9.4

PROGRAMMING FUNCTIONS

When you select the MPLAB ICD 3 in-circuit debugger from the Programmer menu,
program items will be added to the following MPLAB IDE functions:
• Programmer Menu
• Toolbars/Status Bar
9.4.1
Program
Program specified memory areas: program memory, Configuration bits, ID locations
and/or EEPROM data. See the Settings dialog for programming options.
Verify
Verify programming of specified memory areas: program memory, Configuration bits,
ID locations and/or EEPROM data.
Read
Read specified memory areas: program memory, Configuration bits, ID locations
and/or EEPROM data. See the Settings dialog for read options.
Blank Check All
Check to see that all device memory is erased/blank.
Erase Flash Device
Erase all Flash memory.
Settings
Open the Programmer dialog (see Section 9.5 "Settings Dialog"). Set up program
and firmware options.
9.4.2
When the MPLAB ICD 3 in-circuit debugger is selected as a programmer, these
toolbars are displayed in MPLAB IDE:
• Basic program toolbar (Blank Check All, Read, Program, Verify, Erase Flash
Device).
The selected programmer (MPLAB ICD 3), as well as other programming information,
is displayed in the status bar on the bottom of the MPLAB IDE desktop. Refer to the
MPLAB IDE on-line help for information on the contents of the status bar.
© 2008 Microchip Technology Inc.
Debugger Function Summary
Programmer Menu
Toolbars/Status Bar
DS51766A-page 73
