ELITEpro XC TECHNICAL SPECIFICATIONS

Specification
Memory
Service Types
Voltage Channels
Current Channels
Maximum Current Channel
Input Voltage
Measurement Type
Line Frequency
Waveform Sampling
Channel Sampling Rate
(internal sampling)
Data Interval
Energy Measurements
Analog Measurements
Accuracy
Resolution
LED Indicators
USB (Standard)
ETHERNET (Standard)
BLUETOOTH® Wireless
Technology (Optional)
Wi-Fi Adapter (Optional)
1.800.561.8187
Single Phase-Two Wire, Single Phase-Three Wire, Three Phase-Four Wire (WYE), Three
Phase-Three Wire (DELTA), DC Systems (solar/battery).
3 channels, CAT III, 0-600 VAC (line-to-line) or 600 VDC
4 channels, .67 VAC max, +/- 1 VDC max; ideal for 333 mV full scale CTs
External transducer dependent; 200% of current transducer rating (mV CTs); Measure
up to 6000A with RōCoil CTs
True RMS using high-speed digital signal processing (DSP)
The default integration period is fifteen minutes. The choices are 1, 3, 10, 15, 30
seconds; 1, 2, 5, 10, 15, 20 and 30 minutes; 1 and 12 hours; 1 day.
Volts, Amps, Amp-Hrs (Ah), kW, kWh, kVAR, kVARh, kVA, kVAh, Displacement Power
Factor (dPF). All parameters for each phase and for system total.
0–10 Volts, 0 or 4–20 ma current loop non-isolated, external power for current loop.
User scaling for sensor reporting in physical units.
Better than 1% (<0.2% typical) for V, A, kW, kVAR, kVA, PF
0.01 Amp, 0.1 Volt, 1 Watt, 1 VAR, 1 VA, 0.01 Power Factor, 0.001 ANALOG
Tri-colors (red, green, and blue): 1 LED to indicate communication, 4 LEDs for correct
phasing (green when voltage and current on the same phase; red when incorrectly
wired, blue for wireless, Bluetooth wireless technology, and Ethernet).
Communication
USB standard (Type B). 1.8 M (6 FT) A-to-B USB Cable (included)
Standard RJ-45 Connector supports 10/100 MB Ethernet over Cat 5 or better.
Configure for DHCP or Static IP address.
Internal antenna: typical conditions <10ft up to 100ft range. Requires Bluetooth
wireless technology adapter on Window PC. Adapter must support the Serial Port
Internal Wi-Fi adapter with two separate configurations:
Internal antenna/External 5 dbi antenna: typical conditions <40ft up to 100ft
depending on environment and antenna choice.
14
www. .com
Description
16 MB non-volatile
DC/50/60Hz
12 kHz
200 samples/cycle at 60Hz
240 samples/cycle at 50Hz
Profile (SPP).
