Page 1: User Manual
PROTECT YOUR WARRANTY This unit must be installed by a registered, licensed installer as required by Government regulations. Wi-Fi Reverse Cycle Split System Air Conditioner USER MANUAL Model Number AK-9000WIFI Model Number AK-12000WIFI Model Number AK-18000WIFI N13275... -
Page 2: Table Of Contents
Contents Important Safety Instructions Product Overview Getting Started Remote Control Operation Operation Modes Manual Operation Wi-Fi Control Troubleshooting Guide Cleaning and Maintenance After Sales Support 1300 886 649 | info@tempo.org... -
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT! This unit comes with separate installation instructions for use by an appropriately qualified installer. Do not try to install the air conditioner on your own; doing so will expose you to danger and void the warranty. It is your responsibility to ensure the unit is installed by a qualified technician, who should check that it is earthed in accordance with applicable regulations and install a thermomagnetic circuit breaker. - Page 4 Important Safety Instructions (Cont.) Usage Conditions and Restrictions • Domestic use: This appliance has been made for air conditioning domestic environments and may also be used by expert or trained users in shops, light industry environments and farm houses. • Intended purpose: This appliance should only be used as described in this manual.
- Page 5 Important Safety Instructions (Cont.) • Air inlet/outlets and wind vanes: Never insert a finger, stick or similar object into these openings. As a fan is rotating at a high speed, it will cause injury and/or damage to the appliance. Do not touch the swinging wind vanes.
-
Page 6: Product Overview
Product Overview Scope of Delivery Indoor unit (Fig. 1) Fig. 1 Front panel Air filter LC display and signal receptor Louvres Supply cord Remote controller (with 2 AAA batteries and wall holder) Outdoor unit (Fig. 2) Drain hose Refrigerant gas/ liquid pipe Cut-off valve 10 Air outlet cover... - Page 7 Product Overview (Cont.) Remote Control All available buttons on the remote control are described in detail in the “Remote Control Operatioon” section on pages 10–16. Note: Figures, graphics and descriptions throughout this user manual are for explanatory and illustrative purposes only and may differ slightly from the appearance of the product purchased.
-
Page 8: Getting Started
Getting Started Before First Use To prevent injury and property damage, make sure you read and understand the instructions and advice listed below before operating the air conditioner. • Make sure the indoor and outdoor units of the air conditioner have been installed by a professional installer and the earth wire is connected safely. - Page 9 Getting Started (Cont.) Remote Control Operation • Remove the cover from the battery compartment at the back of the remote control by sliding it off the housing. • Insert 2 new AAA (1.5V) batteries (included), ensuring the polarities (+/-) match the markings inside the compartment. •...
-
Page 10: Remote Control Operation
Remote Control Operation Remote Control Buttons and Functions Descriptions Remote Control Outside Note: The buttons on the outside of the remote control are only effective when the surface cover is closed. Note: • Remote control illustrations are for explan- atory purposes only and may differ slightly depending on the model purchased. - Page 11 Remote Control Operation (Cont.) Buttons Descriptions (Remote Control: Outside) ON/OFF button • Press this button to start of stop the unit. Note: Pressing this button will clear any previously set functions, such as the timer or sleeping function. SPEED button •...
- Page 12 Remote Control Operation (Cont.) Remote Control Inside Note: The buttons on the inside of the remote control are only effective when the surface cover is open. After Sales Support 1300 886 649 | info@tempo.org...
- Page 13 Remote Control Operation (Cont.) Buttons Descriptions (Remote Control: Inside) ON/OFF button • Press this button to start of stop operation. Note: Pressing this button will clear any previously set functions, such as the timer or sleeping function. MODE button • Press this button to select the operation mode, as follows: SPEED button •...
- Page 14 Remote Control Operation (Cont.) TIMER button This button allows you to program the timer for automatic switch on/off. • When the unit is switched on, press this button to set the OFF-timer. When the unit is switched off, press this button to set the ON-timer. •...
- Page 15 Remote Control Operation (Cont.) 10 DISPLAY button • In display mode, press this button once to turn off the wall unit display, press it again and the display will show the ambient and setting temperature after flashing for about five seconds. Note: This is a convenient feature if you do not want the wall unit display illuminated, or just who want to check ambient and set temperatures.
- Page 16 Remote Control Operation (Cont.) 14 SPOT SWING button • Press this button to adjust the airflow direction, the horizontal wind direction vanes will rotate automatically. • When the airflow is directed to where you want it, press it again to stop rotation of the horizontal wind direction vanes.
-
Page 17: Operation Modes
Operation Modes Automatic Mode In this mode the unit automatically adjusts the temperature according to the room temperature to ensure and maintain comfortable conditions. The temperature is automatically set to 24°C. Press the MODE button to select Auto mode. • Press the SPEED button to select the fan speed from the following •... - Page 18 Operation Modes (Cont.) Fan Mode In Fan mode only the air conditioner’s ventilation will be working. Setting a temperature in this mode will be ineffective. (However, you are able to adjust the fan speed in other modes using the SPEED button.) •...
-
Page 19: Manual Operation
Manual Operation Manual Stopping and Starting When the remote control does not work or cannot be found, please follow the steps below to start or stop operation. Lift the top cover open and locate the AUTO button in the position below. •... -
Page 20: Wi-Fi Control
Wi-Fi router is switched on and your phone is connected to your home Wi-Fi network. • On your mobile device, tap on the AKAI Home App, it will take you to the Device List. This is where your air conditioner will appear once the set-up has been configured. - Page 21 Wi-Fi Control (Cont.) • Tap ADD DEVICE, then enter the password to your home Wi-Fi network. • On the air conditioner’s remote control, press the HEALTH button 8 times, every press of the button will be followed by a short beep – do not pause for more than 2 seconds in between pressing the button.
- Page 22 This is very important, otherwise your mobile device cannot communicate with the air conditioner. • On your mobile device, tap on the AKAI Home App, it will take you to the Device List. • Tap on the icon for your air conditioner and you will be taken to its home page.
- Page 23 Wi-Fi Control (Cont.) • On/off: Tap the POWER button to switch on the air conditioner, if it is switched off, or to switch it off if you left it on accidentally. If switching off, you may be prompted to confirm. When shutting down, you will have an option to run the iClean or Anti-Fungus functions (see page 15 for more).
- Page 24 Wi-Fi Control (Cont.) • Mode: To change the operation mode, tap the MODE button and then swipe up or down to select the appropriate mode from Cooling, Heating, Dry, Fan or Auto. Tap OK to confirm your selection. The adjusted value will be displayed on the control page.
- Page 25 Wi-Fi Control (Cont.) • Sleep curve: To program different temperatures for the duration of your sleep time, tab the SLEEP CURVE button, then tap EDIT. • You can program different temperatures at different points of time during your rest time. The sleep curve is divided into 10 minute segments. You can also set other parameters, such as fan speed and quiet operation.
- Page 26 Wi-Fi Control (Cont.) • Timer: Tap this button set a TIMER so the unit comes on or turns off at a set time. After Sales Support 1300 886 649 | info@tempo.org...
-
Page 27: Other Functions
Wi-Fi Control (Cont.) Other functions Naming, deleting or adding an air conditioner Tap the three “More” dots in the top right corner of the air conditioner’s home page. You can then select to add a device, display the device list or update software. - Page 28 21. More information For more information on the AKAI Wi-Fi Reverse Cycle Split System range of air conditioners, scan the QR code below, which will take you to the AKAI website (www.akai.com.au). After Sales Support 1300 886 649 | info@tempo.org...
-
Page 29: Troubleshooting Guide
Troubleshooting Guide If you experience problems with your air conditioner, check for solutions in the table below. If the problem cannot be solved by simple adjustments, call the after sales support line, or contact a licensed air conditioner technician. Problem Possible cause and solution General air conditioner problems Air conditioner does... - Page 30 • If the air conditioner is correctly connected to the wireless router, the Wi-Fi indicator light on the display should be on. Remote control via Restart your AKAI Home App or reconnect your smartphone does smartphone with the wireless router. not work, despite correct connection.
-
Page 31: Cleaning And Maintenance
Cleaning and Maintenance Periodic cleaning and maintenance is essential for keeping your air conditioner in good condition and working efficiently. CAUTION! Before carrying out any maintenance, make sure the air conditioner is turned off at the power socket outlet. Cleaning the Indoor Unit Turn off and unplug the air conditioner. - Page 32 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649 before returning it to the store for a refund.
