Non-Proprietary Security Policy, Version 1.0
Network interface bay – For network interface module (for BRI, PRI, and V.35/RS-449/RS-530
connection)
Balanced Audio connector – Input for mixed or powerful microphones or output for external audio
equipment
VCR/DVD connector – Play VCR/DVD content into calls or record the calls to VCR/DVD
Serial ports – RS-232 port for touch panel, camera control, or other RS-232 device
Monitor 1Y and C – output for main monitor
S-Video connector – Input to system from camera or output for S-Video monitor
Audio connector –Output to external speaker
VGA connector – Input to system for ImageShare II and computer VGA, or outputs to VGA monitor and
projector
LAN connector – For IP calls, VSX Web, and remote management
Conference link connector – For microphone pod, SoundStation VTX 1000, or Visual Concert VSX
IR Sensor – Input from external IR sensor
Analog phone connector – For analog phone line
Camera 1 control connector – For camera 1 PTZ control
Camera 1Y and C – Input from main camera
IR Sensor – Input from IR sensor
Power button – Controls power and provides system status
LED – LEDs indicate system status
Power connector – For power cord
Polycom VSX 3000, VSX 5000, and VSX 7000s
© 2007 Polycom, Inc. -
This document may be freely reproduced and distributed whole and intact including this Copyright Notice.
June 15, 2007
Page 14 of 23
