Dear customer,
We are delighted that you have decided to purchase the PowerBox BaseLog
RC power supply unit from our range. We wish you every success with your
new PowerBox BaseLog, and hope you have loads of fun with it.

1. PRODUCT DESCRIPTION

The PowerBox BaseLog is a modern power supply system containing all
the electronic components required to power modern receivers, servos and
models. All the components which are essential to a reliable power supply,
i.e. ICs, micro-controllers and electronic circuits, are duplicated. The unit
incorporates some of the latest electronic innovations, including a graphic
OLED screen and the ability to transmit telemetry data from the PowerBox
BaseLog to transmitters of various makes. The net result is that the unit
provides unprecedented facilities for monitoring airborne batteries.
FEATURES:
Dual regulated output voltage

User-selectable output voltage of 5.9 V or 7.4 V, software-variable using

the SensorSwitch
Informative graphic OLED screen with a resolution of 128 x 64 pixels

Facility for connecting Futaba*, M-Link, Spektrum, HoTT and Jeti down-

link bus systems
Direct transmission of both batteries' voltage + capacity to the transmitter

Voltage display for each battery

Residual capacity display for both batteries

Minimum value memory for both batteries

Large heat-sink area for high regulator performance

Supports all currently used battery types: LiPo/LiIon, NiMH/NiCd, LiFePo

Suppression of possible servo feedback currents

Various patch-leads (MPX / JR / Futaba, MPX / MPX) available, allowing

the use of all receiver types
This range of functions makes the PowerBox BaseLog the ideal battery ba-
cker for large model aircraft with wingspans in the range 2.0 m to 2.6 m, as
well as for helicopters and gliders.
*with the Teleconverter, Order.No: 5600
