Icom IC-F8101 Service Manual page 50

SECTION 7.
[CHASSIS PARTS]
REF ORDER
NO. NO.
W101** 8920001520 CAB-1190
W102** 8920000550 CAB-1058
8920000550 CAB-1058
8920000580 CAB-1065
8920000550 CAB-1058
8920000550 CAB-1058
8920000550 CAB-1058
8920000550 CAB-1058
8920000580 CAB-1065
8920000550 CAB-1058
8920000550 CAB-1058
8920000550 CAB-1058
8920000550 CAB-1058
8920000550 CAB-1058
8920000580 CAB-1065
8920000550 CAB-1058
W103** 8970024762 1.5DCOAXIAL130MM-2 C31/C31
W107** 8900019690 OPC-2117 MJ0.4JC1.5/58AU
W108** 8900016110 OPC-1680 (P0.5N30L100)
W109** 8900016110 OPC-1680 (P0.5N30L100)
W110** 8900014871 OPC-1332A-1 (P0.5N40L100) TJM
W111** 8900019630 OPC-2067
W113** 8900020281 OPC-2083B
W114** 8900019700 OPC-2128
W115** 8900018760 OPC-1969 (P0.5N20L60)
W116** 8900017660 OPC-1877 (P0.5N20L100)
W117** 8900020020 OPC-2139
W118** 8900020200 OPC-2146
W119 8920000490 CAB-1056
MP1 8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
MP2 8930070860 O-RING (BM) (TOT)
MP4 8820000530 FLANGE BOLT M4 X 8 NI
MP5 8810008661 PHBT M3 X 8 NI-ZC3
MP6 8810004301 PH M3 X10 ZK3
MP7 8810005771 BIND M3 X 8 ZK3BLACK
MP9 8930048550 2177 CLIP
MP10 8810003171 SET SCREWA M3 X 8 ZC3
MP11 8810009050 SET SCREWH M3 X10 NI
MP16 8010021983 3296 CHASSIS-3
MP17 8110009990 3296 U-COVER
MP18 8110010000 3296 L-COVER
MP22 8930082010 3296 U-SEAL (TOT)
MP23 8930082020 3296 L-SEAL (TOT)
MP24 8930082030 3296 BUSH PLATE
MP25 8930082040 3296 A-BUSH PLATE
MP37 8810003161 SET SCREWA M3 X 6 ZC3
MP42 8930069580 THERMAL SHEET (BA) TC-600HS-1.4 (14.5)
MP43 8930068820 THERMAL SHEET (AX)TC-600HS-1.4 (9.7)
MP44 8930053472 THERMAL SHEET (R)-2 TC200HS (10X10)
MP45 8950000180 CABLE TIE -80 (DENNISON DS-80)
MP46 6950000040 M-TYPE CAP (BLACK) M1K
MP48 8930083200 MS-F SD460X610-T0 (50X50)
MP51 8930056211 SHIELD SPONGE (G)-1
MP52 8930056211 SHIELD SPONGE (G)-1
MP53 8930069680 FERRITE SHEET (P)
MP54 8950001980 CABLE TIE GT-140I
MP55 8930084360 HEXAGON SPACER (AH)
MP56** 8930007500 THERMAL SHEET J
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[MAIN-A UNIT]
REF ORDER
QTY.
NO. NO.
J1001* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
1
J1002* 6510027580 16FLT-SM2-TB (LF) (SN) (M)
[#31] 1
J1003* 6510027950 BM13B-SRSS-TBT (LF) (SN)
[#32] 1
J1004* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
[#33] 1
J1005* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
[#34] 1
J1101 6510018450 TMP-S01X-B1
[#36] 1
[#41] 1 J1102 6510018450 TMP-S01X-B1
J1801* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
[#42] 1
J1802 6510028400 HU-1632-T
[#43] 1
[#44] 1
[#45] 1 BT1001* 3020000400 CR1632/BK
[#46] 1
MP1001* 8930065741 2590 D-EARTH SPRING-1
[#51] 1
MP1003* 8510020070 3296 C-SHIELD CASE Y1218
[#52] 1
[#53] 1 MP1004* 8510020080 3296 D-SHIELD CASE Y1219
MP1005* 8510020190 3296 A-SHIELD PLATE Y1231
[#54] 1
MP1006* 8510020140 3296 A-MAIN CASE Y1229
1
MP1007* 8510020150 3296 SHIELD PLATE Y1230
1
MP1009* 8510020130 3296 MAIN CASE Y1228
1
MP1010 8930065741 2590 D-EARTH SPRING-1
1
MP1012* 8930058840 SHIELD SPONGE (T)
1
MP1015* 8930058840 SHIELD SPONGE (T)
1
MP1016* 8930058840 SHIELD SPONGE (T)
1
MP1017* 8930065741 2590 D-EARTH SPRING-1
1
MP1018* 8930094110 MS-F SD460X610-T0 (25X25)
1
1 MP1019* 8930094290 INSULATION SHEET (NX)
MP1020* 8510021830 3765 S-CASE M5K
1
MP1021* 8510021830 3765 S-CASE M5K
1
MP1022* 8510021830 3765 S-CASE M5K
1
MP1023* 8510021830 3765 S-CASE M5K
[#31] 4
[#32] 4
[#33] 4
[#34] 4
[DSP1-A UNIT]
[#36] 4
[#41] 8
REF ORDER
[#42] 8
NO. NO.
[#43] 8
[#44] 8
J3001* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
[#45] 8
J3002* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
[#46] 8
J3006* 6510018961 B2B-PH-SM4-TB (LF) (SN)
[#51] 4
J3007* 6510027880 BM15B-SRSS-TBT (LF) (SN)
[#52] 4
J3303* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
[#53] 4
J3305* 6510030190 BM09B-SRSS-TBT (LF) (SN)
[#54] 4
J3307* 6510022472 40FLT-SM2-TB (LF) (SN) (M)
1
J3308* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1
30
F1* 5210001120 0466.200NR
6
F2* 5210001150 046601.5NR
8
1
MP3001 8510020040 3296 SHIELD CASE
5
2
1
1
[DSP2-A UNIT]
1
1
REF ORDER
1
NO. NO.
1
1 J8201* 6510027580 16FLT-SM2-TB (LF) (SN) (M)
2
J8202* 6510022201 40FLZ-SM2-R-TB (LF) (SN)
1
J8203* 6510023921 20FLZ-SM2-TB (LF) (SN)
4 J8204* 6510028090 ASP-153805-01
1
J8205* 6510031360 SM05B-SRSS-TB (LF) (SN)
4
1 F8001* 5210001150 046601.5NR
4 F8002* 5210001150 046601.5NR
1
1
MP8001 8510020750 3500 SHIELD CASE
1
1
4
1
7-1
