Page 1: User Manual
PROTECT YOUR WARRANTY This unit must be installed by a registered, licensed installer as required by Government regulations. Fixed Speed Reverse Cycle Split System Air Conditioner USER MANUAL Model Number AK-9000-F N13275... -
Page 2: Table Of Contents
Contents Important Safety Instructions Product Overview Getting Started Instructions Troubleshooting Guide Cleaning and Maintenance After Sales Support 1300 886 649 | info@tempo.org... -
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT! This unit comes with separate installation instructions for use by an appropriately qualified installer. Do not try to install the air conditioner on your own; doing so will expose you to danger and void the warranty. It is your responsibility to ensure the unit is installed by a qualified technician, who should check that it is earthed in accordance with applicable regulations and install a thermomagnetic circuit breaker. - Page 4 Important Safety Instructions (Cont.) Usage Conditions and Restrictions • Domestic use: This appliance has been made for air conditioning domestic environments and may also be used by expert or trained users in shops, light industry environments and farm houses. • Intended purpose: This appliance should only be used as described in this manual.
- Page 5 Important Safety Instructions (Cont.) • Keep clear: Do not climb onto or place any objects on top of the outdoor unit. Supervise children to ensure they do not sit on the outdoor unit. • Air inlet/outlet: Never insert a finger, stick or similar object into these openings.
-
Page 6: Product Overview
Product Overview Indoor unit (Fig. 1) Indoor Unit Front panel Fig. 1 Air filter LCD display and Air inlet signal receiver Louvres Supply cord Remote controller Outdoor unit (Fig. 2) Drain hose Refrigerant gas/ liquid pipe Air outlet Cut-off valve 10 Air outlet cover Outdoor Uni t Fig. -
Page 7: Remote Control
Product Overview (Cont.) Remote Control Remote Control (Fig. 3) ON/OFF Fig. 3 FRESH SPEED STRONG FEEL DUST TIMER DISPLAY UP / DOWN 10 CLEAN 11 MODE 12 SLEEP 13 SWING 14 HEALTH 15 ANTI-MOULD Please see the “Instructions” section for a description of all buttons and functions. -
Page 8: Getting Started
Getting Started Before First Use To prevent injury and property damage, make sure you read and understand the instructions and advice listed below before operating the air conditioner. • Make sure the indoor and outdoor units of the air conditioner have been installed by a professional installer and the earth wire is connected safely. -
Page 9: Remote Control Operation
Getting Started (Cont.) Remote Control Operation Inserting Batteries • Remove the cover from the battery compartment by sliding it off the housing. • Insert 2 new AAA (1.5V) batteries (included), ensuring the polarities (+/-) match the markings inside the compartment. •... -
Page 10: Instructions
Instructions Remote Control Buttons and Function Descriptions Fig. 3 ON/OFF button Press this button to start the air conditioner; press it again to stop operation. FRESH button This button is ineffective with this model air conditioner. SPEED button Press this button to select the fan speed as follows: STRONG button Press this button to set the highest level of cooling or heating. - Page 11 Instructions (Cont.) FEEL button This button works in conjunction with Auto, Cooling or Heating mode. A temperature sensor is built in the remote control. When this mode is activated, the remote control will display the FEEL indicator and the air conditioner will maintain the set temperature based on the temperature close to the remote control.
- Page 12 Instructions (Cont.) Setting the OFF-timer time (automatic stop) • When the air conditioner is in ON state, press the TIMER button to activate the timer, the LCD displays TIMER OFF and the timer time. The time can be set from 0.5 hours to 24 hours. •...
- Page 13 Instructions (Cont.) 12 SLEEP button Press the SLEEP button, the LCD display will flash 5 times, indicating Sleep mode has been selected. After setting Sleep mode: • Cooling mode: The cooling operation enables the set temperature to rise by 1°C after 1 hour and by another 1°C after another hour. •...
-
Page 14: Automatic Mode
Instructions (Cont.) Automatic Mode In this mode the unit automatically adjusts the temperature according to the room temperature to ensure and maintain comfortable conditions. The temperature is automatically set to 24°C. • Press the MODE button to select Auto mode. •... -
Page 15: Fan Mode
Instructions (Cont.) Fan Mode In Fan mode only the air conditioner’s ventilation will be working. Setting a temperature in this mode will be ineffective. • Press the MODE button repeatedly until Fan mode is selected. • The default speed for Fan mode is LOW. Press the SPEED button, repeatedly, to select another fan speed (MID, HIGH). - Page 16 Instructions (Cont.) Manual Airflow Adjustment (horizontal air direction) • Use your hands to move the vertical airflow vane and change horizontal airflow direction. Note: Adjust the horizontal airflow direction before the air conditioner starts. Do not insert your finger into air intake or outlet vents when the air conditioner is operating.
-
Page 17: Troubleshooting Guide
Troubleshooting Guide If you experience problems with your air conditioner, check for solutions in the table below. If the problem cannot be solved by simple adjustments, call the after sales support line, or contact a licensed air conditioner technician. Problem Possible cause and solution Air conditioner does •... - Page 18 Troubleshooting Guide (Cont.) Problem Possible cause and solution Noise like running Refrigerant is flowing inside the unit — no cause for water when cooling concern. Mist is emitted Cold air used for rapid cooling of the air in the room when cooling may resemble fog —...
-
Page 19: Cleaning And Maintenance
Cleaning and Maintenance Periodic cleaning and maintenance is essential for keeping your air conditioner in good condition and working efficiently. CAUTION! Before carrying out any maintenance, make sure the air conditioner is turned off at the power socket outlet. Cleaning the Indoor Unit Turn off and unplug the air conditioner. - Page 20 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649 before returning it to the store for a refund.
