Proline Promag 53
Endress+Hauser
2

Identification

2.1

Device designation

The "Promag 53" flow measuring system consists of the following components:
• Promag 53 transmitter
• Promag W, Promag P or Promag H sensor
In the compact version, transmitter and sensor form a single mechanical unit; in the remote version
they are installed separately.
2.1.1

Nameplate of the transmitter

PROMAG 53
Order Code:
1
Ser.No.:
TAG No.:
16-62VDC/20-55VAC
2
50-60Hz
EPD/MSU
3
I-OUT (HART), f-OUT
4
RELAY, STATUS-IN, I-IN
5
i
Fig. 2: Nameplate specifications for the "Promag 53" transmitter (example)
1 Ordering code/serial number: See the specifications on the order confirmation for the meanings of the individual
letters and digits.
2 Power supply / frequency: 16...62 V DC / 20...55 V AC / 50...60 Hz
Power consumption: 15 VA / W
3 Additional functions and software:
– EPD/MSU: with Empty Pipe Detection
– ECC: with Electrode Cleaning Circuitry
4 Outputs / inputs:
I-OUT (HART): with current output (HART)
f-OUT: with pulse/frequency output
RELAY: with relay output
STATUS-IN: with status input (auxiliary input)
I-IN: with current input
5 Reserved for information on special products
6 Ambient temperature range
7 Degree of protection
53P1H-XXXXXXXXXXXX
12345678901
ABCDEFGHJKLMNPQRST
15VA/W
6 7
IP67 / NEMA/Type 4X
-20°C (-4°F) <Tamb<+60°C (+140°F)
Pat. UK EP 541 878 EP 618 680
Pat. UK 2 084 740 EP 219 725 EP 521 169
Pat. US 5,323,156 5,479,007
Pat. US 4,382,387 4,704,908 5,351,554
2 Identification
F06-53xxxxxx-18-06-xx-xx-000
