1.1

INTRODUCTION

An overview of the MPLAB ICD 3 in-circuit debugger system is given.

• MPLAB ICD 3 In-Circuit Debugger Defined

• How the MPLAB ICD 3 In-Circuit Debugger Helps You
• MPLAB ICD 3 In-Circuit Debugger Kit Components
• Device and Feature Support
1.2 MPLAB ICD 3 IN-CIRCUIT DEBUGGER DEFINED
The MPLAB ICD 3 in-circuit debugger is an in-circuit debugger that is controlled by a
PC running MPLAB IDE (v8.15 or greater) software on a Windows
MPLAB ICD 3 in-circuit debugger is an integral part of the development engineer's
toolsuite. The application usage can vary from software development to hardware
integration.
The MPLAB ICD 3 in-circuit debugger is a complex debugger system used for
hardware and software development of Microchip PIC
dsPIC
Programming™ (ICSP™) and Enhanced In-Circuit Serial Programming 2-wire serial
interfaces.
The debugger system will execute code like an actual device because it uses a device
with built-in emulation circuitry, instead of a special debugger chip, for emulation. All
available features of a given device are accessible interactively, and can be set and
modified by the MPLAB IDE interface.
The MPLAB ICD 3 debugger was developed for emulating embedded processors with
rich debug facilities which differ from conventional system processors in the following
aspects:
• Processors run at maximum speeds
• Capability to incorporate I/O port data input
In addition to debugger functions, the MPLAB ICD 3 in-circuit debugger system also
may be used as a development programmer.
© 2008 Microchip Technology Inc.
DEBUGGER USER'S GUIDE

Chapter 1. Overview

®
Digital Signal Controllers (DSCs) that are based on In-Circuit Serial
®
MPLAB ICD 3 IN-CIRCUIT
®
microcontrollers (MCUs) and
®
platform. The
DS51766A-page 9
