DENT Instruments ELITEpro XC Operator's Manual page 47

The following options are available for configuring Physical Power Channels.
Name
V High
V Low
PT Ratio
Type
Amps
Phase Shift
Volts
Amps
KW
KVA
PF
KVAR
See Power Measurement—Connecting CTs and Configuring Channels for information on how to
properly configure the Setup Table for single-phase 2-wire, single-phase 3-wire, 3-phase 3-wire, and
3-phase 4-wire services.
1.800.561.8187
Physical Power Channel Options
Name the channel so it describes the location or
item being monitored, such as "Water Heater"
or "Pump L1 Phase." A maximum of 20
characters is allowed.
High-side voltage. This is the "high" reference
voltage that will be measured with respect to
the reference "low" voltage, V Low.
Low-side voltage; reference for AC voltage.
Potential Transformer turns ratio. This is used
when a step-down transformer is needed to
measure AC voltages greater than 600V. The
default is 1.000.
This is the type of CT connected to the
ELITEpro XC
Depends on the type of CT selected. Displays
the value entered in the CT Size screen.
Compensate for CT Phase Shift with this setting.
Default setting is 1.1 degrees.
To record any or all of these values use the
menu to select an option.
www.
Choices are: L1, L2, L3, Neutral.
Choices are: L1, L2, L3, Neutral.
Choices are: MilliVolt or RōCoil.
Choices are: Average, Minimum, or
Maximum. In addition the integrated
hourly value in an option where
47
information@itm.com
.com
Optional
appropriate.
