Chapter 3. Installation; Introduction; Installing The Software; Installing The Usb Device Drivers - Microchip Technology MPLAB ICD 3 User Manual

3.1

INTRODUCTION

How to install the MPLAB ICD 3 in-circuit debugger system is discussed.

• Installing the Software

• Installing the USB Device Drivers

• Connecting the Target
• Setting Up the Target Board
• Setting Up MPLAB IDE
3.2 INSTALLING THE SOFTWARE
To install the MPLAB IDE software, first acquire the latest MPLAB IDE installation
executable (MPxxxxx.exe, where xxxxx represents the version of MPLAB IDE) from
either the Microchip web site (www.microchip.com) or the MPLAB IDE CD-ROM
(DS51123). Then run the executable and follow the screens to install MPLAB IDE.
Note:
3.3 INSTALLING THE USB DEVICE DRIVERS
Installing MPLAB IDE will preinstall the USB device drivers for the MPLAB ICD 3
in-circuit debugger. Therefore, once you have installed MPLAB IDE, connect the
debugger to the PC with a USB cable and follow the Windows "New Hardware Wizard"
to automatically install the drivers.
Expanded USB device driver installation instructions may found at:
MPLAB IDE installation directory\ICD 3\Drivers\ddri.htm
Note:
© 2008 Microchip Technology Inc.
MPLAB
DEBUGGER USER'S GUIDE

Chapter 3. Installation

MPLAB IDE v8.15 or greater is required to use the MPLAB ICD 3 in-circuit
debugger.
If a new MPLAB ICD 3 is connected to your PC, you will need to reinstall
the drivers for the new unit.
®
ICD 3 IN-CIRCUIT
DS51766A-page 21
