Non-Proprietary Security Policy, Version 1.0
FIPS 140-2 Logical Interface
Power
The following is the list of ports and interfaces for the VSX 7000e system and Figure 8 below shows the ports on
module's back panel.
Network interface bay – For network interface module (for BRI, PRI, and V.35/RS-449/RS-530
connection)
VCR/DVD connector – Play VCR/DVD content into calls or record the calls to VCR/DVD
Audio connector – Input to system from ImageShare II and computer, or outputs to external speaker
Serial ports – RS-232 port for touch panel, camera control, or other RS-232 devices
S-Video connector – Input to system from camera or output for S-Video monitor
Analog phone connector – For analog phone line
Camera 1 control connector – For camera 1 PTZ control
VGA connector – Input to system for ImageShare II and computer VGA, or outputs to VGA monitor and
projector
LAN connector – For IP calls, VSX Web, and remote management
Conference link connector – For microphone pod, SoundStation VTX 1000, or Visual Concert VSX
IR Sensor – Input from IR sensor
Power button – Controls power and provides system status
LED – LEDs indicate system status
Power connector – For power cord
