S
ETUP
4. S
ETUP
AC Power
Each Vesuvio II has a fixed power supply that works with an input voltage of either 120 VAC, 60 Hz or 230
VAC, 50 Hz, depending on the specific model. To determine the power requirements for each Vesuvio II,
refer to the label affixed to the product. You can also refer to the Technical Specifications chart in this
manual.
The listed current rating indicates the maximum current draw during normal operation. For more
information, download Sizing Circuit Breakers from the Chauvet website: www.chauvetprofessional.com.
.
•
Always connect the product to a protected circuit (circuit breaker or fuse). Make
sure the product has an appropriate electrical ground to avoid the risk of
electrocution or fire.
•
To eliminate unnecessary wear and improve its lifespan, during periods of non-
use completely disconnect the product from power via breaker or by unplugging
it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
AC Plug
The Vesuvio II comes with a power input cord terminated with a Seetronic Powerkon IP65 connector on
one end and an Edison plug on the other end (U.S. market). If the power input cord that came with your
product has no plug, or if you need the change the plug, use the table below to wire the new plug.
Connection
AC Live
AC Neutral
AC Ground
Resetting the Breaker
This product is equipped with a resettable circuit breaker. If the breaker trips, all sections of this product will
lose power.
1.
Remove the power cord from main power.
2.
Allow unit to cool for 15 minutes.
3.
After 15 minutes, you may attempt to reset the breaker by pressing the button with your finger.
4.
Plug the product's power cord into the power outlet and continue using as recommended.
DMX Linking
You can link the Vesuvio II to a DMX controller using a 3- or 5-pin DMX connection. If using other DMX-
compatible products with this product, you can control each individually with a single DMX controller.
DMX Personalities
The Vesuvio II uses a 3- or 5-pin DMX data connection for the 15-channel DMX personality.
•
Refer to the Introduction for a brief description of each DMX personality.
•
Refer to the Operation chapter to learn how to configure the Vesuvio II to work in these
personalities.
•
The DMX Values section provides detailed information regarding the DMX personalities.
If you are not familiar with or need more information about DMX standards,
Master/Slave connectivity, or the DMX cables needed to link this product to a
DMX controller, download the DMX Primer from the Chauvet website:
www.chauvetprofessional.com.
Vesuvio II User Manual Rev. 2
Wire (U.S.)
Black
White
Green/Yellow
Wire (Europe)
Brown
Blue
Green/Yellow
Screw Color
Yellow or Brass
Silver
Green
Page 8 of 19
