M2Tech
YOUNG M
III
K
DIGITAL-TO-ANALOG CONVERTER AND PREAMPLIFIER
REVISION 1.0 – SEPTEMBER 2017
www.m2tech.biz
®
12) Bluetooth
module receiver antenna. Keep this antenna clear from metal shields or
covers.
13) Power mode switch. Enables and disables immediate operation as soon as power is
applied.
14) Power supply input. Connect the connector from the stock 15V-1.2A adaptor or from
the Van Der Graaf MkII. 5.5/2.1mm jack with positive on tip.
15) Trigger output. Connect to the trigger input of any other device accepting 12V
.
DC
Female 3.5mm jack.
Copyright © 2017, M2Tech Srl
12
