- Page 1 5.8GHz Wireless Audio/Video Extender With Built-in Remote Control Extender PID: 10247 OWNERS MANUAL...
-
Page 2: Table Of Contents
Troubleshooting Specifications INTRODUCTION Thank you for purchasing the Monoprice 10247 Wireless Audio/Video Extender! For best results please read this manual carefully, paying extra attention to the safety warnings. Keep this manual in a safe place for future reference. The Monoprice 10247 Wireless Audio/Video Extender adds wireless flexibility to your home audio and video system. -
Page 3: Features
Compatible with 38KHz and 56KHz IR signals PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. ... -
Page 4: Safety Warnings
SAFETY WARNINGS To avoid personal injury or damage to your equipment, please adhere to the following safety guidelines: 1. Do not expose this device to water or moisture of any kind. Do not place objects filled with liquids on or near this device. 2. -
Page 5: Connections And Controls
CONNECTIONS AND CONTROLS The following diagrams identify the various connections and controls on the Transmitter and Receiver units of the Extender: Receiver Transmitter & Receiver Transmitter (Rear view) Accessories Infrared Adaptor Extender Transmitter and Receiver 1. RF Channel Selector 2. 5.8 GHz Antenna 3. -
Page 6: Installation
INSTALLATION 1. Using one of the included video cables, connect the yellow, red, and white RCA plugs to the corresponding jacks on your DVD player (or other video source device). 2. Plug the other end of the video cable into the RCA jacks on the back of the Transmitter unit. - Page 7 4. Plug the DC connector from one of the AC adapters into the DC 5V input on the back of the Transmitter unit. Plug the other end into a 100-120 VAC/60Hz power outlet. 5. Using one of the included video cables, connect the yellow, red, and white RCA plugs to the corresponding jacks on your TV.
-
Page 8: Operation
OPERATION 1. Use the Channel Selection switch on the Transmitter to select one of the four wireless channels. Set the Channel Selection switch on the Receiver to the same channel. Transmitter Receiver Channel selection button must be set to the same channel on both the transmitter &... - Page 9 For best performance position the antennas so that they are face-to-face (the side with the dot). Receiver Transmitter Receiver IR Receiver For best IR reception performance the Receiver unit should be positioned so that the front is slightly ahead of the Side View Television screen.
- Page 10 For best results, the remote control should be positioned within 15 degrees of the IR sensing window on the Receiver unit. Additionally, it should be no closer than 1 foot and no further than 15 feet. IR sensor window Remote Control Receiver Distance not less than 1 foot and no more than 15 feet...
-
Page 11: Troubleshooting
TROUBLESHOOTING No picture or sound a) Check the power on/off switches on the Transmitter, Receiver, source device, and TV. b) Make sure the power plug and signal cables are pushed all the way in. c) Check that the transmitter & receiver are set to the same wireless channel. d) Make sure that all cables are connected as per the installation instructions. -
Page 12: Specifications
SPECIFICATIONS TRANSMITTER Output Level 13dBm (complies with CE) Operating Frequencies 5790, 5828, 5847, and 5866 MHz Modulation FM (Video and Audio) Video Input Level 1.0 V p-p Audio Input Level 1.0 V p-p S-Video Input Level Y:1Vpp, C:288mV Video Input Impedance 75 ohm Audio Input Impedance 2K ohm...
