Mocka Trestle Desk
Assembly INSTRUCTIONS
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
small
screw
screw
x32
x4
Hardware Supplied
Please check all components are included before
assembly. We recommend the table top is
trestle legs with the screws provided.
Flathead screwdriver required
mocka.co.nz | mocka.com.au
E
C
D
nut
screw
Allen key
x4
x4
x1
ed to the
Table support
brace
upper
brace
Trestle leg
Table top
middle brace
lower brace
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mocka Trestle Desk
Summary of Contents for Mocka Trestle Desk
- Page 1 Mocka Trestle Desk ASSEMBLY INSTRUCTIONS Thank you for your purchase. Please follow the instructions below for correct assembly. Table top small screw Allen key screw screw Table support brace upper Hardware Supplied brace Trestle leg middle brace Please check all components are included before assembly.
- Page 2 Mocka Trestle Desk ASSEMBLY INSTRUCTIONS Lay out two hinged trestle legs side by side, with the table Place one upper brace under the trestle legs as support brace underneath as shown. Ensure the holes shown. Repeat the process in Step 1 and attach the...
- Page 3 Mocka Trestle Desk ASSEMBLY INSTRUCTIONS Place two lower leg braces under both the trestle legs Fold and lift the whole trestle stand upright as shown at each end as shown. Align the pre-drilled holes in above. Ensure that it stands safely and all screws are the legs with holes in the braces.
- Page 4 Mocka Trestle Desk ASSEMBLY INSTRUCTIONS Place a leg brace between the two lower braces as Repeat Steps 1 to 5 to assemble the second trestle shown, aligning with the pre-drilled centre holes. Attach stand. Securely tighten all screws and bolts before in place using 2x screws (D) and 4x nuts (E).
- Page 5 Mocka Trestle Desk ASSEMBLY INSTRUCTIONS Carefully lower the table top into position above the two All done! Regularly check all screws are suitably trestle stands. Shift legs so their holes align with the screw tightened. Enjoy! holes in the underside of the table top. Fasten table top to supports from below using 4x small screws (B).
