Icom IC-F8101 Service Manual page 51

[DISPLAY-A UNIT]
REF ORDER
NO. NO.
J6001* 6510029490 10FLZ-SM2-TB (LF) (SN)
J6002* 6510031620 28FLZ-SM2-GAN-TB (LF) (SN)
J6003* 6510027950 BM13B-SRSS-TBT (LF) (SN)
J6005* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
DS1 5030003450 CMF2P2007-E
S6301* 2230001110 SKRPACE010
S6302* 2230001110 SKRPACE010
S6303* 2230001110 SKRPACE010
S6304* 2230001110 SKRPACE010
S6305* 2230001110 SKRPACE010
S6306* 2230001110 SKRPACE010
S6307* 2230001110 SKRPACE010
S6308* 2230001110 SKRPACE010
S6309* 2230001110 SKRPACE010
S6310* 2230001110 SKRPACE010
S6311* 2230001110 SKRPACE010
S6312* 2230001110 SKRPACE010
S6313* 2230001110 SKRPACE010
S6314* 2230001110 SKRPACE010
S6315* 2230001110 SKRPACE010
S6316* 2230001110 SKRPACE010
S6317* 2230001110 SKRPACE010
S6318* 2230001110 SKRPACE010
S6319* 2230001110 SKRPACE010
S6320* 2230001110 SKRPACE010
S6321* 2230001110 SKRPACE010
S6322* 2230001110 SKRPACE010
S6323* 2230001110 SKRPACE010
S6324* 2230001110 SKRPACE010
S6325* 2230001110 SKRPACE010
MP6001 8930082070 SPONGE (KY)
MP6002 8930061640 RUBBER SHEET (BH) (SHJ)
MP6003 8930068080 THERMAL SHEET (AU)TC400HS-1.4 (12X34)
[MIC-A UNIT]
REF ORDER
NO. NO.
J6901* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
J6902 6510030290 ICOM-CCBPM08MCC
[FRONT-A UNIT]
REF ORDER
NO. NO.
W1 8900020400 OPC-2216
MP1 8810009181 BT M2 X 5 NI-ZC3
MP2 8210026640 3296 FRONT PANEL
MP3 8930081610 3296 4-KEY
MP4 8930087200 3296 KEYBOARD (A)
MP5 8310077300 3296 WINDOW PLATE
8310077300 3296 WINDOW PLATE
8310077300 3296 WINDOW PLATE
8310077300 3296 WINDOW PLATE
8310087730 3296 WINDOW PLATE (A)
8310077300 3296 WINDOW PLATE
8310077300 3296 WINDOW PLATE
8310077300 3296 WINDOW PLATE
8310077300 3296 WINDOW PLATE
8310077300 3296 WINDOW PLATE
8310087730 3296 WINDOW PLATE (A)
MP6 8930082090 3296 WINDOW SHEET
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[PA-A UNIT]
REF ORDER
QTY.
NO. NO.
1 J4001* 6510018450 TMP-S01X-B1
1 J4002* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J4003* 6510015541 B4B-ZR-SM4-TF (LF) (SN)
1
1 J4004* 6510021531 IMSA-9230B-1-04Z024-PT1
J4005* 6510021531 IMSA-9230B-1-04Z024-PT1
1 J4006* 6510021391 IMSA-9230B-1-03Z024-PT1
J4007* 6510021391 IMSA-9230B-1-03Z024-PT1
1 J4008* 6510028210 SJ050010 (TMP-J01X-V6)
1 J4009* 6510027580 16FLT-SM2-TB (LF) (SN) (M)
1 J4010* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J5001* 6510028210 SJ050010 (TMP-J01X-V6)
1
1 J5002* 6510018450 TMP-S01X-B1
1 J5005* 6510018450 TMP-S01X-B1
1
1 F4001* 5220000400 FHA010-01F
1 F4002* 5210000940 1205
1
S4001* 2260003250 DECASMDC050F/60-2
1
1
1 EP4004* 6910020710 OT-047 M3
1 EP4005* 6910020710 OT-047 M3
1
1 MP4001* 8510020760 3500 PA CASE
1 MP4002* 8930076670 THERMAL SHEET (BM)TC700HS1.4 (15X22)
1 MP4004 8930065741 2590 D-EARTH SPRING-1
MP4006 8930077680 3015 PA EARTH SPRING
1
1 MP4007* 8930065741 2590 D-EARTH SPRING-1
1 MP4008* 8510021040 3500 SHIELD PLATE
1 8510021040 3500 SHIELD PLATE
8510021040 3500 SHIELD PLATE
1
1 MP4009* 8930086691 2427 EARTH SPRING (A)-1
1 8930086691 2427 EARTH SPRING (A)-1
8930086691 2427 EARTH SPRING (A)-1
2 MP4010 8930079760 SHIELD SPONGE (CO)
2 MP4011 8930079760 SHIELD SPONGE (CO)
1 MP4012* 8930059330 SHIELD SPONGE (W)
8930059330 SHIELD SPONGE (W)
8930059330 SHIELD SPONGE (W)
MP4013* 8930059330 SHIELD SPONGE (W)
8930059330 SHIELD SPONGE (W)
8930059330 SHIELD SPONGE (W)
MP5004* 8930065741 2590 D-EARTH SPRING-1
QTY.
MP5005* 8930065741 2590 D-EARTH SPRING-1
MP5006* 8930065741 2590 D-EARTH SPRING-1
1
MP5007* 8930065741 2590 D-EARTH SPRING-1
1
[DRIVER-A UNIT]
REF ORDER
NO. NO.
QTY.
MP6851* 8410002480 2429 PA HEATSINK
1
7
1
1
1
[#31] 1
[#32] 1
[#33] 1
[#34] 1
[#36] 1
[#41] 1
[#42] 1
[#43] 1
[#44] 1
[#45] 1
[#46] 1
1
7-2
DESCRIPTION QTY.
[#33]
[#43]
[#53]
[#33]
[#43]
[#53]
[#33]
[#43]
[#53]
[#33]
[#43]
[#53]
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
