Chauvet Mini Fogger F-800 User Manual

Optional Controllers

• Timer Remote
• Wireless remote

Power Connections

The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.

Technical Specifications

Power 120V~60Hz AC
Fuse 20mm Glass 7A Fast Blow
Preheat Time
Fog Output
Tank Capacity
Dimensions 315 x 160 x 135mm / 12.4in x 6.3in x 5.3in
Weight
User Information
(Please complete for your records)
Date Purchased: / /
Dealer Stamp:
230V~50Hz AC
20mm Glass 4A Fast Blow
4 minutes
3,000 cu ft per minute
1 Liter / Quart
4kg / 8.8lbs
Serial No:
Model:
F-800 MINI FOGGER
M M M M i i i i n n n n i i i i F F F F o o o o g g g g g g g g e e e e r r r r
F-800
Users Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29 th Ct., Hollywood, Florida, USA, FL 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
European Office:
Unit 18, Hunslet Trading Estate, Leeds, UK
LS10 1BL
Tel: (0113) 276-0755 Fax: (0113) 277-6675
www.ChauvetLighting.com
