DENT Instruments ELITEpro XC Operator's Manual page 55

Mini
20A
50A
All of the CTs in the table are available from DENT Instruments.
These are internally shunted CTs (333.3 mV output) which
make them safe to handle even when connected to an
energized wire. They are also case-insulated for 600V phase-to-
phase service. Do not use on services with higher voltages.
The following table is a list of the UL recognized (61010-1) CTs
that can be used to maintain the UL listing.
High
Performance
20A Mini
CT-HSC-020-U
CT-HSC-020-B
1.800.561.8187
Small
Medium
Midi
Split Core
Split Core
5A/15A
100A
(high
accuracy)
50A 200A
100A
Current Ratings of CTs Available from DENT Instruments
High
Performance
50A Mini
CT-HSC-050-U
CT-HSC-050-B
CAUTION: DO NOT USE UNSHUNTED CTs. ONLY USE SHUNTED CTS WITH 333 mVAC OUTPUT. ALL
DIAGRAMS IN THIS SECTION SHOW THE CT PHASING ARROW POINTING TOWARD THE LOAD.
www.
Large Split
Core
100A 600A
200A 1000A
400A
600A
High
Performance
100A Midi
CT-HMC-0100-U
CT-HMC-0100-B
UL Recognized CTs
55
.com
Clamp- RōCoil
on (Rogowski)
150A 5,000A
RōCoil mV™ Various
sizes available.
500A
Contact DENT
Instruments.
1000A
D Y K ? You can extend
ID OU NOW
the leads for a RōCoil up to 100
feet and a split core up to 1000
feet without loss of accuracy,
provided that the new wire is of
the same size or larger than the
CT lead wire.
High RōCoil
Performance (Rogowski)
200A Midi
CT-HMC-0200-U CT-RXX-1310-U
CT-HMC-0200-B CT-RXX-A4-U
