Microchip Technology MPLAB ICD 3 User Manual page 73

9.2.2
These debugger menu options will appear on the right mouse menus in code displays,
such as program memory and source code files. Descriptions of other menu options
not listed here can be found in the MPLAB IDE Help or the MPLAB Editor Help.
Set Breakpoint
Set or remove a breakpoint at the currently selected line.
Breakpoints
Remove, enable or disable all breakpoints.
Run To Cursor
Run the program to the current cursor location. Formerly Run to Here.
Set PC at Cursor
Set the Program Counter (PC) to the cursor location.
Center Debug Location
Center the current PC line in the window.
9.2.3
When the MPLAB ICD 3 in-circuit debugger is selected as a debugger, these toolbars
are displayed in MPLAB IDE:
• Basic debug toolbar (Run, Halt, Animate, Step Into, Step Over, Step Out, Reset).
• Simple program toolbar (Read, Program, Erase Flash Device).
The selected debug tool (MPLAB ICD 3), as well as other development information, is
displayed in the status bar on the bottom of the MPLAB IDE desktop. Refer to the
MPLAB IDE on-line help for information on the contents of the status bar.
© 2008 Microchip Technology Inc.
Debugger Function Summary
Right Mouse Button Debugger Menu
Toolbars/Status Bar
DS51766A-page 67
