4. Reassemble in reverse order
OnandOff switches
Note! Disconnect the electric power to the machine!
1. Remove right side machine housing panel as outlined under MACHINE HOUSING PANELS.
2. Lift the locking tab to release switch from actuator body.
Switch
Locking tab
3. Disconnect lead wires from switch.
Actuator body
3
