Polycom VSX7000s Quick Install Manual
Video conference unit
Hide thumbs
Also See for VSX7000s:
- Features and benefits (4 pages) ,
- Brochure & specs (2 pages) ,
- Integrator's reference manual (418 pages)
Related Manuals for Polycom VSX7000s
Summary of Contents for Polycom VSX7000s
-
Page 1: Quick Install Guide
Polycom VSX7000s Video Conference Unit Quick Install Guide Manitoba First Nations SchoolNet March 14, 2006 Author: Theodore Baschak Version: 1.0... - Page 2 Introduction Whats in the box? Polycom Video Conference unit ✔ subwoofer/power unit ✔ microphone ✔ remote control ✔ power cord ✔ svideo cable ✔ microphone cable ✔ network cable ✔ documentation CD ✔ accessories ✔ This video conference unit will allow you to: conduct teacher interviews remotely ●...
- Page 3 Step 1 – Connect Polycom Video Conference Unit I'm your friendly neighborhood subwoofer and power supply! ON/OFF Switch I'm a Microphone! I'm a network cable! Plug me into I'm a TV with the switch in SVIDEO inputs! Step 3!! The only things to watch out for here is that you've got the TV plugged into the correct output (the one marked [ 1 ] on the back of the unit as show with the GREEN arrow).
- Page 4 Ports 10 and up should be free Step 3 – Plug Polycom into Switch/Router If you have the fortigate unit you want to plug the network cable from the video conference unit into one of the available ports shown below:...
-
Page 5: Step 4 - Make A Test Call
Step 4 – Make a test call Power on the unit and let it initialize. ● When its done it will be at a screen that says “Place a Call” on the top, a ● small view of whats visible to remote viewers on the right, a field to enter a number to call, buttons for the address book (Directory) and a list of Recent calls.
