SIIG JJ-CFTS11 Quick Installation Manual

Cf to serial adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Features and Benefits

16-bit CompactFlash interface
•
Compatible with 16-bit PCMCIA Card (via a
•
CF-to-PCMCIA adapter)
Supports RS232E serial port specification
•
Supports data rate up to 115,200 bps
•
Works with modems, PDAs, Pocket PCs and
•
other serial devices

System Requirements

For Desktop or Notebook PC with a PCMCIA slot:
Windows 98/98SE/ME/2000/XP/Server
•
2003
CF-to-PCMCIA adapter (not included)
•
CD-ROM (for driver installation)
•
04-0331A
CF to Serial Adapter
Quick Installation Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JJ-CFTS11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG JJ-CFTS11

Summary of Contents for SIIG JJ-CFTS11

  • Page 1 CF to Serial Adapter Quick Installation Guide Features and Benefits 16-bit CompactFlash interface • Compatible with 16-bit PCMCIA Card (via a • CF-to-PCMCIA adapter) Supports RS232E serial port specification • Supports data rate up to 115,200 bps • Works with modems, PDAs, Pocket PCs and •...

  • Page 2: Package Contents

    For Pocket PC: Windows CE 3.0 or later • Pocket PC 2000 or later • Built-in CF slot • Package Contents (1) CF to Serial adapter • (1) CF to Serial cable • (1) Driver CD • This quick installation guide •...
  • Page 3 Layout CF to Serial Cable CF to Serial flat connector CF to Serial 9 Pin Adapter Connector Figure 1. CF to Serial Adapter layout Note: When connecting the CF to Serial Cable to the CF to Serial Adapter, make sure the triangle on the CF to Serial flat connector is pointing up.

  • Page 4: Software Installation

    Software Installation Windows Driver Installation Windows 98: The CF to Serial Adapter must be inserted into the computer before booting up Windows 98 otherwise it will not be detected by the system. Insert the CF to Serial Adapter into the CF-to- PCMCIA adapter (not included), then insert the unit into the system's PCMCIA slot.
  • Page 5 At the Add New Hardware Wizard, click Next. Select Search for the best driver for your device. (Recommended) and click Next. Insert the driver CD, check CD-ROM drive, uncheck the other boxes, then click Next. Click Next, at the Insert Disk box click OK. Insert your Windows 98 Installation CD, then click OK.
  • Page 6 Windows 2000: Boot up to Windows. Insert the CF to Serial Adapter into the CF-to-PCMCIA adapter (not included), then insert the unit into the system's PCMCIA slot. At the Found New Hardware Wizard, click Next. Select Search for a suitable driver for my device (Recommended) and click Next.
  • Page 7 Click Continue anyway. Our driver has been thoroughly tested in Windows for stability and compatibility. Click Finish. Restart Windows to complete the installation. Verify Windows Installation Check Device Manager to verify successful driver installation. Windows 98/98SE/ME: From the main desktop, right click My Computer, then click Properties.

  • Page 8: Technical Support

    THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE Fremont, CA 94538-3152 CF to Serial Adapter is a trademark of SIIG, Inc. All other names used in this publication are for identification only and may be trademarks of their respective companies. April, 2004...
