Connecting The Usb Cable - DENT Instruments ELITEpro XC Operator's Manual

C
ONNECTING THE
1) Connect the USB cable to an available USB port on the computer and insert the other end in the
COM port of the ELITEpro XC.
If a USB cable is used inside an electrical panel, it must be rated to the appropriate voltage or wrapped
in an appropriately-rated insulating sleeve. The DENT-supplied cable does not meet this requirement
without an insulating sleeve.
2) Turn the breaker on.
1.800.561.8187
USB C
ABLE
Power In/Out
Power End Panel Connections
www.
33
information@itm.com
.com
USB Port
