SIIG JU-000071-S1 Quick Installation Manual

Usb 2.0 to vga adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Introducing the USB 2.0 to VGA Adapter
The USB 2.0 to VGA allows you to connect a monitor, LCD
or projector to your PC or notebook and use it as an
extended desktop or as a larger/different display for your
main screen.
Features and Benefits
•
Compliant with USB specification, revision 2.0
•
Supports suspend and wake-up modes
•
Functionality: primary, extended or mirror
•
Resolution: up to 1680 x1050 @ 32-bit color
System Requirements
•
Pentium
•
An available USB 2.0 port
•
Windows
(32-/64-bit) / Server 2003 (32-bit) / 2000
Serial Number Sticker
For future product return or exchange, this serial number
is required. Please keep it for your reference.
04-0473C
USB 2.0 to VGA Adapter
Quick Installation Guide
4 1.5GHz or equivalent PC
®
7 (32-/64-bit) / Vista (32-/64-bit) / XP
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JU-000071-S1 and is the answer not in the manual?

Questions and answers

Related Manuals for SIIG JU-000071-S1

Summary of Contents for SIIG JU-000071-S1

  • Page 1 USB 2.0 to VGA Adapter Quick Installation Guide Introducing the USB 2.0 to VGA Adapter The USB 2.0 to VGA allows you to connect a monitor, LCD or projector to your PC or notebook and use it as an extended desktop or as a larger/different display for your main screen.

  • Page 2: Package Contents

    Package Contents • USB to VGA • Driver CD • Quick installation guide Layout VGA port USB port Figure 1: USB 2.0 to VGA Layout Installation It is recommended that you install the driver Before connecting the USB 2.0 to VGA to the computer. Windows 7 (32-/64-bit) Insert the driver CD.
  • Page 3 At User Account Controls, click Yes. Click Next, Select I accept the terms of the license agreement, click Next. Select Yes, I want to restart my computer now, then click Finish. Connect your second monitor to the USB 2.0 to VGA and turn it on.
  • Page 4 When Windows resumes, plug the USB 2.0 to VGA into the computer. Click Install two times. Note: Some systems will go to 8-bit resolution after installing the driver. Please reset it back to your normal resolution. Windows XP (32-/64-bit) Insert the driver CD. Click Start, then Run, type D:\setup.exe, click OK.

  • Page 5: Windows 2000

    Windows Server 2003 (32-bit) Insert the driver CD. Click Start, in the Start Search box, type D:\setup.exe, click OK. (Change D: to match your CD-ROM drive letter) Click Next, select I accept the terms of the license agreement, click Next. Click Install, then click Finish.
  • Page 6 Connect your second monitor to the USB 2.0 to VGA and turn it on. When Windows resumes, connect the USB 2.0 to VGA to the computer and the drivers will install automatically. Restart Windows to complete the installation. To Verify Windows Installation Right click Computer or My Computer, then click Manage.

  • Page 7: Display Utility

    Display Utility After successful driver installation a display utility will appear in the lower right portion of the taskbar. This utility allows you to quickly change the settings and resolutions for the USB 2.0 to VGA. Access the menu by right clicking the icon.

  • Page 8: Frequently Asked Questions

    Frequently Asked Questions Why won't my DVD player work when I move it over to the extended display? Some DVD playback software packages do not support playing on a second display adapter. How come my video will not play on Media Player if I move it over to the extended desktop? Check that you have moved the Media Player window completely over to the extended screen.
  • Page 9 Blank Page...
  • Page 10 Blank Page...

  • Page 11: Technical Support And Warranty

    You can also submit questions online and a technical support analysts will promptly respond. SIIG offers a 5-year manufacturer warranty with this product. Please see our web site for more warranty details. If you encounter any problems with this product, please follow the procedures below.
  • Page 12 Fremont, CA 94538-3152, USA Ph: 510-657-8688 USB 2.0 to VGA Adapter is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
