Summary of Contents for Monoprice 21792
- Page 1 MONOPRICE Blackbird™ 4K HDBaseT™ Extender Kit P/N 21792 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... - Page 3 INTRODUCTION Thank you for purchasing this Blackbird™ 4K HDBaseT™ Extender Kit! This kit consists of a transmitter and receiver, which allows a 1080p HDMI® signal to be transmitted to distances up to 328 feet (100 meters) and a 4K signal to be transmitted to distances up to 229 feet (70 meters) over a single Cat6 Ethernet cable.
-
Page 4: Customer Service
If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-... -
Page 5: Product Overview
PRODUCT OVERVIEW Transmitter 1. RS232 MODE Switch: Selects the RS232 mode. The CTRL position is the normal operating mode where RS232 data is passed back and forth with the receiver. The two UPDATE positions are for updating the transmitter's firmware using one of two FIRMWARE UPDATE methods. - Page 6 8. HDMI IN Port: HDMI® port for connecting the HDMI cable from the video source device. 9. HDBT OUT Jack: RJ45 jack for connecting the Ethernet cable to the receiver. 10. ETHERNET Jacks: RJ45 jacks for connecting to an existing Ethernet network and/or devices.
-
Page 7: Sample Connection Diagram
5. RS232 Connector: Connector for the included 3-pin to DB9 RS232 cable. 6. IR IN Jack: 3.5mm jack for connecting the IR receiver. 7. IR OUT Jack: 3.5mm jack for connecting the IR transmitter. 8. HDMI OUT Port: HDMI port for connecting the HDMI® cable to the video display. 9. -
Page 8: Installation
INSTALLATION Perform the following steps to install this HDBaseT™ Extender Kit. 1. Ensure that all equipment to be connected is powered off and unplugged from its power source. 2. Place the transmitter and receiver in their intended locations. Use the included mounting brackets to secure the units in place, as desired. -
Page 9: Firmware Update
source device. Alternatively, if you want to control the remote display from the source end, plug the include IR transmitter into the IR OUT jack on the receiver, then position the IR emitter where it can transmit IR signals to the IR "eye" on the display. 10. -
Page 10: Technical Support
TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates. -
Page 11: Regulatory Compliance
Modifying the equipment without Monoprice’s authorization may result in the equipment no longer complying with FCC requirements for Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense. - Page 12 This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Blackbird™ is a trademark of Monoprice Inc. HDBaseT™ and the HDBaseT Alliance logo are trademarks of the HDBaseT Alliance.
