9.3.1.2
Use the buttons to add a breakpoint and set up additional break conditions. Also, a
stopwatch is available for use with breakpoints and triggers.
Note:
TABLE 9-2:
Add Breakpoint
Stopwatch
Event Breakpoints
Sequenced Breakpoints
ANDed Breakpoints
9.3.2
Click Add Breakpoint in the Breakpoints Dialog to display this dialog.
Select a breakpoint for the Breakpoints dialog here.
9.3.2.1
Set up a program memory breakpoint here.
TABLE 9-3:
Address
Breakpoint Type
Pass Count
© 2008 Microchip Technology Inc.
Debugger Function Summary
BREAKPOINT DIALOG BUTTONS
Buttons displayed will depend on the selected device.
BREAKPOINT DIALOG BUTTONS
Control Function
Add a breakpoint
Set up the stopwatch
Set up break on an event
Set up a sequence until break Section 9.3.5 "Sequenced
Set up ANDed condition until
break
Set Breakpoint Dialog
PROGRAM MEMORY TAB
PROGRAM MEMORY BREAKPOINT
Control
Location of breakpoint in hex
The type of program memory breakpoint. See the device data
sheet for more information on table reads/writes.
Program Memory Execution
address
TBLRD Program Memory
TBLWT Program Memory
Break on pass count condition.
Always break
Break occurs Count instructions after Event
instructions before breaking after event specified in "Breakpoint
type"
Event must occur Count times
"Breakpoint type" occurs Count (0-255) times
Related Dialog
Section 9.3.2 "Set Breakpoint
Dialog"
Section 9.3.3 "Stopwatch Dia-
log"
Section 9.3.4 "Event Break-
points Dialog"
Breakpoints Dialog"
Section 9.3.6 "ANDed Break-
points Dialog"
Function
–
break on execution of above
–
break on table read of above address
–
break on table write to above address
–
always break as specified in "Breakpoint type"
–
break only after event specified in
–
wait Count (0-255)
