Simultaneously pressing the FREQ button and AUDIO
button will power the transmitter on and off.

UP/DOWN ARROWS

The Up and Down arrows are used to select the operat-
ing frequency, adjust the audio level, or set the Compat-
ibility Mode.
Pressing both arrows simultaneously locks the control
panel buttons so they can only be used to display
current settings. A capital "L" appears in the display to
indicate the controls are locked.
To unlock the control panel, press both arrows again.
"unL" appears in the display to indicate that the control
panel is unlocked.
Frequency Agile UHF Ultra-Miniature Belt-Pack Transmitter
The lock status, locked or unlokced, is preserved even if
the unit is shut off.

ANTENNA

The fixed flexible cable antenna is supplied with the
transmitter. This antenna is cut to the 1/4 wavelength of
the center of the frequency block (the frequency range)
of the transmitter.
BATTERY COMPARTMENT AND THUMB
SCREW
The large knurled brass thumbscrew is used to release
or secure the Battery Compartment Cover Plate, allow-
ing access to the battery.
