path configuration, click on “Path” item under the device name, as shown in Figure 134: the display will show the page with the list of the paths already configured. To change an existing path, click on the linked device type or name; to add a path, click “Add a path” in the upper side of the page. Figure 134: Lift Interface Configuration –...
Page 188 The data available for the configuration are summarized in the following table: Type of linked device List of device types to which the path must be linked. Allowed values: Call module, Entry panel, key reader, Switchboard. Name of linked device List of system devices of the selected type.
Page 189 Figure 136 : Lift Interface Configuration – Command relay association in Floor Mode SSOCIATING IN PARTMENT In this case, the operation is performed by configuring the settings of each apartment. First select the desired apartment from the devices list, then select the interface to be configured in the section “Lifts serving this apartment”...
Page 190: Apartments Configuration
PARTMENTS ONFIGURATION An important chapter for the IPervoice start-up concerns the apartments configuration. These can be connected to a CAT5 dedicated network or to an IP network, according to the type of riser. The system provides many functions; these will be described by category, starting from the device involved with use in configuration phases.
Page 191 Figure 138: Apartment selection – by 4-user decoder In the second case, identify the desired floor inside the respective block-stair, then apartments are displayed, as shown in Figure 139. Warning: The function “Add IP apartment”, shown in the page, is used to add an apartment equipped with IP devices only.
Page 192: Adding An Apartment
The FrontEnd displays the data entry page, as shown in Figure 140. Because this paragraph concerns the minimum data that allows IPervoice to manage a new apartment, only the parameters concerning the “Basic Info” section of the configuration page will be described. The other functions will be described later in the section “Apartment advanced configuration”...
Page 193 Name Apartment name. Required field. Maximum length: 32 characters. Topological code It is the apartment unique code. The user must specify the Floor, by selecting it from the pull-down menu and must enter the last part of the real topological code. Required field. Fixed length: 2 alphanumeric characters (e.g.
Page 194: Apartment Advanced Configuration
Figure 141: Advanced apartment configuration – Call forwarding setup This section is only available if the call forwarding function is configured on the IPerVoice system. See Server Configuration” on page 261. for more information.
Page 195: Floors Accessible By The Residents Of The Apartment
11.3.2 F LOORS ACCESSIBLE BY THE RESIDENTS OF THE APARTMENT This section, that is shown expanded in Figure 142, makes it possible to select the floors to which the apartment residents can access. This function is related to the use of the lift interface 1039/37, that allows residents to be associated to a list of floors enabled for the use of the lift.
Page 196: In The Calling Call Module
11.3.3 I N THE CALLING CALL MODULE This section describes the configuration data concerning the interaction between apartment and call modules and vice versa. This data is related to two main functions: the first one, provided by the devices 1039/13 and 1039/18, allows some apartment parameters to be changed from the door unit; the second one allows a specific message to be shown to visitors, that will be displayed on the call module when the resident is absent.
Page 197: Path Images
11.3.4 P MAGES This paragraph will deal with subjects already described in the previous section. In this case, the target is the visitor, helping them to visually find the Block that includes the apartment they are visiting. For each call module associated to the apartment, it is possible to choose an image, that will appear on the display when the door is opened to let the visitor in.
Page 198: Call Buttons
11.3.5 C UTTONS On the apartment stations there are some configurable buttons (seven max.), that can send commands outside the apartment. They are mostly used, when the apartment station handset is off- hook (or the conversation button has been pressed, in hands-free models), to call a switchboard, to call another apartment in the same riser column (managed by the same IP gateway), or to call a VoIP telephone (Figure 145).
Page 199: Special Functions
Competence area switchboards The call is sent only to switchboards with competence on the apartment VoIP Phone The call is sent to the VoIP telephone selected from the pull-down menu. Apartment In this case, the call is sent to an apartment. The selection is made by entering the topological code of the apartment to be called, which must be managed by the same IP gateway.
Page 200 Even though the commands for special decoders 1039/80 outputs are similar to those already described (for example, on page 132 or page 143), there are two options, described in the following table and concerning two new aspects: the “special buttons” and the cameras, activated in auto-on cycle. Special buttons The system executes the command on the configured outputs when the special button, the same selected from the pull-down menu, is pressed.
Page 201: Resident Management
11.4 R ESIDENT ANAGEMENT As already described, the IPervoice system manages the residents data, by associating them to the apartments. So, the system creates “residents address books” linked to their respective blocks and stairs, instead of a single general directory.
Page 202 Click on “Add a resident”, under the title, to gain access to the data entry page. If some residents have already been added, they will appear in the list, as shown in Figure 148. Figure 149: Apartment configuration – Entering the main data of a new resident Table 48 helps to understand the meaning of the main values to be entered;...
Page 204: Residents Address Book Updating
Once the residents data has been entered, the residents address book must be rebuilt. This operation is performed by the IPervoice server to update the call modules directories. To activate the function, select the item “UPDATE SYSTEM” on the main menu: the result is displayed in a pop-up window, as shown in Figure 150.
Page 205: Door Code Configuration
11.4.2 D ONFIGURATION To open a door from a main or secondary call module, a “Door code” can be used. A code, unique in all the system, can be assigned to each resident; when this code is entered on the keypad of one or more call modules, the relay used to open the door or the vehicle entrance gate is activated.
Page 206 The following table shows the meaning of the available fields: Door Code Numeric door lock release code, required field. Minimum length: 4 characters, 8 characters max. Note: to activate the “hold-up” code, enter a valid door code increased by one unit, e.g.: door code: 123456, associated hold-up: 123457.
Page 207: Key Code Configuration
11.4.3 K ONFIGURATION Using the same method, one or more passages can be opened with a proximity key (model 1125/50). In this case, a key is associated to the selected resident. It is possible to select doors related to call modules, as for door codes, or doors managed by IP key readers.
Page 208 Key Code Proximity key identification code. Required field in hexadecimal format. Fixed length: 8 characters. Note: the identification code is engraved on the back of the key. Time Profile Selection of Door lock release time profile (if available) (see paragraph “Time Bands”...
Page 209: Automatic Key Code Wizard
Encoder 125 must be connected, with the provided cable, to a USB port of the computer, where the IPervoice FrontEnd is being used. The device is directly powered by the PC and so it doesn’t need any additional power supply .
Page 210 Figure 156: Automatic Key Code Wizard - Search criteria selection After search criteria have been defined, press the button “Next”. The system activates the Encoder and is ready to read proximity keys. If this operation is performed for the first time, follow instructions described in the previous paragraph.
Page 211 Now it can be downloaded following information on: http://www.oracle.com/technetwork/java/javase/downloads If the check mark (tick) is not selected, the Encoder will not work properly The application which controls the Encoder 125 is based on a Java Applet inside the Internet browser used to connect to IPervoice FrontEnd.
Page 212 IPervoice is installed (see “IPervoice Server Upgrade” on page 267). The PC used for connection to FrontEnd downloads the Applet from IPervoice server. Only the first time it is used, the old version must be deleted before downloading the new one. This operation is performed from “Java control panel”...
Page 213 The second operation must be performed each time the IPervoice server is updated; after pressing the button “Settings…” and “Delete file…” a dialog window will appear, asking to confirm temporary files deletion; check that both tick boxes are selected and press “OK”.
Page 214 Figure 162: Automatic Key Code Wizard – Code change If the key is already assigned to another user, before changing the assignment from the old to the new user the system will ask for a confirmation (Figure 163). In both cases press “Yes” to confirm the operation and “No”...
Page 215: Apartment Stations Configuration
Video door phone category; in this way, the system can establish audio and video communications. In order to assign the correct typology to devices, access with the IPervoice FrontEnd to the section dedicated to apartment station configuration. Apartment stations are considered to be devices included in the apartments;...
Page 216 Apartment station configuration data is shown in , their meaning in Figure 165 Table 51 Figure 165: Apartment stations configuration – configuration data Number Apartment station identification number. The value is selected from the pull-down menu. Warning: Each apartment must always have an apartment station with identification number 0: this is the “Master door phone”, used by the system for automatic diagnostic operations.
Page 217: Intercom Interface Configuration
NTERFACE ONFIGURATION If four stations per apartment are not enough to meet system requirements, IPervoice allows to extend this limit up to a max. of sixteen, using intercom interfaces. One to four intercom interfaces (1039/36) can be added for each apartment; each interface allows to connect up to four apartment stations. To add a new intercom interface, first of all select the desired apartment from the devices list and click on “Add intercom interface”, as shown in Figure 166.
Page 218 Figure 168: Intercom Interface Configuration – Intercom Interface configuration data Name assigned to the intercom interface. Required field. Name Max. length: 32 characters. Number Intercom interface number inside the apartment. The number can be selected from a pull-down menu; available values are: 0, 1, 2, 3.
Page 219 Figure 170: Intercom Interface Configuration – Apartment Stations configuration data Besides data described in Table 51 in the chapter “Apartment Stations Configuration”, in case of apartment station associated to an intercom interface, it is possible to configure the call buttons behaviour present in the apartment station.
Page 220: Ip Apartments Configuration
The FrontEnd shows the page used to enter data, composed by six sections. The first one, “Basic Infos”, allows to enter the data needed by IPervoice to add the apartment in the system. La Figure 172 and Table 54 show configuration data to be entered by the user and their meaning.
Page 221: Call Forwarding All'interno Di Un Appartamento Ip
Figure 172: IP apartment configuration – Adding an apartment Name Apartment name. Max. length: 32 characters. Topological code It is the unique code of the apartment. The user selects the floor from the pull-down menu and enters the last part of the topological code. Required field, fixed length: 2 alphanumeric characters (ex.
Page 222 SIP Username SIP user to which the call made to the apartment will be transferred. The user must be registered on the Urmet SIP server at sip.urmet.com. Table 55: Adding an IP apartment – Call forwarding configuration Figure 173: IP apartment configuration IP – Call forwarding...
Page 223: Advanced Functions Configuration
12 A DVANCED FUNCTIONS CONFIGURATION This chapter describes IPervoice system special or advanced functions used to realize specific tasks. This section will treat the following arguments: “Numeric code” addressing mode with prefix Time profile management (Doors, Passages, Holidays) Access profile management...
Page 224 This mode is used by 1039/13 or 1039/18 main and secondary call modules. In case of main module, the user will select the desired Block from the list and then will enter the apartment code; in case of secondary module, the user will directly enter the apartment code, because the Block prefix is already saved in the call module (Figure 174).
Page 225 Figure 175: Advanced functions configuration - Prefix mode, assignment to Block Prefix code Numeric code assigned to the block. Allowed values: from 00 to 99 Default value: -- (the block won’t be visible in the system)
Page 226: Time Profiles
12.2 T ROFILES As already mentioned in the chapter “The Access Control Service - Time Bands” on page 66, IPervoice system allows to define one or more time bands to limit the access to the building. The main purpose is to perform a centralized management of time bands;...
Page 227 Figure 177: Multi-Server mode – Advanced functions configuration – Time profiles list...
Page 228: Time Profile Door
12.2.1 T ROFILE After entering the door time profile management function, the installer will access a page as shown in Figure 178, used to enter data needed for profile definition. Figure 178: Advanced functions configuration – Adding a new door profile Name Profile name.
Page 229: Time Profile Access
Multi-Server: after changes have been performed, press the button “Confirm” to automatically apply them to all IPervoice servers configured in the Multi-Server system. If one or more servers are disconnected (this state is shown by a red icon in the devices tree), save operations will not be possible.
Page 230: Holidays
Multi-Server: after changes have been performed, press the button “Confirm” to automatically apply them to all IPervoice servers configured in the Multi-Server system. If one or more servers are disconnected (this state is shown by a red icon in the devices tree), save operations will not be possible.
Page 231: Access Profile
12.3 A CCESS ROFILE As already mentioned, also door lock release code and proximity key management can be performed by defining one or more profiles, according to requirements. To access this function, select from the devices tree the item “Access Profiles”. (See Figure 181, if the system in configured in standard mode, or Figure 182 in Multi-Server mode).
Page 232 Figure 183: Advanced functions configuration - Access profile definition As already mentioned, each access profile allows to define a standard behaviour for management of door lock release codes, proximity keys or both. According to selections, one or more passages (doors) can be assigned to the profile;...
Page 233: Access Profiles In Multi-Server Mode
Selected Door for Selection of doors enabled to be opened by a door lock release code. Door Code Selecting the “check-box” on the top of the list, the doors of all devices are enabled, then the ones belonging to a type of devices, and so on. Selected Door for Selection of doors enabled to be opened by proximity keys.
Page 234: Door Profiles
12.4 D ROFILES The third and last profile category concerns doors used to access the building. Two categories can be configured: Door profiles for call modules Door profiles for IP key readers To access the door profiles list, select from the devices tree the item “Door Profiles” as shown in Figure 185 if the system is in standard mode or as in Figure 186 if in Multi-Server mode.
Page 235: Door Profiles Call Module
12.4.1 D ROFILES ODULE Figure 187 shows the page used by the installer to create a new profile or change an existing profile. Figure 187: Advanced functions configuration – Entering call modules door profile The following table describes the field meaning and limits for data input. Code Door profile code, value assigned by the system.
Page 236 Multi-Server: after changes have been performed, press the button “Confirm” to automatically apply them to all the IPervoice servers configured in the Multi-Server system. If one or more servers are disconnected (this state is shown by a red icon in the devices tree), save operations will not be possible.
Page 237: Door Profiles Key Reader
12.4.2 D ROFILES EADER The page used to create and change profiles for IP key readers is similar to the one used for call modules (See Figure 188). Figure 188: Advanced functions configuration – Entering IP key reader door profile The following table describes the field meaning.
Page 238 Multi-Server: after changes have been performed, press the button “Confirm” to automatically apply them to all the IPervoice servers configured in the Multi-Server system. If one or more servers are disconnected (this state is shown by a red icon in the devices tree), save operations will not be possible.
Page 239: External Person Groups
ERSON ROUPS IPervoice system can manage the controlled access to the building also for externals (maintenance men, suppliers, etc.). For an accurate access management, it is possible to define one or more groups, each one composed by respective users. According to requirements, these groups can be specific for firms, service areas, etc.
Page 240 Figure 190: Multi-Server mode - Advanced functions configuration – List of external person group To change an existing group, click on the group name; to create a new one, press the button “Add an external person group”. In the second case, the procedure is composed by two steps: first create the group, then select this group and add the name of externals.
Page 241 REATING A NEW GROUP Figure 192: Advanced functions configuration – Adding an external person group Name Group name, required alphanumeric field. Max. length: 32 characters. Lift associated to If there are one or more Lift interfaces configured in the system (as for External person group example 1039/37), it is possible to specify the blocks and the floors where the access is enabled for that group.
Page 242 REATION OR HANGING A ROUP IN ULTI ERVER Figure 193: Multi-Server mode – Advanced functions configuration – Enter an external person group As described above, to create or change a group in Multi-Server mode, select the server where to start data entering.
Page 243 DDING AMES Figure 194: Advanced functions configuration- Adding an external person To enter identification data for externals, follow the procedure already described for residents (see paragraph “Resident Management“ on page 201). The following table describes fields and references for further details. Last Name Last name, required field.
Page 244: Entering Names In Multi-Server Mode
Used Key code If selected, this means that a proximity key has been assigned to the name. For programming procedure, see paragraph “Key Code Configuration” on page 207. Default value: Not selected Door Code Door lock release numeric code, required field if the user has selected “Used door code”.
Page 245 Figure 195: Multi-Server mode – Advanced functions configuration – Entering external persons Warning: if the user selects a previously entered Access Profile, as described in paragraph 12.2.2 on page 229, all the servers receive its configurations, while if the user selects an “Access Profile Custom”, data concerning Time Profile, Start and End Validity and Suspended, must be manually entered for each server where the user is enabled to operate.
Page 246: User Custom Fields
IPervoice allows to extend External Persons data model with customized information. These data are not relevant for IPervoice system, which will store and associate them to each user defined in the system. To access “User custom fields” management, select the related item from the devices tree, as shown in Figure 196.
Page 247 Press the button “Add new User Custom Field”: the FrontEnd will open the page used to enter/change data, as shown in Figure 197. Figure 197: Advanced functions configuration – Entering Custom fields The following table describes the concerned fields and shows usage limits. Label Custom field identifier, required field.
Page 248: Zones
12.7 Z ONES IPervoice system access control allows to manage also advanced functions concerning restricted access zones. Available features are “anti pass-back” and “counting”, which can be tuned during configuration. Anti pass-back control avoids that a person, just entered in a controlled zone, allows another person to enter, using the same access identity (Key or Door code).
Page 249 Figure 199: Advanced functions configuration - Anti pass-back zone data entering Name Zone name, required field. Max. length: 32 characters Type Zone type. It can be selected from the pull-down menu. Available values: • Anti pass-back: Typical operating mode: if a user enter the zone, he must go out before entering again.
Page 250 Threshold Available in Counting and Both mode; it defines the max. number of users inside the zone. Default value: 10 Doors list List of doors (passages) which can be used as entrance or exit doors. Warning: a door can’t be an entrance and exit door for the same zone.
Page 251: Server Configuration
12.8 S ERVER ONFIGURATION In the main menu, select the item “SRV CONFIGURATION” to access IPervoice server configuration page (Figure 200). Figure 200: Advanced functions configuration - IPervoice Server parameter configuration System date and time additional parameters are configurable. The following table describes their...
Page 252 IP Settings - Net mask used in IPervoice IP network. Subnet mask Default value: 255.255.0.0 IP Settings - Router IP address used by IPervoice server to access Internet, used for the Default router “Call Forwarding” function. Default value: none IP Settings - DNS server IP address for names resolution;...
Page 253 IPerVoice system. Default value: Free DHCP - The two text boxes allow to set start IP address and end IP address, Range assigned to devices by DHCP. Warning: To make changes effective, reboot the IPervoice server. Perform this operation carefully.
Page 254: Server Configuration In Multi-Server Mode
It is suggested not to perform arbitrary operations which could cause malfunction in the system. Figure 201: Multi-Server mode - Advanced functions configuration – iPervoice server parameters setting Only users with System Administrator rights can access the Multi-Server configuration.
Page 255 Press the button “Goto multi server configuration” to access the summary page, which allows to configure a Multi-server system. Figure 202 shows a system already activated; the list contains all the servers present in the configuration and their status. The following table describes information meaning and possible operations.
Page 256 For each server in the list there are also three buttons, used to perform the following operations: Remove the server from the Multi-Server configuration; configuration of devices, groups and users (Resident and External) and all other data needed for the proper operation of the site are kept, in order to be available for standard mode.
Page 257: Software Users Configuration
In the text box under the title bar, enter the IP address of the IPervoice server to be added to the system and press the button “Add” on the right of the box. In the list below, the FrontEnd will enter the new server, showing its name, IP address and operating state.
Page 258: Predefined Users
REDEFINED SERS Each time a new IPervoice system is installed, four users and five profiles with different rights used to operate inside the FrontEnd are automatically created. They are listed in the following table, starting from “User Rights” with less restrictions.
Page 259: Software User
Name of the role. Required field. Max. length: 32 characters User rights configuration List of rights which can be configured in IPervoice system. For each one there is a pull-down menu used to select the allowed operation. Available values: •...
Page 260: Changing The Password
Call module password / Password and password confirmation used to perform some configuring Confirm Call module operations from call modules. Required numeric masked fields. To be valid password they must be identical. Max. length: 8 characters. This data can be accessed and changed only if the user is provided with Installer or System Administrator rights.
Page 261: System Maintenance And Utility Functions
All these operations are performed using the IPervoice FrontEnd, so in the following explanations is assumed that the PC is connected to IPervoice IP network and the user has gained access to the FrontEnd with the internet browser. For details, refer to the chapter “The Frontend” on page 89.
Page 262 Figure 208: System maintenance – System configuration backup – procedure start Configuration data are stored in a compressed file , that the installer must save in a PC folder, as shown in Figure 209 . Once the operation is complete, the display shows the following screen Figure 210.
Page 263: Backup Of System Configuration Data In Multi-Server Mode
It is also suggested to perform a backup after the changes have been made, in order to restore the system if the IPervoice server is replaced. 13.1.1 B...
Page 264: Restore Of System Configuration Data
Figure 213: System maintenance – System configuration restore, backup file selection After the selection, IPervoice will load the file on the server and restore operations will start. At the end, the user is notified about the operation result: to complete the procedure, the last operation to be performed is a complete manual reboot, by switching off and on all the IP system devices.
Page 265: Restore Of System Configuration Data In Multi-Server Mode
13.2.1 R ESTORE OF SYSTEM CONFIGURATION DATA IN ULTI ERVER MODE Even the restore operation in Multi-Server mode introduces one more phase, in order to specify on which servers restore the configuration data. As shown in Figure 215, you can specify whether to perform a total restore (on all servers) or a partial restore (selecting one or more servers).
Page 266 Table 57: System maintenance – Meaning of system consistency data In case of Multi-Server installations the information relating to the others IPervoice servers are also indicated; in this way the operator can verify the state of operation before proceeding to any updates to...
Page 267: Ipervoice Server Upgrade
ERVOICE ERVER PGRADE The upgrade of IPervoice server firmware allows to install new versions of system applications if new functions and improvements to existent features have been released. To perform the procedure the file containing the upgrade must be available on the PC connected to the FrontEnd. In order to access to the section dedicated to server upgrade, select the item “FW UPGRADE”...
Page 268 Figure 219: System maintenance –Server upgrade, FUP selection If the file is valid, the system will be ready for upgrade only after asking the user for a final confirmation: till this moment, the procedure can be interrupted without changing the system status. After confirming by pressing the button “Yes, continue”, the operation cannot be interrupted.
Page 269 Figure 221: System maintenance – Server upgrade, system reboot Warning: once the server reboot is completed, the FrontEnd page is reloaded to inform the user that the operation has been completed. In some cases, the automatic reload is not performed. If this happens, close the browser and reconnect to the FrontEnd.
Page 270: Ip Devices Automatic Upgrade
13.4.1 IP DEVICES AUTOMATIC UPGRADE Once the upgrade is completed, the system asks to reboot the server to make the new firmware active. Once the reboot is completed, the server checks the firmware consistency on main IP devices, then automatically updates them, if needed. With the function “Check system consistency”, contained in the item “FW UPGRADE”...
Page 271: Ipervoice Servers Upgrade In Multi-Server Mode
13.4.2 IP ERVOICE SERVERS UPGRADE IN ULTI ERVER MODE In Multi-Server mode, the operator must indicate on which servers must be installed the firmware upgrade (Figure 223). The default and recommended, provides that the update process is executed on all servers in the system. However in special circumstances, as in the case of a server that has been "suspended", you may need a partial update in order to align all the servers to the same firmware, so it can be ensured the proper functioning of the entire system.
Page 272: Ipervoice Devices Replacement
PDA Phone or a Netbook is mainly used; the procedure is the same as in “Column Devices Configuration” described on page 165. In the second case, the IPervoice server does not need to identify the column devices before their configuration. The programming procedure, if necessary, is performed with the mobile device through the Bluetooth interface or, only for apartment stations, with the “dip-switches”...
Page 273 The third last step concerns the procedure to be performed with the IPervoice FrontEnd and allows to transfer the configuration from the old device to the new one just replaced. Note: The following example will describe the procedure to be used with the FrontEnd, assuming that a call module must be replaced.
Page 274 Warning: After the replacement and the new configuration have been performed, the IPervoice server checks the consistency of the firmware version installed in the new device and updates it automatically, if necessary. During this time, the device will be out of order, as described in the paragraph “IP devices automatic upgrade” on page 270.
Page 275: Column Devices Replacement
13.5.2 C OLUMN DEVICES REPLACEMENT The procedure for replacing a column device, as for example a 4-user decoder (1039/34), consists in the following steps: 1) Installation of the new device instead of the old one. 2) Download of system configuration data to a SmartPhone or another mobile device. 3) Programming with SmartPhone through Bluetooth interface.
Page 276: Adding New Ip Devices
The “StartUp Wizard” on page 97 IPervoice Devices advanced Configuration on page 127 Column Devices Configuration on page 165 So, instead of describing every single case, two examples will be detailed, one for IP devices and the other for column devices, in order to highlight the differences between the two procedures. In both cases, the first step to add a new device is the button “Add …”...
Page 277 Figure 229: System maintenance – Selecting a device to be added Warning: the list always shows all the devices detected by the system. The user must select the device to be added by considering the “Device Type”, but first of all the “MAC Address”, that is the unique identifier of each IP device.
Page 278: Adding New Ip Devices Using Their Mac Address
DEVICES USING THEIR DDRESS IPervoice FrontEnd allows to add new devices also by MAC address. This mode is the only that can be used if DHCP module has been configured in “Blocked” mode (see paragraph 12.8 - “Server Configuration” on page 251 and following) and allows to achieve the operation by entering the device type and its MAC address.
Page 279: Adding New Column Or Apartment Devices
13.6.3 A DDING NEW COLUMN OR APARTMENT DEVICES To add a new column device, in the following example a 4-user decoder (1039/34), first of all identify the IP Gateway to which the decoder must be associated; to do this, search in the devices tree the block and the stair where the gateway has been installed, select it and expand the item “Decoders”: the FrontEnd displays a page as shown in Figure 233.
Page 280: Deleting Devices (And Other System Components)
ELETING OLUMN DEVICES The first step is performed by selecting the device to be deleted from the devices tree of IPervoice FrontEnd: in Figure 234, as an example, there is the list of decoders associated to the “Gateway West Tower”.
Page 281: Deleting Other System Components
If in the system there are other devices or components connected to the device to be deleted, IPervoice informs the user that the operation is impossible, explaining why the deleting operation has not been performed. Warning: the FrontEnd provides details only about the direct cause that prevents from deleting the device.
Page 282: Template Export
13.8 T EMPLATE XPORT The two functions described below allow the installer to load residents and externals data by importing data from a text file. This feature is very useful if many data must be entered or the same information must be entered many times (for ex., the assignment to an access profile).
Page 283: Compiling The Import File
Key code Proximity key identification code. Required field in hexadecimal . Fixed length: 8 characters Access profile ID Identification code assigned by the system to the access profile. Required field, if Door Code or Key Code data have been entered Table 58: System maintenance–...
Page 284: Data Import
13.9 D MPORT The import process is guided by a two steps Wizard. To start the process, select the item “Import data” in “Maintenance” menu. In the displayed page, the user can select the previously compiled file to be imported to the system (Figure 239). Figure 239: System Maintenance –...
Page 285: System Log
13.10 S YSTEM IPervoice system records operating information in an event log. To see this information by the FrontEnd, select the item “Log” from the main menu. Figure 242 displays an example of the summary page, that shows the contents.
Page 286: Customized Log Search
In the menu bar there are some buttons used for the following functions: Log Search It shows search fields used to “filter” the events list saved by IPervoice; for details, see paragraph 13.10.1 on page 286 Delete Log It deletes all the records in the system log. The FrontEnd asks the user for a confirmation before deleting.
Page 287 “Encoder 125” device. For further information, see the paragraph “Automatic Key Code Wizard” on page 192. After selecting the desired search methods, press the button “Search”; the FrontEnd will query the IPervoice server for the events that meet the configured filter criteria.
Page 288: Search In The System Log In Multi-Server Mode
ULTI ERVER In Multi-Server system, the summary page of IPervoice system log is extended to include the logs of all the system servers. In this way the user can easily perform searches, configure filters on all the present servers without changing the window. Figure 244 shows a typical example of search page in Multi- Server mode.
Page 289: Search
“Search by”, then the profile name from the menu “Search”. Figure 246 shows all the extracted names with “Door Access Profile 01” access profile. Click on a name of the list, IPervoice will show the respective page where data can be changed.
Page 290: Search By Last Name
To use this search, select the item “Person last name” and enter the name in the text box near “Search”. The user can enter only some letters of the name, IPervoice will show all users with the name starting with these letters. In the example (Figure 247), there are all the names starting with “S”...
Page 291: Search By Logic Code Or Numeric Code
13.11.4 S EARCH BY OGIC ODE OR UMERIC This search is used instead of topological code mode when the system is configured to operate in Logic or Numeric addressing mode. In the text box enter the code to be searched or part of it. Figure 249: Utility functions –...
Page 292: Search By Door Code
13.11.6 S EARCH BY This option allows to search a user by using the associated door lock release code. To search the user, input all the door lock release code in Search field. Figure 251: Utility functions – Search by door code 13.11.7 S EARCH BY ADGE CODE...
Page 293: Search In Multi-Server Mode
ULTI ERVER When iPervoice is configured to operate in Multi-Server mode, the search page shows on the right the list of the servers where to perform search operations; Figure 253 shows a typical example. Figure 253: Multi-Server mode – Utility functions – Search The user can select one or more servers where to perform the search, according to requirements.
Page 294 Figure 254: Multi-Server mode – Utility functions – Search by last name For servers without results, the text “(no result)” appears on the right of the server name (see Figure 255). Figure 255: Multi-Server mode – Utility functions - No result found...
Page 295: Stand Alone-Frontend Usage (Ipervoice Sa-Fe)
SAGE ERVOICE SA IPervoice allows to configure the system and its devices using the FrontEnd. This can be used in two different modes: the first one, called Server mode, is described in the previous chapters; the second one, called Mobile mode, will be treated in this chapter.
Page 296: Hardware And Software Requirements
14.1 H ARDWARE AND OFTWARE EQUIREMENTS Before installation, check that the PC is provided with the following minimum requirements: Processor: 1 GHz 32-bit (x86 Core Duo) compatible with Microsoft Windows Vista 32-bit (Home Premium) or Microsoft Windows 7 32-bit (Home Premium, Professional or Ultimate) RAM and disk space: 1 Gbyte RAM and 250 Mbyte of available disk space Video card: compatible with Microsoft Windows Vista 32-bit (Home Premium) or Microsoft Windows 7 32-bit (Home Premium, Professional or Ultimate) 1024 x 768 pixel min.
Page 297: Pre-Installation Checks / Updates
It is suggested to disable or configure properly firewall software, if present, in order to use properly IPervoice sa-fe. In case of problems during access with Internet browser, the firewall must be disabled. IPervoice sa-fe software uses an Active-X control inside Internet Explorer browser to communicate with...
Page 298: Ipervoice Sa-Fe Installation
HECKS When the installation has been completed, check that the folder where the application has been installed (for ex., C:\Urmet\IperVoice sa-fe), allows the user a complete access to the application. To check this: Start “File manager” and find the IperVoice sa-fe application folder Click right and select the menu item “Properties”...
Page 299 The first one is a dedicated web server allowing navigation in pages with Internet Explorer browser; the second one allows to store IPervoice system data. If one or both have not been started, the Stand Alone FrontEnd will not be able to work. Services are the following:...
Page 300: Starting The Application
14.5 S TARTING THE PPLICATION If all previously described steps have been successful, IperVoice sa-fe is ready to be used. There are two different ways to start the application: Select the item “SWITCH TO MOBILE” from IPervoice FrontEnd main menu Double click on the icon “Urmet”...
Page 301: Switching To Mobile Mode (Local Mode)
WITCHING TO OBILE OCAL After selecting from the FrontEnd menu the item “SWITCH TO MOBILE”, IPervoice asks the user to confirm operating mode change (Figure 260). If the answer is yes, it starts all operations needed to launch IperVoice sa-fe.
Page 302 Mobile mode (IperVoice sa-fe will be activated) However, after synchronization, it is possible to access FrontEnd on IPervoice server; to avoid losing changes performed with IperVoice sa-fe, IPervoice server database will be read only. This condition is indicated by the following message: Figure 263: Stand Alone FrontEnd usage –...
Page 303: Back To Server Mode (On-Line Mode)
Server mode. To do this, select the item “SWITCH TO SERVER MODE” from IperVoice sa-fe main menu. The user must confirm by pressing the button “Yes” in the dialog window shown in Figure 266.
Page 304: The Main Menu
14.6 T IperVoice sa-fe main menu is a subset of the one available on IPervoice FrontEnd. The following table describes the available functions and their meaning. REFRESH It executes the forced update of page contents. SEARCH It activates the search functions available in IPervoice, for example: search of a resident or a device by topological or logic code, by key code and so on.
Page 305: Adding And Configuring New Ip Devices
From the devices tree, select the item “New device”; the Stand Alone FrontEnd will show a page similar to Figure 269, which contains the previously added devices or an empty list, if no additions have been performed yet. The MAC address, which identifies uniquely an IP device, is written on the back side of all IPervoice devices.
Page 306 Figure 269: Stand Alone FrontEnd usage – Adding new IP devices By clicking on “Add new devices”, the user will be asked to select, in the dialog window shown in Figure 270, the device type and to enter the MAC address. When the system goes back to Server mode, this MAC address will allow the system to find the new module and configure it as specified.
Page 307: Column Devices Configuration Using Ipervoice Sa-Fe
ONFIGURATION USING OICE SA One of the most useful functions of IperVoice sa-fe is the capability to configure column devices without using an external PDA device (See chapter “Column Devices Configuration - System Data Download to PDA and Smartphone device“ on page 168 and following). In order to use this feature, the PC where the Stand Alone FrontEnd is installed must be equipped with a Bluetooth interface, used to communicate with the dongle 1039/56 connected to the column devices to be programmed.
Page 308 Figure 272: Stand Alone FrontEnd usage – 4-user decoder configuration page By pressing the button “Program via BT”, a new dialog window will appear (shown in Figure 273). If the Bluetooth device has not been acquired yet, press the button “Search” to start the identification procedure (“Bluetooth Programming Interface identification”...
Page 309: Bluetooth Programming Interface Identification
Figure 274: Stand Alone FrontEnd use – Bluetooth programming result 14.9.2 B LUETOOTH ROGRAMMING NTERFACE IDENTIFICATION If the Bluetooth device 1039/56 is used for the first time, the identification procedure is automatically activated. Figure 275 shows the procedure to be used in this situation: the user will be informed that a new Bluetooth device has been detected and asked to confirm if this one can be added to the list.
Page 310: Checking Configuration Data
Figure 276: Stand Alone FrontEnd usage – System data reading via Bluetooth If read information are different from IPervoice sa-fe local database, the user will be informed and inconsistent parameters will be underlined in red. Figure 277 shows a typical example.

urmet domus IPervoice Installation Manual

1 Ipervoice in Brief

2 Digital Audio/Video Transmission

3 General Characteristics

4 System Architecture

5 Ipervoice Services

6 Technical Prescriptions

7 Installation Prescriptions

8 Ipervoice Configuration

9 Ipervoice Devices Advanced Configuration

10 Column Devices Configuration

11 Apartments Configuration

12 Advanced Functions Configuration

13 System Maintenance and Utility Functions

14 Stand Alone-Frontend Usage (Ipervoice Sa-Fe)

Quick Links

Need help?

Questions and answers

Related Manuals for urmet domus IPervoice

Summary of Contents for urmet domus IPervoice
